February 16, 1998
This document describes the features and caveats for Cisco IOS Release 11.1 AA, up to and including Release 11.1(17)AA. Release 11.1(17)AA is a platform-specific software release that supports new features for the Cisco 1600 series routers, Cisco 3600 series routers, and Cisco AS5200 access servers.This document supplements the Cisco IOS Release 11.1 documentation set with new and changed commands that support the new features in Release 11.1(17)AA.
This document will be updated as additional releases of Release 11.1 AA are made available to support new hardware and software features.
This document is divided into the following sections:
Cisco IOS Release 11.1 AA supports the following platforms:
Refer to the Release Notes for Cisco IOS Release 11.1 publication for a summary of the LAN interfaces supported on each platform and the WAN data rates and interfaces supported on each platform.
The following feature sets are available in Release 11.1 AA. Refer to Release Notes for Cisco IOS Release 11.1 for a complete list of the features provided in these sets.
The Cisco 1600 series routers feature sets are as follows:
The Cisco 3600 series routers feature sets are as follows:
The Cisco AS5200 access server feature sets are as follows:
Table 1 lists the interfaces supported in Cisco IOS Release11.1 AA.
| Interface | Cisco 1600 Series | Cisco 3600 Series | Cisco AS5200 |
|---|---|---|---|
| Ethernet (AUI) | Yes | Yes | Yes |
| Ethernet (10BaseT) | Yes | Yes | No |
| Synchronous serial | Yes | Yes | Yes |
| Asynchronous serial | Yes | Yes | Yes |
| Token Ring | No | Yes | No |
| ISDN BRI S/T | Yes | Yes | No |
| ISDN BRI U | Yes | Yes | No |
| ISDN PRI | No | Yes | Yes |
| Channelized T1 and E1 | No | Yes | Yes |
| Switched 56 kbps | Yes | No | No |
| Switched Digital Data Service (DDS) | Yes | No | No |
Use this document in conjunction with the Release Notes for Cisco IOS Release 11.1 and the Cisco IOS Release 11.1 documentation set.
Cisco IOS Release 11.1 documentation and Release 11.1 AA feature documentation can be found on the Documentation CD-ROM and on CCO.
You can access Cisco IOS software documentation, such as printed manuals and configuration notes, either on the Cisco Documentation CD-ROM or at Cisco Connection Online (CCO) on the World Wide Web.
Online documentation for Release 11.1 includes:
Additional information about CCO and the Documentation CD-ROM is in the sections
"Cisco Connection Online" and "Documentation CD-ROM" at the end of these release notes.
The related documents for each platform are as follows:
| Cisco AS5200 |
|
|
Cisco 3600 Series |
|
|
Cisco 1600 Series |
|
The memory requirements for feature sets available in Release 11.1AA are the same as those listed in the "Memory Requirements" for each of the platforms supported, included in the hardware documentation for each platform.
Table 2 lists the minimum memory requirements for the Cisco 1600 series routers feature sets.
Table 3 lists the minimum memory requirements for the Cisco 3600 series routers feature sets.
Table 4 lists the minimum memory requirements for the Cisco AS5200 access server feature sets.
| Feature Set | Cisco Router Series | Minimum Flash | Minimum DRAM |
| IP | Cisco 1600 | 4 MB | 2 MB |
| IP with AppleTalk | Cisco 1600 | 4 MB | 2 MB |
| IP with AppleTalk Plus | Cisco 1600 | 6 MB | 4 MB |
| IP Plus | Cisco 1600 | 4 MB | 4 MB |
| IP/IPX | Cisco 1600 | 4 MB | 2 MB |
| IP/IPX Plus | Cisco 1600 | 6 MB | 4 MB |
| IP/IPX/AppleTalk | Cisco 1600 | 6 MB | 4 MB |
| IP/IPX/AppleTalk Plus | Cisco 1600 | 6 MB | 4 MB |
| Feature Set | Cisco Router Series | Minimum Flash | Minimum DRAM |
| IP | Cisco 3600 | 4 MB | 16 MB |
| IP with IBM base | Cisco 3600 | 4 MB | 16 MB |
| IP/IPX | Cisco 3600 | 4 MB | 16 MB |
| IP/IPX with IBM base | Cisco 3600 | 4 MB | 16 MB |
| IP/IPX with IBM base and APPN | Cisco 3600 | 4 MB | 32 MB |
| Desktop | Cisco 3600 | 4 MB | 16 MB |
| Desktop with IBM base | Cisco 3600 | 4 MB | 24 MB |
| Enterprise | Cisco 3600 | 4 MB | 24 MB |
| Enterprise with APPN1 | Cisco 3600 | 8 MB | 32 MB |
| Cisco AS5200 | Minimum Flash Memory | Minimum Main Memory | Release 11.1 AA Runs from |
|---|---|---|---|
| IP/Managed Modems Set | 8 MB Flash | 8 MB DRAM | Flash |
| Desktop/Managed Modems Set | 8 MB Flash | 8 MB DRAM | Flash |
| Enterprise/RMON/Managed Modems Set | 8 MB Flash | 8 MB DRAM | Flash |
| Packet Memory | 9 MB Flash | 9 MB DRAM | Flash |
The following sections list the new features that are available in each release of Cisco IOS Release 11.1 AA. Features are described in detail in the documentation that accompanies the hardware.
There are no new features for these releases.
This software release now supports the Cisco AS5200 access server microcom modem module, which can connect up to 33.6 Kbps.
There are no new features for these releases.
Cisco 3600 routers, in this software release, now support the NM-1E1R2W network module.
The following new features have been added to Release 11.1(7)AA:
The following new features have been added to Release 11.1(6)AA:
The new commands for the Cisco 1600 series, Cisco 3600 series, and the AS5200 access server are listed in this section.
The ROM monitor and Cisco IOS commands that are new or modified, or have special syntax or usage for Cisco 1600 series routers, are listed. All other commands used with these routers are documented in the Cisco IOS Release 11.2 command references.
The commands are the following:
For documentation describing the new software features specific to the Cisco 1600 series routers, refer to the online feature module New Features for Cisco 1600 Series Routers.
From CCO, go to http://www.cisco.com/ via you web browser and follow this path: to Software & Support, scroll down and select Cisco Documentation. Next, click on Cisco IOS Software Configuration, click on Cisco IOS Release 11.2, and then click on Feature Guides for IOS 11.2 P.
The ROM monitor and Cisco IOS commands that are new or modified, or have special syntax or usage for Cisco 3600 series routers, are listed. All other commands used with these routers are documented in the Cisco IOS Release 11.2 command references.
The commands are the following:
For documentation describing the new software features specific to the Cisco 3600 series routers, refer to the online feature module New Features for Cisco 3600 Series Routers.
From CCO, go to http://www.cisco.com/ via you web browser and follow this path: to Software & Support, scroll down and select Cisco Documentation. Next, click on Cisco IOS Software Configuration, click on Cisco IOS Release 11.2, and then click on Feature Guides for IOS 11.2 P.
The Cisco IOS command listed below, is new or modified, or has a special syntax or usage for Cisco A5200 access server. All other commands used with this server are documented in the Cisco IOS Release 11.2 command references.
The command is the following:
For documentation describing this new software feature specific to the Cisco AS5200 access server, refer to the online feature module Channelized E1 Signaling for the Cisco AS5200.
From CCO, go to http://www.cisco.com/ via you web browser and follow this path: to Software & Support, scroll down and select Cisco Documentation. Next, click on Cisco IOS Software Configuration, click on Cisco IOS Release 11.2, and then click on Feature Guides for IOS 11.2 P.
Refer to the Release Notes for Cisco IOS Release 11.1 publication for a list of the caveats that apply to Release 11.1. The caveats that apply to Cisco IOS Release 11.1 apply to Release 11.1 AA.
Only serious caveats with release note attachments are described in these release notes. The complete caveats against Release 11.1 are available in the Cisco Documentation CD-ROM package. In the CD-ROM package, access the Cisco IOS 11.1 caveats in the Cisco IOS Release 11.1 database. If you have an account on Cisco Connection Online (CCO), you can view additional caveats using the bug search tools in the Bug Toolkit, such as the Bug Navigator.
There are no caveats for this release.
This section describes possible unexpected behavior by Release 11.1(16)AA. Unless otherwise noted, these caveats apply to all 11.1AA releases up to and including 11.1(16)AA. These caveats are listed in the 11.1 AA Release Note because they apply to specific platforms supported by Release 11.1 AA.
This section describes possible unexpected behavior by Release 11.1(15)AA. Unless otherwise noted, these caveats apply to all 11.1 CA releases up to and including 11.1(15)AA. These caveats are listed in the 11.1 AA Release Note because they apply to specific platforms supported by Release 11.1 AA.
This section describes possible unexpected behavior by Release 11.1(14)AA. Unless otherwise noted, these caveats apply to all 11.1 CA releases up to and including 11.1(14)AA. These caveats are listed in the 11.1AA Release Note because they apply to specific platforms supported by Release 11.1 AA.
This section describes possible unexpected behavior by Release 11.1(13)AA. Unless otherwise noted, these caveats apply to all 11.1 A.A. releases up to and including 11.1(13)AA. These caveats are listed in the 11.1 AA Release Note because they apply to specific platforms supported by Release 11.1 AA.
router# show interface s0:22
Serial0:22 is up, line protocol is up
Hardware is DSX1
MTU 1500 bytes, BW 64 Kbit, DLY 20000 usec, rely 129/255, load 7/255
Encapsulation PPP, loopback not set, keepalive set (10 sec)
DTR is pulsed for 1 seconds on reset
LCP Open, multilink Open
Open: ipcp
Last input 00:00:01, output 00:00:01, output hang never
Last clearing of "show interface" counters 00:01:15
Queueing strategy: fifo
Output queue 0/40, 0 drops; input queue 0/75, 0 drops
30 second input rate 2000 bits/sec, 4 packets/sec
30 second output rate 2000 bits/sec, 4 packets/sec
130 packets input, 6766 bytes, 0 no buffer
Received 0 broadcasts, 130 runts, 0 giants
130 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored, 0 abort
130 packets output, 6808 bytes, 0 underruns
0 output errors, 0 collisions, 1 interface resets
0 output buffer failures, 0 output buffers swapped out
1 carrier transitions
Timeslot(s) Used:23, Transmitter delay is 0 flags
There are no caveats for these releases.
This section describes possible unexpected behavior by Release 11.1(7)AA. Unless otherwise noted, these caveats apply to all 11.1 AA releases up to and including 11.1(7)AA. These caveats are listed in the 11.1 AA Release Note, because they apply to specific platforms supported by Release 11.1 AA.
There are no caveats for this release.
