December 29, 1997
These release notes discuss the new features and significant software components for the Cisco 4000 series for Cisco IOS Release 11.3
For more detailed information about the features and caveats in these release notes, refer to the Release Notes for Cisco IOS Release 11.3, which contains features and caveats for all 11.3 platforms. The electronic documentation can be found on the Documentation CD-ROM and on Cisco Connection Online (CCO). (Refer to the "Online Navigation" section for more details.)
These release notes discuss the following topics:
To determine which version of Cisco IOS software is running on your Cisco 4000 series router, log in to the router and enter the show version User EXEC command, as shown below:
router> show version Cisco Internetwork Operating System Software IOS (tm) 4500 Software (C4500-J-M), Version 11.3, SHARED PLATFORM, RELEASE SOFTWARE (fc1) Copyright (c) 1986-1997 by cisco Systems, Inc. Compiled Tue 11-Feb-97 19:32 by tamb Image text-base: 0x600088A0, data-base: 0x607A4000 ROM: System Bootstrap, Version 5.3(10) [tamb 10], RELEASE SOFTWARE (fc1) ROM: 4500 Bootstrap Software (C4500-BOOT-M), Version 10.3(1), RELEASE SOFTWARE (fc1) 4700 uptime is 2 minutes System restarted by reload System image file is "flash:c4500-j-mz.112-4.P", booted via flash cisco 4700 (R4K) processor (revision D) with 16384K/4096K bytes of memory. Processor board ID 03755623 R4700 processor, Implementation 33, Revision 1.0 (Level 2 Cache) G.703/E1 software, Version 1.0. Bridging software. SuperLAT software copyright 1990 by Meridian Technology Corp). X.25 software, Version 2.0, NET2, BFE and GOSIP compliant. TN3270 Emulation software (copyright 1994 by TGV Inc). 6 Ethernet/IEEE 802.3 interface(s) 2 Token Ring/IEEE 802.5 interface(s) 2 Serial network interface(s) 4294967294 terminal line(s) 128K bytes of non-volatile configuration memory. 4096K bytes of processor board System flash (Read/Write) 4096K bytes of processor board Boot flash (Read/Write) Configuration register is 0x0
The following Cisco 4000 series routers are supported by Cisco IOS Release 11.3:
This section identifies the LAN and WAN interfaces supported on Cisco 4000 series routers.
The following LAN interfaces are supported on Cisco 4000 series routers:
The following WAN data rates are supported on Cisco 4000 series routers:
The following WAN interfaces are supported on Cisco 4000 series routers:
The Cisco IOS software documentation is divided into nine modules and two master indexes. There are also four supporting documents.
Each module consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, and Cisco IOS software functionality and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Each configuration guide can be used in conjunction with its corresponding command reference.
Two master indexes provide indexing information for the Cisco IOS software documentation set: an index for the configuration guides and an index for the command references. In addition, individual books contain a book-specific index.
The Cisco IOS documentation set consists of the following books and chapter topics:
| Books | Chapter Topics |
|---|---|
|
Configuration Fundamentals Overview Cisco IOS User Interfaces File Management Interface Configuration System Management |
|
IP Addressing IP Services IP Routing Protocols |
|
AppleTalk Novell IPX |
|
Apollo Domain Banyan VINES DECnet ISO CLNS XNS |
|
ATM Frame Relay SMDS X.25 and LAPB |
|
Terminal Access Security Network Access Security Accounting and Billing Filtering Traffic Preventing Fraudulent Route Updates Network Data Encryption |
|
Dial Business Solutions and Examples Dial-In Port Setup DDR and Dial Backup Remote Node and Terminal Service Cost-Control and Large-Scale Dial Solutions VPDN |
|
Switching Paths for IP Networks Fast Switching Autonomous Switching NetFlow Switching Optimum Switching Virtual LAN (VLAN) Switching and Routing Inter-Switch Link Protocol Encapsulation IEEE 802.10 Encapsulation LAN Emulation |
|
Transparent Bridging Source-Route Bridging Remote Source-Route Bridging DLSw+ STUN and BSTUN LLC2 and SDLC IBM Network Media Translation DSPU and SNA Service Point SNA Frame Relay Access Support APPN NCIA Client/Server Topologies IBM Channel Attach |
|
|
The Cisco IOS software documentation set is available as printed manuals or electronic documents.
You can access the electronic documents either on the Cisco Documentation CD-ROM or on Cisco Connection Online (CCO) on the World Wide Web.
On the Documentation CD-ROM, go to Cisco Product Documentation, select Cisco IOS Software Configuration, and then select Cisco IOS Release 11.3.
On CCO, go to Software and Support and select Documentation. Next, select Documentation, click on Cisco IOS Software Configuration, and then click on Cisco IOS Release 11.3.
New online navigation enhancements for Release 11.3 include:
For additional information about the Documentation CD-ROM and CCO, refer to the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of these release notes.
Release 11.3 supports features in the following categories:
Detailed descriptions of the features can be found on the Documentation CD-ROM or on CCO.
On the Documentation CD-ROM, go to Cisco Product Documentation, select Cisco IOS Software Configuration, and then select Cisco IOS Release 11.3. From the bulleted list, select New Features in Release 11.3.
On CCO, go to Software and Support and select Documentation. Next, select Documentation, click on Cisco IOS Software Configuration, and then click on Cisco IOS Release 11.3. From the bulleted list, click on New Features in Release 11.3.
The Cisco IOS software is packaged into "feature sets" (also called "software images"). There are many different feature sets available, and each feature set contains a specific subset of Cisco IOS features. The feature set matrix is used to see the overall feature set organization.
The feature set matrix (See Table 1) shows the new feature set organization and lists which feature sets are available on the Cisco 4000 series for Release 11.3. The matrix uses the following symbols:
| Feature Set Matrix Symbol | Description |
|---|---|
| Basic | This feature is offered in the basic feature set. |
| Plus | This feature is offered in the Plus feature set |
| Encrypt | This feature is offered in the encryption feature sets, which consist of 40-bit (Plus 40) or 56-bit (Plus 56) data encryption feature sets. |
| Standard Feature Sets | Cisco 4000 Series |
|---|---|
| IP | Basic, Plus, Encrypt |
| Desktop (IP/IPX/AppleTalk/DEC) | Basic, Plus |
| Enterprise | Plus, Encrypt |
| Enterprise APPN | Plus, Encrypt |
Cisco IOS images with strong encryption (including, but not limited to 56-bit DES) are subject to U.S. Government export controls, and have a limited distribution. Images to be installed outside the U.S. require an export license. Customer orders might be denied or subject to delay due to U.S. Government regulations. Contact your sales representative or distributor for more information, or send e-mail to export@cisco.com.
To determine what features are available with each feature set, see Table 2. The table summarize what features you can use when running a specific feature set on the Cisco 4000 series for Cisco IOS Release 11.3. The feature set table uses the following symbols:
| Feature Set Table Symbol | Description |
|---|---|
| Yes | This feature is offered in the feature set. |
| -- | This feature is not offered in the feature set. |
| Feature Set | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Feature | IP | IP Plus | IP Plus 40 | IP Plus 56 | IP/ IPX/ AT/ DEC | IP/ IPX/AT/ DEC Plus | Enter- prise Plus | Enter- prise Plus 40 | Enter- prise Plus 56 |
| IBM Support | |||||||||
| APPN High Performance Routing | No | No | No | No | No | No | No | No | No |
| APPN MIB Enchancements | No | No | No | No | No | No | No | No | No |
| APPN over Ethernet LAN Emulation | No | No | No | No | No | No | No | No | No |
| APPN Scalability Enhancements | No | No | No | No | No | No | No | No | No |
Bisync Enhancements, includes:
|
No | Yes | Yes | Yes | No | Yes | Yes | Yes | Yes |
| Cisco MultiPath Channel (CMPC) | No | No | No | No | No | No | No | No | No |
DLSw+ Enhancements, includes:
|
No | Yes | Yes | Yes | No | Yes | Yes | Yes | Yes |
FRAS Enhancements, includes:
|
No | Yes | Yes | Yes | No | Yes | Yes | Yes | Yes |
| SRB over FDDI on Cisco 4000-M, 4500-M, and 4700-M Routers | No | No | No | No | No | No | No | No | No |
| TN3270 LU Nailing | No | No | No | No | No | No | No | No | No |
| TN3270 Server Enhancements | No | No | No | No | No | No | No | No | No |
| Token Ring LANE | No | No | No | No | No | No | No | No | No |
| Tunneling of Asynchronous Security Protocols | No | Yes | Yes | Yes | No | Yes | Yes | Yes | Yes |
| Internet | |||||||||
| DRP Server Agent | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| IP Routing | |||||||||
| Easy IP (Phase 1) | No | Yes | Yes | Yes | No | Yes | Yes | Yes | Yes |
| Hot Standby Router Protocol (HSRP) over ISL in Virtual LAN Configurations | No | No | No | No | No | No | No | No | No |
| IP Enhanced IGRP Route Authentication | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
TCP Enhancements, includes:
|
No | No | No | No | No | No | Yes | Yes | Yes |
| LAN Support | |||||||||
| AppleTalk Access List Enhancements | No | No | No | No | Yes | Yes | Yes | Yes | Yes |
| DECnet Accounting | No | No | No | No | Yes | Yes | Yes | Yes | Yes |
| IPX Named Access Lists | No | No | No | No | Yes | Yes | Yes | Yes | Yes |
| IPX SAP-after-RIP | No | No | No | No | Yes | Yes | Yes | Yes | Yes |
| NLSP Enhancements | No | No | No | No | Yes | Yes | Yes | Yes | Yes |
| NLSP Multicast Support | No | No | No | No | Yes | Yes | Yes | Yes | Yes |
| Management | |||||||||
| Cisco Call History MIB Command Line Interface | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Cisco IOS Internationalization | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Entity MIB, Phase 1 | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| SNMPv2C | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Virtual Profiles | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Multimedia | |||||||||
| IP Multicast Load Splitting across Equal-Cost Paths | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| IP Multicast over ATM Point-to-Multipoint Virtual Circuits | No | No | No | No | No | No | No | No | No |
| IP Multicast over Token Ring LANs | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Stub IP Multicast Routing | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Quality of Service | |||||||||
| RTP Header Compression | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Security | |||||||||
| Double Authentication | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Encrypted Kerberized Telnet | No | No | No | No | No | No | No | No | Yes |
| HTTP Security | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Per-User Configuration | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Reflexive Access Lists | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| TCP Intercept | No | No | No | No | No | No | Yes | Yes | Yes |
| Vendor-Proprietary RADIUS Attributes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Switching | |||||||||
| AppleTalk Routing over ISL and IEEE 802.10 in Virtual LANs | No | No | No | No | No | No | No | No | No |
| CLNS and DECnet Fast Switching over PPP | No | No | No | No | No | No | Yes | Yes | Yes |
DECnet/Vines/XNS over ISL, includes:
|
No | No | No | No | No | No | No | No | No |
| Fast-Switched Policy Routing | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| IPX Routing over ISL Virtual LANs | No | No | No | No | No | No | No | No | No |
| VIP Distributed Switching Support for IP Encapsulated in ISL | No | No | No | No | No | No | No | No | No |
| Terminal Services | |||||||||
| Virtual Interface Template Service | No | No | No | No | No | No | No | No | No |
| Virtual Templates for Protocol Translation | No | No | No | No | No | No | Yes | Yes | Yes |
| WAN Optimization | |||||||||
| ATM MIB Enhancements | No | No | No | No | No | No | No | No | No |
| PAD Enhancements | No | No | No | No | No | No | Yes | Yes | Yes |
| PAD Subaddressing | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| WAN Services | |||||||||
| Bandwidth Allocation Control Protocol | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Enhanced Local Management Interface (ELMI) | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Frame Relay Enhancements | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
Table 3 describes the memory requirements for the Cisco 4000 series platform's feature set supported by Cisco IOS Release 11.3.
Beginning with Cisco IOS Release 10.3, some software image sizes exceed 4 MB and, when compressed, exceed 2 MB. Also, some systems now require more than 1 MB of main system memory for data structure tables.
For Cisco routers to take advantage of the Release 11.3 features, you must upgrade the code or main system memory as listed in Table 3. Some platforms have specific chip or architecture requirements that affect what can be upgraded and in what increments.
| Platform/Feature Set | Minimum Required Code Memory | Required Main Memory | Release 11.2 F Runs from |
|---|---|---|---|
| Cisco 4000 | |||
| IP | 4 MB Flash | 16 MB DRAM | RAM |
| IP Plus | 4 MB Flash | 16 MB DRAM | RAM |
| IP Plus 40 | 4 MB Flash | 16 MB DRAM | RAM |
| IP Plus 56 | 4 MB Flash | 16 MB DRAM | RAM |
| IP/IPX/AT/DEC | 4 MB Flash | 16 MB DRAM | RAM |
| IP/IPX/AT/DEC Plus | 4 MB Flash | 16 MB DRAM | RAM |
| Enterprise Plus | 8 MB Flash | 16 MB DRAM | RAM |
| Enterprise Plus 40 | 8 MB Flash | 16 MB DRAM | RAM |
| Enterprise Plus 56 | 8 MB Flash | 16 MB DRAM | RAM |
| Enterprise/APPN Plus | 8 MB Flash | 32 MB DRAM | RAM |
| Enterprise/APPN Plus 40 | 8 MB Flash | 32 MB DRAM | RAM |
| Enterprise/APPN Plus 56 | 8 MB Flash | 32 MB DRAM | RAM |
| Cisco 4000-M | |||
| IP | 4 MB Flash | 8 MB DRAM | RAM |
| IP Plus | 4 MB Flash | 8 MB DRAM | RAM |
| IP Plus 40 | 4 MB Flash | 8 MB DRAM | RAM |
| IP Plus 56 | 4 MB Flash | 8 MB DRAM | RAM |
| IP/IPX/AT/DEC | 4 MB Flash | 8 MB DRAM | RAM |
| IP/IPX/AT/DEC Plus | 4 MB Flash | 16 MB DRAM | RAM |
| Enterprise Plus | 8 MB Flash | 16 MB DRAM | RAM |
| Enterprise Plus 40 | 8 MB Flash | 16 MB DRAM | RAM |
| Enterprise Plus 56 | 8 MB Flash | 16 MB DRAM | RAM |
| Enterprise/APPN Plus | 8 MB Flash | 32 MB DRAM | RAM |
| Enterprise/APPN Plus 40 | 8 MB Flash | 32 MB DRAM | RAM |
| Enterprise/APPN Plus 56 | 8 MB Flash | 32 MB DRAM | RAM |
| Cisco 4500 | |||
| IP | 4 MB Flash | 32 MB DRAM | RAM |
| IP Plus | 4 MB Flash | 32 MB DRAM | RAM |
| IP Plus 40 | 4 MB Flash | 32 MB DRAM | RAM |
| IP Plus 56 | 4 MB Flash | 32 MB DRAM | RAM |
| IP/IPX/AT/DEC | 4 MB Flash | 32 MB DRAM | RAM |
| IP/IPX/AT/DEC Plus | 8 MB Flash | 32 MB DRAM | RAM |
| Enterprise Plus | 8 MB Flash | 32 MB DRAM | RAM |
| Enterprise Plus 40 | 8 MB Flash | 32 MB DRAM | RAM |
| Enterprise Plus 56 | 8 MB Flash | 32 MB DRAM | RAM |
| Enterprise/APPN Plus | 8 MB Flash | 32 MB DRAM | RAM |
| Enterprise/APPN Plus 40 | 8 MB Flash | 32 MB DRAM | RAM |
| Enterprise/APPN Plus 56 | 8 MB Flash | 32 MB DRAM | RAM |
| Cisco 4500-M and Cisco 4700 Series | |||
| IP | 4 MB Flash | 16 MB DRAM | RAM |
| IP Plus | 4 MB Flash | 16 MB DRAM | RAM |
| IP Plus 40 | 4 MB Flash | 16 MB DRAM | RAM |
| IP Plus 56 | 4 MB Flash | 16 MB DRAM | RAM |
| IP/IPX/AT/DEC | 4 MB Flash | 16 MB DRAM | RAM |
| IP/IPX/AT/DEC Plus | 8 MB Flash | 16 MB DRAM | RAM |
| Enterprise Plus | 8 MB Flash | 16 MB DRAM | RAM |
| Enterprise Plus 40 | 8 MB Flash | 16 MB DRAM | RAM |
| Enterprise Plus 56 | 8 MB Flash | 16 MB DRAM | RAM |
| Enterprise/APPN Plus | 8 MB Flash | 32 MB DRAM | RAM |
| Enterprise/APPN Plus 40 | 8 MB Flash | 32 MB DRAM | RAM |
| Enterprise/APPN Plus 56 | 8 MB Flash | 32 MB DRAM | RAM |
For information on upgrading to a new software release, refer to the Cisco IOS Software Release Upgrade Paths and Packaging Simplification product bulletin #703.
You can also access this product bulletin on the Web at http://www.cisco.com, http://www-europe.cisco.com, or http://www-china.cisco.com. For more information, refer to the "Cisco Connection Online" section later in this document.
Possibly unexpected behavior in Cisco IOS Release 11.3 was found in the following areas:
A complete list of the caveats, including descriptions and possible workarounds, can be found on the Documentation CD-ROM or on CCO.
On the Documentation CD-ROM, go to Cisco Product Documentation, select Cisco IOS Software Configuration, and then select Cisco IOS Release 11.3. From the bulleted list, select Important Notes and Caveats for Release 11.3.
On CCO, go to Software and Support and select Documentation. Next, select Documentation, click on Cisco IOS Software Configuration, and then click on Cisco IOS Release 11.3. From the bulleted list, click on Important Notes and Caveats for Release 11.3.
