Using CiscoView

This chapter provides information on how to use CiscoView. It is divided into the following sections:

Note For additional information on CiscoView, see the context-sensitive help system. This comprehensive help system provides procedures, overview material, and links to related information.

Understanding the CiscoView Main Window

When you first open CiscoView, a small window appears, as shown in Figure 3-1.

Figure 3-1: CiscoView Main Menu

Many of the menu items are grayed out because you have not opened a device. Once a device is open, a larger window appears showing the front or rear panel of the device. Figure 3-2 shows the main CiscoView window displaying a Cisco 4000 device.

Figure 3-2: CiscoView Main Window, Displaying a Cisco 4000 Device

Title bar--provides the CiscoView application name and the name of the currently connected device.

Menu bar--enables you to perform CiscoView tasks, including displaying configuration and performance information for devices, cards, and ports; displaying different device representations; and controlling some of the operating characteristics of CiscoView.

Toolbar--provides a shortcut for entering important CiscoView commands such as Print, Help, Configure, or Monitor, and for launching applications, when available, such as Telnet.

System information--displays information about the type of device, the Cisco device software that is running, and additional system information. For some devices, CPU use is displayed.

Device view--displays a graphical representation of the back or front panel of the device. Click on this area to display information about different parts of the device. For example, to display information regarding the configuration of an Ethernet port on a Cisco AS5200 device rear panel, double-click the port or do the following:

Select the port. From the Menu bar, select Configure>port....
Click and hold down the right mouse button to display the port popup window. Select Configure>Port.
For more information on a particular device, press F1 with the mouse button positioned over the display for that device. All devices may not support the use of F1.

Status bar--provides a brief description of the currently selected device, interface, or port, and provides an ongoing operational status, including polling and error message information. For port status details, refer to Table 3-1.

Legend--provides information about port status (see Table 3-1).

**Table 3-1: CiscoView Port Status Legend**
Color	Indicates
Cyan or greenish blue	Dormant or waiting for an external event, such as receiving packets to transmit or dialing a remote site
Brown	Administratively down
Red	Operational failure
Yellow	Minor alarm
Magenta	Testing
Green	Up

Popup menus--go to the configuration and monitor information for the device, a card, or a port. For more information on popup menus, see "Starting CiscoView and Displaying a Device" later in this chapter.

Menus can vary, depending on the device you are using. If an option is grayed out, it is not applicable to that device. Table 3-2 and Table 3-3 describe menu items found in the CiscoView File menu and the View menu.

Table 3-2: CiscoView File Menu Items

Item	Explanation
Open Device	Displays the back panel of a new device
Open Previous	Reviews a list of devices that you have already displayed
Print	Prints the physical view of the device
Print Setup	Displays and allows you to change printer parameters
Exit	Exits CiscoView

**Table 3-3: CiscoView View Menu Items**
Item	Explanation
Refresh	Refreshes the current display by making sure that all information is current.
50%	Toggles the size of the device display between 50 and 100 percent.
Stack	Displays the devices in sequence of their physical order. It is grayed out if the device does not support the stack feature.
Front View	Displays the front panel of a device for selected devices only.
Rear	Displays the real panel of the device.
Logical	Displays the logical modem connections on a Cisco AS5200 only.

The Configure menu depends on the device you are using and what you have selected on the device to configure: the device itself, a card, or a port. For example, port configuration menu items might be Configure>basePort, or Configure>TTY_port. For more information on displaying a device, see "Starting CiscoView and Displaying a Device" later in this chapter. Table 3-4 describes typical Configure menu items.

Table 3-4: CiscoView Configure Menu Items

Item	Explanation
Device	Displays device configuration information. If nothing is selected, the device configuration is displayed.
Card	Displays card configuration information for a selected card. To view the card information, select a specific card first, then select Configure>Card.
Port	Displays port configuration information for a selected port. To view the port information, select a specific port first, then select Configure>Port. The types of ports that can be selected are modem port, port_tty, or port_con, depending on the type of device you are using.

The Monitor menu depends on the device you are using and what you have selected on the device to monitor: the device itself, a card, or a port. For more information on displaying a device, see "Starting CiscoView and Displaying a Device" later in this chapter. Table 3-5 describes the Monitor menu items.

Table 3-5: CiscoView Monitor Menu Items

Item	Explanation
Device	Displays the monitoring information for a selected device. The monitoring information describes the various performance aspects of a device, card, or port. The monitor window is a collection of graphical displays presented as dials or stripcharts, known as a dashboard. For more information on monitoring information, see "Using the Dashboard Monitor."
Card	Displays the monitoring information for a selected card.
Port	Displays the monitoring information for a selected port.

The Options menu allows you to change the presentation and the operating characteristics of CiscoView. For example, if you wanted to display the Toolbar or change the polling frequency, you do it through the Options menu. Table 3-6 describes the Options menu items.

Table 3-6: CiscoView Options Menu Items

Item	Explanation
Show Toolbar	Displays or hides the toolbar to access shortcut commands.
Show Legend	Displays or hides the legend.
Show System Information	Displays or hides system information.
Properties	Sets various operating characteristics, including polling frequency, the number of retries, the timeout interval, the Read and Write community string, MIB labels displayed as descriptors or an alias, and where to launch CiscoView: either in the same window or a separate one.
Debug	Displays troubleshooting information and should be used only with Cisco support personnel. Writes the trace for device discovery and status polling to the /tmp/.cvlog.
Debug SNMP	Displays all the SNMP traffic in encoded form to and from the device and should be used only with advice from Cisco support personnel.

The Admin menu appears on specific devices that have administrative option features. Refer to the online help for more information.

Understanding Configuration

Configuration is a process that establishes the characteristics of the devices and services on the network and records this information in the appropriate files. Configuring a device for management means supplying information about the specific device. After the specific aspects of the device are entered into the system, the system can identify the device and monitor its performance, and you can manage the device using CiscoView.

You configure devices through CiscoView. See the online help for details on configuring specific devices.

Starting CiscoView and Displaying a Device

There are several ways to display a CiscoView device, including

Using CiscoWorks
Using other network management platforms
Using the command line

The CiscoView Open Device dialog box allows you to display a device in CiscoView or to change the currently displayed device. To display information, you need to know the Read Community Name and the Write Community Name. The community string is a Simple Network Management Protocol (SNMP) security feature that requires a password to access SNMP features on a host, such as a Cisco router. Community strings used in CiscoView must match the device strings and the strings for the network management platform, otherwise permission will be denied. To display the device, do the following:

Step 1 Select File>Open Device...

Step 2 Enter the name or IP address of the device that you want to view in the Host field.

Step 3 Enter the Read Community string in the Read Community field.

Step 4 Enter the Write Community string in the Write Community field.

Step 5 Click OK.

CiscoView displays a front or rear panel of the device. To display information, change configurations, and change community string information at the management window, you need to enter the Read/Write All password in the Read Community and Write Community fields in this dialog box. If you open the device without a Write Community string, and need to change device information, you can use the Option>Properties dialog box to reset the community string information.

Note

File>Open Previous

Understanding the Display

The display you see when you first enter CiscoView is of the front or rear panel of the device. Click on various parts of the graphic to see what it contains.

After you have made a selection from the panel, select Configure or Monitor to configure or monitor the device, card, or port.

You can also use the right mouse button to get to a popup menu that allows you to configure or monitor a device, card, or port. For example, if you are using a Cisco AS5200 card and need port information, select a port on the display and click the right mouse button. The following popup menu appears:

Select one of the options, Configure, Monitor, or Reset.

Printing a Display

You can print the CiscoView Main window and specify certain printing options. To print the main window, select File>Print.

To print the main window, and specify printing options, do the following:

Step 1 Select File>Print Setup.

The CiscoView Print Setup window is displayed.

Step 2 In the Printer Name field, select a printer from the scrolling list, or enter the name of a printer.

Step 3 In the Copies field, enter the number of copies you want to print.

Step 4 In the Orientation field, select the paper orientation for printing by clicking on the radio button next to the appropriate orientation format: portrait or landscape.

Step 5 In the Format field, select your printer format type by clicking on the radio button next to the appropriate option: Ljet or PostScript. Ljet (LaserJet) prints the CiscoView Main window in PCL. PostScript prints the window in PostScript. For most low-end printers, use the Ljet option.

Step 6 Click OK to close this window.

Step 7 Select File>Print to print the window display.

Changing CiscoView Operating Characteristics

You can change some CiscoView operating characteristics, such as the polling frequency or the number of retries, from within the CiscoView application. To change the operating characteristics, do the following:

Step 1 Select Options>Properties.

The CiscoView Properties dialog box appears.

Step 2 Enter a value in the Polling Frequency field to change the polling frequency. The default varies by device. A typical value is every 60 seconds. To disable polling frequency, set the value to zero. If you set the polling frequency below 60 seconds for a number of devices, it might slow down your network. It is advisable to use low polling frequencies in specific testing situations and change them back when done. Do not poll faster than every 5 seconds.

Step 3 Enter a new value in the Retries field to change the number of retries. The default is 3. The retries value indicates how many times CiscoView retries an unresponsive device. In busy networks, SNMP datagrams can get discarded. The Retries value allows the application to continue operation during network problems. A value of 3 is considered reasonable. You can increase the value if the network is slow.

Step 4 Enter a new value in the Timeout field to change the timeout interval. A timeout is the amount of time it takes to reach a device. If it takes longer than the time specified, the device is considered either unreachable or down. The interval value is specified in seconds. The default is 3.

As a guideline, the timeout value should be set to twice the average end-to-end delay in your network. If you have a network with several slow links, you might need to set the timeout to a higher value. If you have only LAN links in your network, a value of 2 seconds is reasonable to account for processing delays and timer accuracy.

In high traffic situations, you might experience timeouts. You should not reduce the polling frequency since this can cause a general error. Increase the timeout interval if you consistently experience timeouts.

Step 5 Click the radio button next to the MIB Label translation field to display MIB descriptors instead of textual labels. Textual labels are the default. MIB descriptors are actual variable names used to manage devices, for example, locIfOutBitsSec and MIB textual labels are aliases of the MIB descriptor. The MIB textual label for locIfOutBitsSec is Output BPS.

Step 6 Enter the string in the appropriate field to enter the Read or Write Community string. This option allows you to enter the write community string for a device after you display the device.

This is useful, for example, if you want to make changes to a device or port setting but did not specify the write community string when you first opened the device display. You can enter the write community string in the Write Community field without exiting and reopening the dialog box.

Step 7 Select the window from which you want to launch CiscoView, from the same window or from a separate window. The default is Separate.

Note

This option allows you to keep the desktop from being cluttered by reusing the existing CiscoView window to display devices.

Step 8 Click OK to have the changes you made take effect.

Finding Devices

Sometimes finding a device on a large network can pose a problem, but you can find devices in CiscoView easily once you understand how the information is organized. Topics covered are:

Organizing Management Information
Categorizing Information

Organizing Management Information

CiscoView displays two primary types of information. Configuration information includes data such as information about a device chassis. Performance information includes data such as the number of Ethernet errors during a given period.

Configuration information is displayed in CiscoView Configuration windows. Performance information is displayed in CiscoView Monitor windows, which are sometimes referred to as dashboards.

Configuration and performance information is displayed for devices, cards, and ports.

Categorizing Information

CiscoView displays different categories of information for each device, card, and port. To see the categories of information that can be displayed for each component type, look at the CATEGORY popup menu on the Configuration or Monitor windows. To display a particular type of information, select the category type.

Displaying Configuration Information

CiscoView displays configuration information through the Configuration menu on the CiscoView main window or by selecting Configure from a component popup menu. CiscoView displays configuration information in the Configuration window that includes either a list of fields for a single port or a table that includes fields for multiple ports.

Displaying Performance Information

CiscoView displays performance information through the Monitor menu on the main window or by selecting Monitor from a component popup menu. Performance information is displayed in a dashboard made up of a collection of small graphical displays in one window. For more information on the dashboard monitor, see "Using the Dashboard Monitor" section.

Using the Dashboard Monitor

The dashboard monitor displays various types of network performance information, such as poll utilization errors. The display depends on the type of type of device and whether it is a device or a port. A typical dashboard monitor consists of dials or stripcharts, as shown in Figure 3-3.

Figure 3-3: Dashboard Monitor

Each display represents information provided by a MIB variable, with the common meaning indicated above the display.

Using the Grapher Tool

Within the dashboard monitor is a grapher tool that you can use to depict performance in graph form. To start the grapher tool for the network management platform, you select a graphical display in the dashboard and click the Grapher button. You can use all of the features of the grapher tool when you are troubleshooting performance problems. The network management platform grapher tool cannot support the graphing of multiple MIB variables in one data set. If the selected graphical display is composed of such formulas, the following error message appears:

Sorry, can't graph formulas.

Using CiscoView Tables

For some devices, CiscoView allows you to select multiple ports. You can display configuration or performance information for multiple ports or port groups in a single window. The entries that can be modified are displayed in pink on a color monitor. Figure 3-4 shows the table for three of the ports for a Cisco AS5200 card.

Figure 3-4: CiscoView Tables

To create a CiscoView table:

Step 1 Select multiple ports by clicking on them as you hold down the Shift key.

Step 2 Click Configure or Monitor.

A CiscoView Table appears, displaying information about all the selected ports.

You can add, delete, or modify table entries. Table 3-7 describes how to edit CiscoView Tables.h

Table 3-7: Editing CiscoView Tables

Change

Action

Add an entry

Select Create.

Modify an entry

1 .	Select the table column entry that you want to modify.

2 . View the possible values, if available, by displaying the popup menu next to the entry.

3 . Select or enter the new value in the table column.

4 . Click Modify.

5 . Click OK.

Remove an entry

1 .	Select any column in the table row that you want to delete.

2 . Click Delete.

3 . Click OK.

Using Online Help

Context-sensitive online help provides you with step-by-step instructions on how to use CiscoWorks Windows applications. The help system also provides a glossary and keyword search capability. The following table provides a quick guideline to access help from a number of vantage points:

For Information about	Do This
The help system for specific products	Select Help>Contents
How to use the help system	Select Help>Using Help
How to use CiscoView features	Select Help>Using CiscoView
Current CiscoView versions	Select Help>About CiscoView
The current device package version	Select Help>About CiscoView
How to view configuration and performance, dashboard windows, and field descriptions	Click Help in the dialog box
How to change a component value	Click Help with the cursor over the field
How to use help view	Select Help>On Help

Because CiscoView device packages are independent, the help system for each package might vary slightly.

Note Report any help or documentation bugs to cs-ciscoworks@cisco.com or bug-doc@cisco.com.

Jumps and Popup Windows

Two key concepts in using the help system are jumps and popup windows. Click on a highlighted underlined topic to jump to a help window specific to that topic. When you jump to another topic, you need to click Back on the Menu bar to go back to the previous help topic. Click on a dotted underlined term to open a popup help window, which defines that term. When you go to a popup window, press Return to return to your previous help topic.

Help Topics Window

You open the Help Topics window by selecting Help>Contents or by clicking Help Topics in an open CiscoView help window. The Help Topics window has three functional tabs:

Contents tab--links to CiscoView device and application help topics and subtopics.
Index tab--searches for keywords in the help system.
Find tab--allows you to search the help system, and indexes every help word.

: For information on how to use this tab, select Help>Using Help from the CiscoView menu bar.

Help Window Menu and Button Bars

Each help window has a menu bar and a button bar. The menu bar provides standard help functions for printing help topics, copying and pasting text from help topics, making online notes about particular help topics, and placing bookmarks.

The button bar contains the following buttons:

Contents--Opens the current help table of contents. Help topics are highlighted and underlined. Select a help topic to open a help window specific to the underlined topic. Some topics open popup windows that contain a list of subtopics. Select a help subtopic to open a help window specific to the underlined subtopic.
Back--Moves you back sequentially to previously opened help windows.
Print--Prints current help topic window.
Browse--Allows you to browse through sets of related help screens, providing quick access to overviews of particular help topics.

Overview and See Also Links

Many help windows have Overview and See Also links in the help window topics. You can select the Overview link to obtain background information for the procedure described in the current help window. Select the See Also link to view a list of related topics and go directly to those topics from the current help window.

Exit Help

Select File>Exit from Help window menu bar to exit Help.
