January 5, 1998
These release notes discuss the new features and caveats for the Cisco AS5100 and AS5200 for Cisco IOS Release 11.3(1) T. Use this document in conjunction with Release Notes for Cisco IOS Release 11.3. The software caveats that apply to Release 11.3 also apply to Release 11.3 T.
Additional information on Release 11.3(1) T, including software configuration information and Cisco IOS commands, are available on the World Wide Web and the Documentation CD-ROM. (See the section "Online Navigation" later in this document.)
These release notes discuss the following topics:
To determine which version of Cisco IOS software is running on your Cisco AS5100 or AS5200, log in to the router and enter the show version User EXEC command, as shown below:
router> show version Cisco Internetwork Operating System Software IOS (tm) 4500 Software (C4500-J-M), Version 11.3, SHARED PLATFORM, RELEASE SOFTWARE (fc1) Copyright (c) 1986-1997 by cisco Systems, Inc. Compiled Tue 11-Feb-97 19:32 by tamb Image text-base: 0x600088A0, data-base: 0x607A4000 ROM: System Bootstrap, Version 5.3(10) [tamb 10], RELEASE SOFTWARE (fc1) ROM: 4500 Bootstrap Software (C4500-BOOT-M), Version 10.3(1), RELEASE SOFTWARE (fc1) 4700 uptime is 2 minutes System restarted by reload System image file is "flash:c4500-j-mz.112-4.P", booted via flash cisco 4700 (R4K) processor (revision D) with 16384K/4096K bytes of memory. Processor board ID 03755623 R4700 processor, Implementation 33, Revision 1.0 (Level 2 Cache) G.703/E1 software, Version 1.0. Bridging software. SuperLAT software copyright 1990 by Meridian Technology Corp). X.25 software, Version 2.0, NET2, BFE and GOSIP compliant. TN3270 Emulation software (copyright 1994 by TGV Inc). 6 Ethernet/IEEE 802.3 interface(s) 2 Token Ring/IEEE 802.5 interface(s) 2 Serial network interface(s) 4294967294 terminal line(s) 128K bytes of non-volatile configuration memory. 4096K bytes of processor board System flash (Read/Write) 4096K bytes of processor board Boot flash (Read/Write) Configuration register is 0x0
This section identifies the LAN and WAN interfaces supported on Cisco AS5100 and AS5200.
The following LAN interfaces are supported on Cisco AS5100 and AS5200:
The following WAN data rates are supported on Cisco AS5100 and AS5200:
The following WAN interfaces are supported on Cisco AS5100 and AS5200:
For more information about the features introduced in these release notes, refer to the Feature Guide for Cisco IOS Release 11.3(1) T and the Cisco IOS Software Release 11.3(1) T Content and Platform Support Product Bulletin. These release notes should also be used in conjunction with Release Notes for Cisco IOS Release 11.3, which contains some feature and caveat information applicable to Release 11.3(1) T.
The related documents mentioned above, in addition to detailed software configuration information on the features and Cisco IOS commands supported by Release 11.3(1) T, are available on the Web and on the Documentation CD-ROM. (See the "Online Navigation" section later in this document.)
The Cisco IOS software documentation is divided into nine modules and two master indexes. There are also four supporting documents.
Each module consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, and Cisco IOS software functionality and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Each configuration guide can be used in conjunction with its corresponding command reference.
Two master indexes provide indexing information for the Cisco IOS software documentation set: an index for the configuration guides and an index for the command references. In addition, individual books contain a book-specific index.
The Cisco IOS documentation set consists of the following books and chapter topics:
| Books | Chapter Topics |
|---|---|
|
Configuration Fundamentals Overview Cisco IOS User Interfaces File Management Interface Configuration System Management |
|
IP Addressing IP Services IP Routing Protocols |
|
AppleTalk Novell IPX |
|
Apollo Domain Banyan VINES DECnet ISO CLNS XNS |
|
ATM Frame Relay SMDS X.25 and LAPB |
|
Terminal Access Security Network Access Security Accounting and Billing Filtering Traffic Preventing Fraudulent Route Updates Network Data Encryption |
|
Dial Business Solutions and Examples Dial-In Port Setup DDR and Dial Backup Remote Node and Terminal Service Cost-Control and Large-Scale Dial Solutions VPDN |
|
Switching Paths for IP Networks Fast Switching Autonomous Switching NetFlow Switching Optimum Switching Virtual LAN (VLAN) Switching and Routing Inter-Switch Link Protocol Encapsulation IEEE 802.10 Encapsulation LAN Emulation |
|
Transparent Bridging Source-Route Bridging Remote Source-Route Bridging DLSw+ STUN and BSTUN LLC2 and SDLC IBM Network Media Translation DSPU and SNA Service Point SNA Frame Relay Access Support APPN NCIA Client/Server Topologies IBM Channel Attach |
|
|
The Cisco IOS software documentation is available as printed manuals or electronic documents.
You can access the electronic documents either on Cisco Connection Online (CCO) on the World Wide Web or on the Cisco Documentation CD-ROM.
On CCO and the CD-ROM, the main path is as follows:
Cisco Connection Online: Products and Ordering: Documentation: Cisco Documentation: Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.3:
For Product Bulletins on CCO and the CD-ROM, the path is as follows:
Cisco Connection Online: Products and Ordering: More Information: Product Bulletins: Cisco IOS Release 11.3.
New online navigation enhancements for Release 11.3 include:
For additional information about the Documentation CD-ROM and CCO, refer to the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of these release notes.
The following new features are supported by Cisco AS5100 and AS5200 in Cisco IOS Release 11.3(1) T:
The Cisco IOS software is packaged into "feature sets" (also called "software images"). There are many different feature sets available, and each feature set contains a specific subset of Cisco IOS features. The feature set matrix is used to see the overall feature set organization.
The feature set matrices (See Table 1 and Table 2) show the new feature set organization and lists which feature sets are available on Cisco AS5100 and AS5200 for Release 11.3 T. The matrices use the following symbols:
| Feature Set Matrix Symbol | Description |
|---|---|
| Basic | This feature is offered in the basic feature set. |
| Plus | This feature is offered in the Plus feature set |
| Encrypt | This feature is offered in the encryption feature sets, which consist of 40-bit (Plus 40) or 56-bit (Plus 56) data encryption feature sets. |
| Standard Feature Sets | Cisco AS5100 |
|---|---|
| IP | Basic |
| Desktop (IP/IPX/AppleTalk/DEC) | Basic |
| Remote Access Server | Basic |
| Standard Feature Sets | Cisco AS5200 |
|---|---|
| IP | Basic, Plus |
| Desktop | Basic, Plus |
| Enterprise | Basic, Plus |
Cisco IOS images with strong encryption (including, but not limited to 56-bit DES) are subject to U.S. Government export controls, and have a limited distribution. Images to be installed outside the U.S. require an export license. Customer orders might be denied or subject to delay due to U.S. Government regulations. Contact your sales representative or distributor for more information, or send e-mail to export@cisco.com.
To determine what features are available with each feature set, see Table 3 and Table 4. The tables summarize what features you can use when running a specific feature set on Cisco AS5100 and AS5200 for Cisco IOS Release 11.3 T. The feature set tables use the following symbols:
| Feature Set Table Symbol | Description |
|---|---|
| Yes | This feature is offered in the feature set. |
| -- | This feature is not offered in the feature set. |
| Feature Set | |||
|---|---|---|---|
| Feature | IP | IP/IPX/AT/ DEC | Remote Access Server |
| IBM Support | |||
| APPN High Performance Routing | No | No | No |
| APPN MIB Enchancements | No | No | No |
| APPN over Ethernet LAN Emulation | No | No | No |
| APPN Scalability Enhancements | No | No | No |
Bisync Enhancements, includes:
|
No | No | No |
| Cisco MultiPath Channel (CMPC) | No | No | No |
DLSw+ Enhancements, includes:
|
No | No | No |
FRAS Enhancements, includes:
|
No | No | No |
| SRB over FDDI on Cisco 4000-M, 4500-M, and 4700-M Routers | No | No | No |
| TN3270 LU Nailing | No | No | No |
| TN3270 Server Enhancements | No | No | No |
| Token Ring LANE | No | No | No |
| Tunneling of Asynchronous Security Protocols | No | No | No |
| Internet | |||
| DRP Server Agent | Yes | Yes | No |
| IP Routing | |||
| Easy IP (Phase 1) | No | No | No |
| Hot Standby Router Protocol (HSRP) over ISL in Virtual LAN Configurations | No | No | No |
| IP Enhanced IGRP Route Authentication | Yes | Yes | Yes |
TCP Enhancements, includes:
|
No | No | No |
| LAN Support | |||
| AppleTalk Access List Enhancements | No | Yes | No |
| DECnet Accounting | No | Yes | No |
| IPX Named Access Lists | No | Yes | Yes |
| IPX SAP-after-RIP | No | Yes | Yes |
| NLSP Enhancements | No | Yes | No |
| NLSP Multicast Support | No | Yes | No |
| Management | |||
| Cisco Call History MIB Command Line Interface | Yes | Yes | No |
| Cisco IOS Internationalization | Yes | Yes | Yes |
| Entity MIB, Phase 1 | Yes | Yes | Yes |
| SNMPv2C | Yes | Yes | Yes |
| Virtual Profiles | Yes | Yes | Yes |
| Multimedia | |||
| IP Multicast Load Splitting across Equal-Cost Paths | Yes | Yes | Yes |
| IP Multicast over ATM Point-to-Multipoint Virtual Circuits | No | No | No |
| IP Multicast over Token Ring LANs | Yes | Yes | Yes |
| Stub IP Multicast Routing | Yes | Yes | Yes |
| Quality of Service | |||
| RTP Header Compression | Yes | Yes | Yes |
| Security | |||
| Double Authentication | Yes | Yes | Yes |
| Encrypted Kerberized Telnet | No | No | No |
| HTTP Security | Yes | Yes | Yes |
| Per-User Configuration | Yes | Yes | Yes |
| Reflexive Access Lists | Yes | Yes | Yes |
| TCP Intercept | No | No | No |
| Vendor-Proprietary RADIUS Attributes | Yes | Yes | Yes |
| Switching | |||
| AppleTalk Routing over ISL and IEEE 802.10 in Virtual LANs | No | No | No |
| CLNS and DECnet Fast Switching over PPP | No | No | No |
DECnet/Vines/XNS over ISL, includes:
|
No | No | No |
| Fast-Switched Policy Routing | Yes | Yes | Yes |
| IPX Routing over ISL Virtual LANs | No | No | No |
| VIP Distributed Switching Support for IP Encapsulated in ISL | No | No | No |
| Terminal Services | |||
| Virtual Interface Template Service | No | No | No |
| Virtual Templates for Protocol Translation | No | No | Yes |
| WAN Optimization | |||
| ATM MIB Enhancements | No | No | No |
| PAD Enhancements | No | No | Yes |
| PAD Subaddressing | Yes | Yes | Yes |
| WAN Services | |||
| Bandwidth Allocation Control Protocol | Yes | Yes | No |
| Enhanced Local Management Interface (ELMI) | Yes | Yes | Yes |
| Frame Relay Enhancements | Yes | Yes | Yes |
| Frame Relay MIB Extensions | Yes | Yes | Yes |
| Frame Relay Router ForeSight | Yes | Yes | Yes |
| ISDN Advice of Charge | Yes | Yes | No |
| ISDN Caller ID Callback | Yes | Yes | No |
| ISDN NFAS | Yes | Yes | No |
| LANE Per-subinterface Debug Messages | No | No | No |
| Layer 2 Forwarding--Fast Switching | No | No | Yes |
| Leased Line ISDN at 128 kbps | No | No | No |
| Multilink PPP Interleaving and Fair-Queuing Support | No | No | No |
| PPP over ATM | No | No | No |
| Telnet Extensions for Dialout | No | No | No |
| VPDN Tunnel Lookup Based on Dialed Number Information | No | No | No |
| X.25 Enhancements | Yes | Yes | Yes |
| X.25 on ISDN | Yes | Yes | No |
| X.25 Switching between PVCs and SVCs | Yes | Yes | Yes |
| X.28 Emulation | Yes | Yes | Yes |
| Feature Set | ||||||
|---|---|---|---|---|---|---|
| Feature | IP | IP Plus | Desktop | Desktop Plus | Enterprise | Enterprise Plus |
| IBM Support | ||||||
| APPN High Performance Routing | No | No | No | No | No | No |
| APPN MIB Enchancements | No | No | No | No | No | No |
| APPN over Ethernet LAN Emulation | No | No | No | No | No | No |
| APPN Scalability Enhancements | No | No | No | No | No | No |
Bisync Enhancements, includes:
|
No | No | No | No | Yes | Yes |
| Cisco MultiPath Channel (CMPC) | No | No | No | No | No | No |
DLSw+ Enhancements, includes:
|
No | No | No | No | Yes | Yes |
FRAS Enhancements, includes:
|
No | No | No | No | Yes | Yes |
| SRB over FDDI on Cisco 4000-M, 4500-M, and 4700-M Routers | No | No | No | No | No | No |
| TN3270 LU Nailing | No | No | No | No | No | No |
| TN3270 Server Enhancements | No | No | No | No | No | No |
| Token Ring LANE | No | No | No | No | No | No |
| Tunneling of Asynchronous Security Protocols | No | No | No | No | Yes | Yes |
| Internet | ||||||
| DRP Server Agent | Yes | Yes | Yes | Yes | Yes | Yes |
| IP Routing | ||||||
| Easy IP (Phase 1) | No | Yes | No | Yes | No | Yes |
| Hot Standby Router Protocol (HSRP) over ISL in Virtual LAN Configurations | No | No | No | No | No | No |
| IP Enhanced IGRP Route Authentication | Yes | Yes | Yes | Yes | Yes | Yes |
TCP Enhancements, includes:
|
No | No | No | No | Yes | Yes |
| LAN Support | ||||||
| AppleTalk Access List Enhancements | No | No | Yes | Yes | Yes | Yes |
| DECnet Accounting | No | No | Yes | Yes | Yes | Yes |
| IPX Named Access Lists | No | No | Yes | Yes | Yes | Yes |
| IPX SAP-after-RIP | No | No | Yes | Yes | Yes | Yes |
| NLSP Enhancements | No | No | Yes | Yes | Yes | Yes |
| NLSP Multicast Support | No | No | Yes | Yes | Yes | Yes |
| Management | ||||||
| Cisco Call History MIB Command Line Interface | Yes | Yes | Yes | Yes | Yes | Yes |
| Cisco IOS Internationalization | Yes | Yes | Yes | Yes | Yes | Yes |
| Entity MIB, Phase 1 | Yes | Yes | Yes | Yes | Yes | Yes |
| SNMPv2C | Yes | Yes | Yes | Yes | Yes | Yes |
| Virtual Profiles | Yes | Yes | Yes | Yes | Yes | Yes |
| Multimedia | ||||||
| IP Multicast Load Splitting across Equal-Cost Paths | Yes | Yes | Yes | Yes | Yes | Yes |
| IP Multicast over ATM Point-to-Multipoint Virtual Circuits | No | No | No | No | No | No |
| IP Multicast over Token Ring LANs | Yes | Yes | Yes | Yes | Yes | Yes |
| Stub IP Multicast Routing | Yes | Yes | Yes | Yes | Yes | Yes |
| Quality of Service | ||||||
| RTP Header Compression | Yes | Yes | Yes | Yes | Yes | Yes |
| Security | ||||||
| Double Authentication | Yes | Yes | Yes | Yes | Yes | Yes |
| Encrypted Kerberized Telnet | No | No | No | No | No | No |
| HTTP Security | Yes | Yes | Yes | Yes | Yes | Yes |
| Per-User Configuration | Yes | Yes | Yes | Yes | Yes | Yes |
| Reflexive Access Lists | Yes | Yes | Yes | Yes | Yes | Yes |
| TCP Intercept | No | No | No | No | Yes | Yes |
| Vendor-Proprietary RADIUS Attributes | Yes | Yes | Yes | Yes | Yes | Yes |
| Switching | ||||||
| AppleTalk Routing over ISL and IEEE 802.10 in Virtual LANs | No | No | No | No | No | No |
| CLNS and DECnet Fast Switching over PPP | No | No | No | No | Yes | Yes |
DECnet/Vines/XNS over ISL, includes:
|
No | No | No | No | No | No |
| Fast-Switched Policy Routing | Yes | Yes | Yes | Yes | Yes | Yes |
| IPX Routing over ISL Virtual LANs | No | No | No | No | No | No |
| VIP Distributed Switching Support for IP Encapsulated in ISL | No | No | No | No | No | No |
| Terminal Services | ||||||
| Virtual Interface Template Service | No | No | No | No | No | No |
| Virtual Templates for Protocol Translation | No | Yes | No | Yes | Yes | Yes |
| WAN Optimization | ||||||
| ATM MIB Enhancements | No | No | No | No | No | No |
| PAD Enhancements | No | Yes | No | Yes | Yes | Yes |
| PAD Subaddressing | Yes | Yes | Yes | Yes | Yes | Yes |
| WAN Services | ||||||
| Bandwidth Allocation Control Protocol | Yes | Yes | Yes | Yes | Yes | Yes |
| Enhanced Local Management Interface (ELMI) | Yes | Yes | Yes | Yes | Yes | Yes |
| Frame Relay Enhancements | Yes | Yes | Yes | Yes | Yes | Yes |
| Frame Relay MIB Extensions | Yes | Yes | Yes | Yes | Yes | Yes |
| Frame Relay Router ForeSight | Yes | Yes | Yes | Yes | Yes | Yes |
| ISDN Advice of Charge | Yes | Yes | Yes | Yes | Yes | Yes |
| ISDN Caller ID Callback | Yes | Yes | Yes | Yes | Yes | Yes |
| ISDN NFAS | Yes | Yes | Yes | Yes | Yes | Yes |
| LANE Per-subinterface Debug Messages | No | No | No | No | No | No |
| Layer 2 Forwarding--Fast Switching | No | Yes | No | Yes | Yes | Yes |
| Leased Line ISDN at 128 kbps | No | No | No | No | No | No |
| Multilink PPP Interleaving and Fair-Queuing Support | No | No | No | No | No | No |
| PPP over ATM | No | No | No | No | No | No |
| Telnet Extensions for Dialout | No | No | No | No | No | No |
| VPDN Tunnel Lookup Based on Dialed Number Information | No | No | No | No | No | No |
| X.25 Enhancements | Yes | Yes | Yes | Yes | Yes | Yes |
| X.25 on ISDN | Yes | Yes | Yes | Yes | Yes | Yes |
| X.25 Switching between PVCs and SVCs | Yes | Yes | Yes | Yes | Yes | Yes |
| X.28 Emulation | Yes | Yes | Yes | Yes | Yes | Yes |
Table 5 describes the memory requirements for the Cisco AS5100 and AS5200 platforms' feature sets supported by Cisco IOS Release 11.3(1) T.
Beginning with Cisco IOS Release 10.3, some software image sizes exceed 4 MB and, when compressed, exceed 2 MB. Also, some systems now require more than 1 MB of main system memory for data structure tables.
For Cisco routers to take advantage of the Release 11.3(1) T features, you must upgrade the code or main system memory as listed in Table 5. Some platforms have specific chip or architecture requirements that affect what can be upgraded and in what increments.
| Platform/Feature Set | Minimum Required Code Memory | Required Main Memory | Release 11.2 F Runs from |
|---|---|---|---|
| Cisco AS5100 | |||
| IP | 8 MB Flash | 6 MB DRAM | Flash |
| IP/IPX/AT/DEC | 8 MB Flash | 4 MB DRAM | Flash |
| Remote Access Server (RAS) | 8 MB Flash | 6 MB DRAM | Flash |
| Cisco AS5200 | |||
| IP | 8 MB Flash | 8 MB DRAM | Flash |
| IP Plus | 8 MB Flash | 8 MB DRAM | Flash |
| Desktop | 8 MB Flash | 8 MB DRAM | Flash |
| Desktop Plus | 8 MB Flash | 8 MB DRAM | Flash |
| Enterprise | 16 MB Flash | 8 MB DRAM | Flash |
| Enterprise Plus | 16 MB Flash | 8 MB DRAM | Flash |
For information on upgrading to a new software release, refer to the Cisco IOS Software Release Upgrade Paths and Packaging Simplification Product Bulletin #703.
You can access this product bulletin on the Web at http://www.cisco.com, http://www-europe.cisco.com, or http://www-china.cisco.com, or on the Documentation CD-ROM.
The path is as follows:
Cisco Connection Online: Products and Ordering: More Information: Product Bulletins: Cisco IOS Release 11.3: Cisco IOS Software Release 11.3 Upgrade Paths (#703, 12/97)
This section describes possibly unexpected behavior by Release 11.3(1) T. Unless otherwise noted, these caveats apply to all 11.3 releases up to and including 11.3(1) T.
When frame relay traffic shaping is enabled on a serial interface, disabling and re-enabling weighted fair queuing will cause a system restart. [CSCdj58431]
The map-class commands frame-relay bc out and frame-relay be out are accepted by the enterprise image. These parameters are relevant for SVC setup. However, the traffic shaping code does not use them. As a result, the values appear to be unset.
This behavior can be avoided by using the command:
frame-relay bc number frame-relay be number
[CSCdj65624]
Cisco Connection Online (CCO) is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional information and services.
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to the Cisco customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can access CCO in the following ways:
For a copy of CCO's Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.
Cisco documentation and additional literature are available in a CD-ROM, which ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more up to date than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM is available as a single unit or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or http://www-europe.cisco.com.
|
|
