Release Notes for Cisco 7000 Family for Cisco IOS Release 11.3 T

December 29, 1998

This release note describes the features and caveats for the Cisco 7000 family of routers that support Cisco IOS Release 11.3(1)T. The Cisco 7000 family includes the Cisco 7500 series routers, Cisco 7200 series routers, and Cisco 7000 series routers with the RSP7000 and RSP7000CI. Use these release notes in conjunction with the Release Notes for Cisco IOS Release 11.3. The software caveats that apply to Release 11.3 also apply to Release 11.3 T.

Detailed software configuration information on the new features and Cisco IOS commands supported by Release 11.3 T is available on the Documentation CD-ROM and on the Web at http://www.cisco.com. For more information, refer to the "Documentation for Release 11.3 T" section later in this document.

This release note does not describe features that are available in Release 11.3. For information about features in Release 11.3, refer to the Release Notes for Cisco IOS Release 11.3.

This release note only contains information for the Cisco 7000 family of routers. For information about other Cisco products, refer to the specific product's release notes. For additional information on features supported in Cisco IOS Release 11.3 T, refer to the Cisco IOS Software Release 11.3 T Content and Platform Support product bulletin.

Cisco Systems provides several software release "trains" based on a single version of Cisco IOS software. Maintenance releases of the Major train software (such as 11.3) deliver fixes to software defects only, thus providing the most stable software for your network, for the features you need. In addition to the Major train, there are Early Deployment (ED) trains. One ED train--Release 11.3 T--delivers both fixes to software defects and support for new Cisco platforms and new cross-platform features.

This release note discusses the following topics:

Documentation for Release 11.3 T

The Cisco IOS software documentation for Release 11.3 T features is available online only. New features for Release 11.3 T are documented in their own sections, which include configuration tasks and also new and changed command reference pages. This information supplements the Cisco IOS Release 11.3 configuration guide and command reference publications.

Cisco IOS Release 11.3 documentation and Release 11.3 T feature documentation can be found on the Documentation CD-ROM (FCS 1/19/98) and on CCO (FCS 12/29/97).

On the Documentation CD, the path is Cisco Product Documentation, Cisco IOS Software Configuration, Cisco IOS Release 11.3 database. For more information, refer to the "Documentation CD-ROM" section later in this document.

On Cisco Connection Online (CCO), http://www.cisco.com/, the path is Cisco Connection Online, Products and Ordering, Documentation, Cisco Documentation, Cisco Product Documentation, Cisco IOS Software Configuration, Cisco IOS Release 11.3. For more information, refer to the "Cisco Connection Online" section later in this document.

Note The most up-to-date Cisco IOS documentation can be found on the latest Documentation CD-ROM and on the Web. These electronic documents contain updates and modifications made after the paper documents were printed.

Platform Support for Release 11.3 T

Cisco IOS Release 11.3 T supports the following Cisco 7000 family of routers:

Cisco 7200 series (including the Cisco 7204 and Cisco 7206)
Cisco 7500 series (including the Cisco 7505, Cisco 7507, and Cisco 7513)
Cisco 7000 series routers (including the Cisco 7000 and Cisco 7010) upgraded with the 7000 Series Route Switch Processor (RSP7000) and 7000 Series Chassis Interface (RSP7000CI)

Note In this document, the term Cisco 7500/RSP series is used to represent both the Cisco 7500 series and the Cisco 7000 series equipped with the RSP7000.

Table 1 summarizes the LAN interfaces supported on the Cisco 7000 family of routers.

Table 2 summarizes the WAN data rates and interfaces supported on the Cisco 7000 family of routers.

"Yes" means that a particular data rate or interface is supported. "No" means that it is not.

**Table 1: LAN Interfaces Supported on Cisco 7000 Family of Routers**
Interface	Cisco 7200 Series	Cisco 7500/RSP Series
Ethernet (AUI)	Yes	Yes
Ethernet (10BaseT)	Yes	Yes
Ethernet (10BaseFL)	Yes	Yes
Fast Ethernet (100BaseTX)	Yes	Yes
Fast Ethernet (100BaseFX)	Yes	Yes
Token Ring 4-Mbps	Yes	Yes
Token Ring 16-Mbps	Yes	Yes
Token Ring full-duplex	Yes	Yes
FDDI DAS	Yes	Yes
FDDI SAS	No	Yes
FDDI full duplex	Yes	Yes
FDDI multimode	Yes	Yes
FDDI single-mode	Yes	Yes
ATM Interface	Yes	Yes
Channel Interface	No	Yes
Second-Generation Channel Interface	No	Yes
Parallel Channel Adapter (Bus and Tag)	No	Yes
ESCON Channel Adapter (ECA)	No	Yes
Versatile Interface	No	Yes
Second-Generation Versatile Interface	No	Yes
MultiChannel Interface (Channelized E1/T1)	Yes	Yes
100 VG Any LAN	Yes	Yes

**Table 2: WAN Data Rates and Interfaces Supported on Cisco 7000 Family of Routers**
Data Rates or Interface	Cisco 7200 Series	Cisco 7500/RSP Series
Data Rate
48/56/64 kbps	Yes	Yes
1.544/2.048 Mbps	Yes	Yes
34/45/52 Mbps	Yes	Yes
Interface
EIA/TIA-232	Yes	Yes
X.21	Yes	Yes
V.35	Yes	Yes
EIA/TIA-449	Yes	Yes
EIA-530	Yes	Yes
EIA/TIA-613 (HSSI)	Yes	Yes
ISDN BRI	Yes	No
ISDN PRI	Yes	Yes
E1-G.703/G.704	Yes	Yes
Channelized T1	Yes	Yes
Channelized E1	Yes	Yes
Channelized T3	No	Yes
Packet-Over-SONET OC-3 Interface	No	Yes
Serial	Yes	Yes

New Features in Release 11.3(1)T

The following new features are supported by the Cisco 7000 family of routers in Cisco IOS Release 11.3(1)T.

SNMP Manager--The SNMP Manager feature allows a router to serve as an SNMP manager. As an SNMP manager, the router can send SNMP requests to agents and receive SNMP responses and notifications from agents. When the SNMP manager process is enabled, the router can query other SNMP agents and process incoming SNMP traps.
SNMP Informs Requests--The SNMP Inform Requests feature allows routers to send inform requests to SNMP managers. Routers can send notifications to SNMP managers when particular events occur. For example, an agent router might send a message to a manager when the agent router experiences an error condition.

: SNMP notifications can be sent as traps or inform requests. Traps are unreliable because the receiver does not send any acknowledgment when it receives a trap. The sender cannot determine if the trap was received. However, an SNMP manager that receives an inform request acknowledges the message with an SNMP response PDU. If the manager does not receive an inform request, it does not send a response. If the sender never receives a response, the inform request can be sent again. Thus, informs are more likely to reach their intended destination.
: Because they are more reliable, informs consume more resources in the router and in the network. Unlike a trap, which is discarded as soon as it is sent, an inform request must be held in memory until a response is received or the request times out. Also, traps are sent only once, while an inform request may be retried several times. The retries increase traffic and contribute to a higher overhead on the network. Thus, traps and inform requests provide a trade-off between reliability and resources. If it is important that the SNMP manager receives every notification, use inform requests. On the other hand, if you are concerned about traffic on your network or memory in the router and you do not need to receive every notification, use traps.

x Digital Subscriber Line Bridge Support--The x digital subscriber line bridge support feature enables you to configure a router for intelligent bridge flooding for x digital subscriber line and other bridge applications.

Cisco IOS Feature Sets

This section lists Cisco IOS software feature sets available for the Cisco 7000 family of routers in Cisco IOS Release 11.3 T. Release 11.3 T supports the same feature sets as Release 11.3, but it might also have new features supported by the Cisco 7000 family of routers.

Feature Set Matrix

Table 3 provides a matrix of the new feature set organization and shows which feature sets are available on the Cisco 7000 family.

The tables use the following conventions to identify feature sets:

Yes: the feature set is offered for the platform
No: the feature set is not offered for the platform
Plus: a value-added option that contains a variable set of additional features depending on the hardware platform selected
Plus 40: a value-added option that contains a variable set of additional features depending on the hardware platform selected, including 40-bit data encryption
Plus 56: a value-added option that contains a variable set of additional features depending on the hardware platform selected, including 56-bit data encryption

Cisco IOS images with strong encryption (including, but not limited to, 56-bit DES) are subject to U.S. government export controls and have a limited distribution. Images to be installed outside the U.S. require an export license. Customer orders may be denied or subject to delay due to U.S. government regulations. Contact your sales representative or distributor for more information, or send e-mail to export@cisco.com.

**Table 3: Cisco IOS Release 11.3 T Supported Feature Sets**
Feature Set	Cisco 7200 Series	Cisco 7500/RSP Series
IP	Yes	Yes
IP Plus	No	No
IP Plus 40	No	No
IP Plus 56	No	No
IP 40	Yes	Yes
IP 56	Yes	Yes
IP/IPX	No	No
IP/IPX Plus	No	No
IP/IPX/AT	No	No
IP/IPX/AT Plus	No	No
IP/IPX/AT Plus 40	No	No
IP/IPX/AT Plus 56	No	No
IP/ASYNC	No	No
IP/IPX/ASYNC	No	No
IP/OSPF/PIM	No	No
IP/IPX/AT/IBM	No	No
IP/IPX/AT/IBM Plus	No	No
IP/IPX/AT/IBM Plus 40	No	No
IP/IPX/AT/IBM Plus 56	No	No
ISDN	No	No
Desktop	No	No
Desktop Plus	No	No
Desktop IBM	Yes	Yes
Desktop IBM 40	Yes	Yes
Desktop IBM 56	Yes	Yes
IP/IPX/AT/DEC	No	No
IP/IPX/AT/DEC Plus	No	No
Enterprise	Yes	Yes
Enterprise Plus	No	No
Enterprise Plus 40	No	No
Enterprise 40	Yes	Yes
Enterprise Plus 56	No	No
Enterprise 56	Yes	Yes
Enterprise APPN	Yes	Yes
Enterprise APPN Plus	No	No
Enterprise APPN Plus 40	No	No
Enterprise APPN Plus 56	No	No
Enterprise APPN 40	Yes	Yes
Enterprise APPN 56	Yes	Yes
Remote Access Server	No	No
FRAD	No	No
LAN FRAD	No	No
Netflow Layer 3 Switching	Yes	No

Feature Set Tables

Cisco IOS software is available in different feature sets depending on the platform. Table 4 and Table 5 list the feature sets for Cisco 7200 series routers. Table 6 and Table 7 list the feature sets for Cisco 7500 series routers and Cisco 7000 series with RSP7000 and RSP7000CI. Table 8 lists optional feature set licenses for the Cisco 7000 family of routers.

**Table 4: Cisco IOS Software Feature Sets for the Cisco 7200 Series, Part 1**
	Feature Set
Feature	IP	IP 40	IP 56	Desktop/ IBM	Desktop/ IBM 40	Desktop/ IBM 56
IBM Support
APPN High Performance Routing	No	No	No	No	No	No
APPN MIB Enchancements	No	No	No	No	No	No
APPN over Ethernet LAN Emulation	No	No	No	No	No	No
APPN Scalability Enhancements	No	No	No	No	No	No
Bisync Enhancements, includes: Bisync 3780 Support BSC Extended Addressing Block Serial Tunneling (BSTUN) over Frame Relay	Yes	Yes	Yes	Yes	Yes	Yes
Cisco MultiPath Channel (CMPC)	No	No	No	No	No	No
DLSw+ Enhancements, `includes:` Backup Peer Extensions for Encapsulation Types DLSw+ Border Peer Caching DLSw+ MIB Enhancements DLSw+ SNA Type of Service LLC2-to-SDLC Conversion between PU4 Devices NetBIOS Dial-on-Demand Routing UDP Unicast Enhancement	Yes	Yes	Yes	Yes	Yes	Yes
FRAS Enhancements, includes: FRAS Boundary Network Node Enhancement FRAS Dial Backup over DLSw+ FRAS DLCI Backup FRAS Host FRAS MIB SRB over Frame Relay	Yes	Yes	Yes	Yes	Yes	Yes
SRB over FDDI on Cisco 4000-M, 4500-M, and 4700-M Routers	No	No	No	No	No	No
TN3270 LU Nailing	No	No	No	No	No	No
TN3270 Server Enhancements	No	No	No	No	No	No
Token Ring LANE	No	No	No	No	No	No
Tunneling of Asynchronous Security Protocols	Yes	Yes	Yes	Yes	Yes	Yes
Internet
DRP Server Agent	Yes	Yes	Yes	Yes	Yes	Yes
IP Routing
Easy IP (Phase 1)	Yes	Yes	Yes	Yes	Yes	Yes
Hot Standby Router Protocol (HSRP) over ISL in Virtual LAN Configurations	Yes	Yes	Yes	Yes	Yes	Yes
IP Enhanced IGRP Route Authentication	Yes	Yes	Yes	Yes	Yes	Yes
TCP Enhancements, includes: TCP Selective Acknowledgment TCP Timestamp	No	No	No	No	No	No
LAN Support
AppleTalk Access List Enhancements	No	No	No	Yes	Yes	Yes
DECnet Accounting	No	No	No	Yes	Yes	Yes
IPX Named Access Lists	No	No	No	Yes	Yes	Yes
IPX SAP-after-RIP	No	No	No	Yes	Yes	Yes
NLSP Enhancements	No	No	No	Yes	Yes	Yes
NLSP Multicast Support	No	No	No	Yes	Yes	Yes
Management
Cisco Call History MIB Command Line Interface	Yes	Yes	Yes	Yes	Yes	Yes
Cisco IOS Internationalization	Yes	Yes	Yes	Yes	Yes	Yes
Entity MIB, Phase 1	Yes	Yes	Yes	Yes	Yes	Yes
SNMPv2C	Yes	Yes	Yes	Yes	Yes	Yes
Virtual Profiles	Yes	Yes	Yes	Yes	Yes	Yes
Multimedia
IP Multicast Load Splitting across Equal-Cost Paths	Yes	Yes	Yes	Yes	Yes	Yes
IP Multicast over ATM Point-to-Multipoint Virtual Circuits	Yes	Yes	Yes	Yes	Yes	Yes
IP Multicast over Token Ring LANs	Yes	Yes	Yes	Yes	Yes	Yes
Stub IP Multicast Routing	Yes	Yes	Yes	Yes	Yes	Yes
Quality of Service
RTP Header Compression	Yes	Yes	Yes	Yes	Yes	Yes
Security
Double Authentication	Yes	Yes	Yes	Yes	Yes	Yes
Encrypted Kerberized Telnet	No	No	No	No	No	No
HTTP Security	Yes	Yes	Yes	Yes	Yes	Yes
Per-User Configuration	Yes	Yes	Yes	Yes	Yes	Yes
Reflexive Access Lists	Yes	Yes	Yes	Yes	Yes	Yes
TCP Intercept	No	No	No	No	No	No
Vendor-Proprietary RADIUS Attributes	Yes	Yes	Yes	Yes	Yes	Yes
Switching
AppleTalk Routing over ISL and IEEE 802.10 in Virtual LANs	No	No	No	Yes	Yes	Yes
CLNS and DECnet Fast Switching over PPP	No	No	No	No	No	No
DECnet/Vines/XNS over ISL, includes: Banyan VINES Routing over ISL Virtual LANs DECnet Routing over ISL Virtual LANs XNS Routing over ISL Virtual LANs	No	No	No	No	No	No
Fast-Switched Policy Routing	Yes	Yes	Yes	Yes	Yes	Yes
IPX Routing over ISL Virtual LANs	No	No	No	Yes	Yes	Yes
VIP Distributed Switching Support for IP Encapsulated in ISL	No	No	No	No	No	No
Terminal Services
Virtual Interface Template Service	No	No	No	No	No	No
Virtual Templates for Protocol Translation	No	No	No	No	No	No
WAN Optimization
ATM MIB Enhancements	No	No	No	No	No	No
PAD Enhancements	No	No	No	No	No	No
PAD Subaddressing	Yes	Yes	Yes	Yes	Yes	Yes
WAN Services
Bandwidth Allocation Control Protocol	Yes	Yes	Yes	Yes	Yes	Yes
Enhanced Local Management Interface (ELMI)	Yes	Yes	Yes	Yes	Yes	Yes
Frame Relay Enhancements	Yes	Yes	Yes	Yes	Yes	Yes
Frame Relay MIB Extensions	Yes	Yes	Yes	Yes	Yes	Yes
Frame Relay Router ForeSight	Yes	Yes	Yes	Yes	Yes	Yes
ISDN Advice of Charge	Yes	Yes	Yes	Yes	Yes	Yes
ISDN Caller ID Callback	Yes	Yes	Yes	Yes	Yes	Yes
ISDN NFAS	Yes	Yes	Yes	Yes	Yes	Yes
LANE Per-subinterface Debug Messages	No	No	No	No	No	No
Layer 2 Forwarding--Fast Switching	No	No	No	No	No	No
Leased Line ISDN at 128 kbps	No	No	No	No	No	No
Multilink PPP Interleaving and Fair-Queuing Support	No	No	No	No	No	No
PPP over ATM	No	No	No	No	No	No
Telnet Extensions for Dialout	No	No	No	No	No	No
VPDN Tunnel Lookup Based on Dialed Number Information	No	No	No	No	No	No
X.25 Enhancements	Yes	Yes	Yes	Yes	Yes	Yes
X.25 on ISDN	No	No	No	No	No	No
X.25 Switching between PVCs and SVCs	Yes	Yes	Yes	Yes	Yes	Yes
X.28 Emulation	No	No	No	No	No	No

**Table 5: Cisco IOS Software Feature Sets for the Cisco 7200 Series, Part 2**
	Feature Set
Feature	Enterprise	Enterprise 40	Enterprise 56	Enterprise/ APPN	Enterprise/ APPN 40	Enterprise/ APPN 56	Network Layer 3 Switching
IBM Support
APPN High Performance Routing	No	No	No	Yes	Yes	Yes	No
APPN MIB Enchancements	No	No	No	Yes	Yes	Yes	No
APPN over Ethernet LAN Emulation	No	No	No	Yes	Yes	Yes	No
APPN Scalability Enhancements	No	No	No	Yes	Yes	Yes	No
Bisync Enhancements, includes: Bisync 3780 Support BSC Extended Addressing Block Serial Tunneling (BSTUN) over Frame Relay	Yes	Yes	Yes	Yes	Yes	Yes	No
Cisco MultiPath Channel (CMPC)	No	No	No	No	No	No	No
DLSw+ Enhancements, `includes:` Backup Peer Extensions for Encapsulation Types DLSw+ Border Peer Caching DLSw+ MIB Enhancements DLSw+ SNA Type of Service LLC2-to-SDLC Conversion between PU4 Devices NetBIOS Dial-on-Demand Routing UDP Unicast Enhancement	Yes	Yes	Yes	Yes	Yes	Yes	No
FRAS Enhancements, includes: FRAS Boundary Network Node Enhancement FRAS Dial Backup over DLSw+ FRAS DLCI Backup FRAS Host FRAS MIB SRB over Frame Relay	Yes	Yes	Yes	Yes	Yes	Yes	No
SRB over FDDI on Cisco 4000-M, 4500-M, and 4700-M Routers	No	No	No	No	No	No	No
TN3270 LU Nailing	No	No	No	No	No	No	No
TN3270 Server Enhancements	No	No	No	No	No	No	No
Token Ring LANE	No	No	No	No	No	No	No
Tunneling of Asynchronous Security Protocols	Yes	Yes	Yes	Yes	Yes	Yes	No
Internet
DRP Server Agent	Yes	Yes	Yes	Yes	Yes	Yes	Yes
IP Routing
Easy IP (Phase 1)	Yes	Yes	Yes	Yes	Yes	Yes	No
Hot Standby Router Protocol (HSRP) over ISL in Virtual LAN Configurations	Yes	Yes	Yes	Yes	Yes	Yes	Yes
IP Enhanced IGRP Route Authentication	Yes	Yes	Yes	Yes	Yes	Yes	Yes
TCP Enhancements, includes: TCP Selective Acknowledgment TCP Timestamp	Yes	Yes	Yes	Yes	Yes	Yes	No
LAN Support
AppleTalk Access List Enhancements	Yes	Yes	Yes	Yes	Yes	Yes	No
DECnet Accounting	Yes	Yes	Yes	Yes	Yes	Yes	No
IPX Named Access Lists	Yes	Yes	Yes	Yes	Yes	Yes	Yes
IPX SAP-after-RIP	Yes	Yes	Yes	Yes	Yes	Yes	Yes
NLSP Enhancements	Yes	Yes	Yes	Yes	Yes	Yes	Yes
NLSP Multicast Support	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Management
Cisco Call History MIB Command Line Interface	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Cisco IOS Internationalization	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Entity MIB, Phase 1	Yes	Yes	Yes	Yes	Yes	Yes	Yes
SNMPv2C	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Virtual Profiles	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Multimedia
IP Multicast Load Splitting across Equal-Cost Paths	Yes	Yes	Yes	Yes	Yes	Yes	Yes
IP Multicast over ATM Point-to-Multipoint Virtual Circuits	Yes	Yes	Yes	Yes	Yes	Yes	Yes
IP Multicast over Token Ring LANs	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Stub IP Multicast Routing	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Quality of Service
RTP Header Compression	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Security
Double Authentication	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Encrypted Kerberized Telnet	No	No	No	No	No	No	No
HTTP Security	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Per-User Configuration	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Reflexive Access Lists	No	No	No	Yes	Yes	Yes	No
TCP Intercept	Yes	Yes	Yes	Yes	Yes	Yes	No
Vendor-Proprietary RADIUS Attributes	No	No	No	Yes	Yes	Yes	Yes
Switching
AppleTalk Routing over ISL and IEEE 802.10 in Virtual LANs	Yes	Yes	Yes	Yes	Yes	Yes	No
CLNS and DECnet Fast Switching over PPP	Yes	Yes	Yes	Yes	Yes	Yes	No
DECnet/Vines/XNS over ISL, includes: Banyan VINES Routing over ISL Virtual LANs DECnet Routing over ISL Virtual LANs XNS Routing over ISL Virtual LANs	Yes	Yes	Yes	Yes	Yes	Yes	No
Fast-Switched Policy Routing	Yes	Yes	Yes	Yes	Yes	Yes	Yes
IPX Routing over ISL Virtual LANs	Yes	Yes	Yes	Yes	Yes	Yes	Yes
VIP Distributed Switching Support for IP Encapsulated in ISL	No	No	No	No	No	No	No
Terminal Services
Virtual Interface Template Service	No	No	No	No	No	No	No
Virtual Templates for Protocol Translation	Yes	Yes	Yes	Yes	Yes	Yes	No
WAN Optimization
ATM MIB Enhancements	No	No	No	No	No	No	No
PAD Enhancements	Yes	Yes	Yes	Yes	Yes	Yes	No
PAD Subaddressing	Yes	Yes	Yes	Yes	Yes	Yes	Yes
WAN Services
Bandwidth Allocation Control Protocol	Yes	Yes	Yes	Yes	Yes	Yes	No
Enhanced Local Management Interface (ELMI)	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Frame Relay Enhancements	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Frame Relay MIB Extensions	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Frame Relay Router ForeSight	Yes	Yes	Yes	Yes	Yes	Yes	Yes
ISDN Advice of Charge	Yes	Yes	Yes	Yes	Yes	Yes	Yes
ISDN Caller ID Callback	Yes	Yes	Yes	Yes	Yes	Yes	Yes
ISDN NFAS	Yes	Yes	Yes	Yes	Yes	Yes	Yes
LANE Per-subinterface Debug Messages	No	No	No	No	No	No	No
Layer 2 Forwarding--Fast Switching	No	No	No	No	No	No	No
Leased Line ISDN at 128 kbps	No	No	No	No	No	No	No
Multilink PPP Interleaving and Fair-Queuing Support	No	No	No	No	No	No	No
PPP over ATM	No	No	No	No	No	No	No
Telnet Extensions for Dialout	No	No	No	No	No	No	No
VPDN Tunnel Lookup Based on Dialed Number Information	No	No	No	No	No	No	No
X.25 Enhancements	Yes	Yes	Yes	Yes	Yes	Yes	Yes
X.25 on ISDN	No	No	No	No	No	No	No
X.25 Switching between PVCs and SVCs	Yes	Yes	Yes	Yes	Yes	Yes	Yes
X.28 Emulation	Yes	Yes	Yes	Yes	Yes	Yes	No

**Table 6: Cisco IOS Software Feature Sets for the Cisco 7500/RSP Series, Part 1**
	Feature Set
Feature	IP	IP 40	IP 56	Desktop/ IBM	Desktop/ IBM 40	Desktop/ IBM 56
IBM Support
APPN High Performance Routing	No	No	No	No	No	No
APPN MIB Enchancements	No	No	No	No	No	No
APPN over Ethernet LAN Emulation	No	No	No	No	No	No
APPN Scalability Enhancements	No	No	No	No	No	No
Bisync Enhancements, includes: Bisync 3780 Support BSC Extended Addressing Block Serial Tunneling (BSTUN) over Frame Relay	Yes	Yes	Yes	Yes	Yes	Yes
Cisco MultiPath Channel (CMPC)	Yes	Yes	Yes	Yes	Yes	Yes
DLSw+ Enhancements, `includes:` Backup Peer Extensions for Encapsulation Types DLSw+ Border Peer Caching DLSw+ MIB Enhancements DLSw+ SNA Type of Service LLC2-to-SDLC Conversion between PU4 Devices NetBIOS Dial-on-Demand Routing UDP Unicast Enhancement	Yes	Yes	Yes	Yes	Yes	Yes
FRAS Enhancements, includes: FRAS Boundary Network Node Enhancement FRAS Dial Backup over DLSw+ FRAS DLCI Backup FRAS Host FRAS MIB SRB over Frame Relay	Yes	Yes	Yes	Yes	Yes	Yes
SRB over FDDI on Cisco 4000-M, 4500-M, and 4700-M Routers	No	No	No	No	No	No
TN3270 LU Nailing	Yes	Yes	Yes	Yes	Yes	Yes
TN3270 Server Enhancements	Yes	Yes	Yes	Yes	Yes	Yes
Token Ring LANE	Yes	Yes	Yes	Yes	Yes	Yes
Tunneling of Asynchronous Security Protocols	Yes	Yes	Yes	Yes	Yes	Yes
Internet
DRP Server Agent	Yes	Yes	Yes	Yes	Yes	Yes
IP Routing
Easy IP (Phase 1)	Yes	Yes	Yes	Yes	Yes	Yes
Hot Standby Router Protocol (HSRP) over ISL in Virtual LAN Configurations	Yes	Yes	Yes	Yes	Yes	Yes
IP Enhanced IGRP Route Authentication	Yes	Yes	Yes	Yes	Yes	Yes
TCP Enhancements, includes: TCP Selective Acknowledgment TCP Timestamp	No	No	No	No	No	No
LAN Support
AppleTalk Access List Enhancements	No	No	No	Yes	Yes	Yes
DECnet Accounting	No	No	No	Yes	Yes	Yes
IPX Named Access Lists	No	No	No	Yes	Yes	Yes
IPX SAP-after-RIP	No	No	No	Yes	Yes	Yes
NLSP Enhancements	No	No	No	Yes	Yes	Yes
NLSP Multicast Support	No	No	No	Yes	Yes	Yes
Management
Cisco Call History MIB Command Line Interface	Yes	Yes	Yes	Yes	Yes	Yes
Cisco IOS Internationalization	Yes	Yes	Yes	Yes	Yes	Yes
Entity MIB, Phase 1	Yes	Yes	Yes	Yes	Yes	Yes
SNMPv2C	Yes	Yes	Yes	Yes	Yes	Yes
Virtual Profiles	Yes	Yes	Yes	Yes	Yes	Yes
Multimedia
IP Multicast Load Splitting across Equal-Cost Paths	Yes	Yes	Yes	Yes	Yes	Yes
IP Multicast over ATM Point-to-Multipoint Virtual Circuits	Yes	Yes	Yes	Yes	Yes	Yes
IP Multicast over Token Ring LANs	Yes	Yes	Yes	Yes	Yes	Yes
Stub IP Multicast Routing	Yes	Yes	Yes	Yes	Yes	Yes
Quality of Service
RTP Header Compression	Yes	Yes	Yes	Yes	Yes	Yes
Security
Double Authentication	Yes	Yes	Yes	Yes	Yes	Yes
Encrypted Kerberized Telnet	No	No	No	No	No	No
HTTP Security	Yes	Yes	Yes	Yes	Yes	Yes
Per-User Configuration	Yes	Yes	Yes	Yes	Yes	Yes
Reflexive Access Lists	Yes	Yes	Yes	Yes	Yes	Yes
TCP Intercept	No	No	No	No	No	No
Vendor-Proprietary RADIUS Attributes	Yes	Yes	Yes	Yes	Yes	Yes
Switching
AppleTalk Routing over ISL and IEEE 802.10 in Virtual LANs	No	No	No	Yes	Yes	Yes
CLNS and DECnet Fast Switching over PPP	No	No	No	No	No	No
DECnet/Vines/XNS over ISL, includes: Banyan VINES Routing over ISL Virtual LANs DECnet Routing over ISL Virtual LANs XNS Routing over ISL Virtual LANs	No	No	No	No	No	No
Fast-Switched Policy Routing	Yes	Yes	Yes	Yes	Yes	Yes
IPX Routing over ISL Virtual LANs	No	No	No	Yes	Yes	Yes
VIP Distributed Switching Support for IP Encapsulated in ISL	No	No	No	No	No	No
Terminal Services
Virtual Interface Template Service	No	No	No	No	No	No
Virtual Templates for Protocol Translation	No	No	No	No	No	No
WAN Optimization
ATM MIB Enhancements	Yes	Yes	Yes	Yes	Yes	Yes
PAD Enhancements	No	No	No	No	No	No
PAD Subaddressing	Yes	Yes	Yes	Yes	Yes	Yes
WAN Services
Bandwidth Allocation Control Protocol	Yes	Yes	Yes	Yes	Yes	Yes
Enhanced Local Management Interface (ELMI)	Yes	Yes	Yes	Yes	Yes	Yes
Frame Relay Enhancements	Yes	Yes	Yes	Yes	Yes	Yes
Frame Relay MIB Extensions	Yes	Yes	Yes	Yes	Yes	Yes
Frame Relay Router ForeSight	Yes	Yes	Yes	Yes	Yes	Yes
ISDN Advice of Charge	Yes	Yes	Yes	Yes	Yes	Yes
ISDN Caller ID Callback	Yes	Yes	Yes	Yes	Yes	Yes
ISDN NFAS	Yes	Yes	Yes	Yes	Yes	Yes
LANE Per-subinterface Debug Messages	No	No	No	No	No	No
Layer 2 Forwarding--Fast Switching	No	No	No	No	No	No
Leased Line ISDN at 128 kbps	No	No	No	No	No	No
Multilink PPP Interleaving and Fair-Queuing Support	No	No	No	No	No	No
PPP over ATM	Yes	Yes	Yes	Yes	Yes	Yes
Telnet Extensions for Dialout	No	No	No	No	No	No
VPDN Tunnel Lookup Based on Dialed Number Information	No	No	No	No	No	No
X.25 Enhancements	Yes	Yes	Yes	Yes	Yes	Yes
X.25 on ISDN	No	No	No	No	No	No
X.25 Switching between PVCs and SVCs	Yes	Yes	Yes	Yes	Yes	Yes
X.28 Emulation	No	No	No	No	No	No

**Table 7: Cisco IOS Software Feature Sets for the Cisco 7500/RSP Series, Part 2**
	Feature Set
Feature	Enterprise	Enterprise 40	Enterprise 56	Enterprise/ APPN	Enterprise/ APPN 40	Enterprise/ APPN 56
IBM Support
APPN High Performance Routing	No	No	No	Yes	Yes	Yes
APPN MIB Enchancements	No	No	No	Yes	Yes	Yes
APPN over Ethernet LAN Emulation	No	No	No	Yes	Yes	Yes
APPN Scalability Enhancements	No	No	No	Yes	Yes	Yes
Bisync Enhancements, includes: Bisync 3780 Support BSC Extended Addressing Block Serial Tunneling (BSTUN) over Frame Relay	Yes	Yes	Yes	Yes	Yes	Yes
Cisco MultiPath Channel (CMPC)	Yes	Yes	Yes	Yes	Yes	Yes
DLSw+ Enhancements, `includes:` Backup Peer Extensions for Encapsulation Types DLSw+ Border Peer Caching DLSw+ MIB Enhancements DLSw+ SNA Type of Service LLC2-to-SDLC Conversion between PU4 Devices NetBIOS Dial-on-Demand Routing UDP Unicast Enhancement	Yes	Yes	Yes	Yes	Yes	Yes
FRAS Enhancements, includes: FRAS Boundary Network Node Enhancement FRAS Dial Backup over DLSw+ FRAS DLCI Backup FRAS Host FRAS MIB SRB over Frame Relay	Yes	Yes	Yes	Yes	Yes	Yes
SRB over FDDI on Cisco 4000-M, 4500-M, and 4700-M Routers	No	No	No	No	No	No
TN3270 LU Nailing	Yes	Yes	Yes	Yes	Yes	Yes
TN3270 Server Enhancements	Yes	Yes	Yes	Yes	Yes	Yes
Token Ring LANE	Yes	Yes	Yes	Yes	Yes	Yes
Tunneling of Asynchronous Security Protocols	Yes	Yes	Yes	Yes	Yes	Yes
Internet
DRP Server Agent	Yes	Yes	Yes	Yes	Yes	Yes
IP Routing
Easy IP (Phase 1)	Yes	Yes	Yes	Yes	Yes	Yes
Hot Standby Router Protocol (HSRP) over ISL in Virtual LAN Configurations	Yes	Yes	Yes	Yes	Yes	Yes
IP Enhanced IGRP Route Authentication	Yes	Yes	Yes	Yes	Yes	Yes
TCP Enhancements, includes: TCP Selective Acknowledgment TCP Timestamp	Yes	Yes	Yes	Yes	Yes	Yes
LAN Support
AppleTalk Access List Enhancements	Yes	Yes	Yes	Yes	Yes	Yes
DECnet Accounting	Yes	Yes	Yes	Yes	Yes	Yes
IPX Named Access Lists	Yes	Yes	Yes	Yes	Yes	Yes
IPX SAP-after-RIP	Yes	Yes	Yes	Yes	Yes	Yes
NLSP Enhancements	Yes	Yes	Yes	Yes	Yes	Yes
NLSP Multicast Support	Yes	Yes	Yes	Yes	Yes	Yes
Management
Cisco Call History MIB Command Line Interface	Yes	Yes	Yes	Yes	Yes	Yes
Cisco IOS Internationalization	Yes	Yes	Yes	Yes	Yes	Yes
Entity MIB, Phase 1	Yes	Yes	Yes	Yes	Yes	Yes
SNMPv2C	Yes	Yes	Yes	Yes	Yes	Yes
Virtual Profiles	Yes	Yes	Yes	Yes	Yes	Yes
Multimedia
IP Multicast Load Splitting across Equal-Cost Paths	Yes	Yes	Yes	Yes	Yes	Yes
IP Multicast over ATM Point-to-Multipoint Virtual Circuits	Yes	Yes	Yes	Yes	Yes	Yes
IP Multicast over Token Ring LANs	Yes	Yes	Yes	Yes	Yes	Yes
Stub IP Multicast Routing	Yes	Yes	Yes	Yes	Yes	Yes
Quality of Service
RTP Header Compression	Yes	Yes	Yes	Yes	Yes	Yes
Security
Double Authentication	Yes	Yes	Yes	Yes	Yes	Yes
Encrypted Kerberized Telnet	No	No	Yes	No	No	Yes
HTTP Security	Yes	Yes	Yes	Yes	Yes	Yes
Per-User Configuration	Yes	Yes	Yes	Yes	Yes	Yes
Reflexive Access Lists	Yes	Yes	Yes	Yes	Yes	Yes
TCP Intercept	Yes	Yes	Yes	Yes	Yes	Yes
Vendor-Proprietary RADIUS Attributes	Yes	Yes	Yes	Yes	Yes	Yes
Switching
AppleTalk Routing over ISL and IEEE 802.10 in Virtual LANs	Yes	Yes	Yes	Yes	Yes	Yes
CLNS and DECnet Fast Switching over PPP	Yes	Yes	Yes	Yes	Yes	Yes
DECnet/Vines/XNS over ISL, includes: Banyan VINES Routing over ISL Virtual LANs DECnet Routing over ISL Virtual LANs XNS Routing over ISL Virtual LANs	Yes	Yes	Yes	Yes	Yes	Yes
Fast-Switched Policy Routing	Yes	Yes	Yes	Yes	Yes	Yes
IPX Routing over ISL Virtual LANs	Yes	Yes	Yes	Yes	Yes	Yes
VIP Distributed Switching Support for IP Encapsulated in ISL	No	No	No	No	No	No
Terminal Services
Virtual Interface Template Service	No	No	No	No	No	No
Virtual Templates for Protocol Translation	Yes	Yes	Yes	Yes	Yes	Yes
WAN Optimization
ATM MIB Enhancements	Yes	Yes	Yes	Yes	Yes	Yes
PAD Enhancements	Yes	Yes	Yes	Yes	Yes	Yes
PAD Subaddressing	Yes	Yes	Yes	Yes	Yes	Yes
WAN Services
Bandwidth Allocation Control Protocol	Yes	Yes	Yes	Yes	Yes	Yes
Enhanced Local Management Interface (ELMI)	Yes	Yes	Yes	Yes	Yes	Yes
Frame Relay Enhancements	Yes	Yes	Yes	Yes	Yes	Yes
Frame Relay MIB Extensions	Yes	Yes	Yes	Yes	Yes	Yes
Frame Relay Router ForeSight	Yes	Yes	Yes	Yes	Yes	Yes
ISDN Advice of Charge	Yes	Yes	Yes	Yes	Yes	Yes
ISDN Caller ID Callback	Yes	Yes	Yes	Yes	Yes	Yes
ISDN NFAS	Yes	Yes	Yes	Yes	Yes	Yes
LANE Per-subinterface Debug Messages	No	No	No	No	No	No
Layer 2 Forwarding--Fast Switching	No	No	No	No	No	No
Leased Line ISDN at 128 kbps	No	No	No	No	No	No
Multilink PPP Interleaving and Fair-Queuing Support	No	No	No	No	No	No
PPP over ATM	Yes	Yes	Yes	Yes	Yes	Yes
Telnet Extensions for Dialout	No	No	No	No	No	No
VPDN Tunnel Lookup Based on Dialed Number Information	No	No	No	No	No	No
X.25 Enhancements	Yes	Yes	Yes	Yes	Yes	Yes
X.25 on ISDN	No	No	No	No	No	No
X.25 Switching between PVCs and SVCs	Yes	Yes	Yes	Yes	Yes	Yes
X.28 Emulation	Yes	Yes	Yes	Yes	Yes	Yes

**Table 8: Optional Feature Set Licenses for Cisco 7000 Family of Routers**
WAN Packet Protocols
ATM DXI
Frame Relay
Frame Relay switching
Frame Relay SVC support (DTE)
Frame Relay traffic shaping
SMDS over ATM
X.25
X.25 switching
Interdomain Routing
BGP
BGP4¹
EGP for Internet scale routing
VIP/VIP2 support²
Included automatically with VIP order
CIP Support2, ³
SNA support
TCP/IP offload
NetFlow Switching⁴
NetFlow Switching software⁵

¹ BGP4 includes soft configuration, multipath support, and prefix filtering with inbound route maps.
² Supported on Cisco 7500 series and Cisco 7000 series with the RSP7000 and RSP7000CI.
³ CIP orders must include one or both of the licenses.
⁴ Cisco 7200 series only.
⁵ NetFlow supports IP over all interfaces with optimal performance on Ethernet, FDDI, and HDLC.

Upgrading to a New Software Release

For information on upgrading to a new software release, refer to the Cisco IOS Software Release Upgrade Paths and Packaging Simplification product bulletin #703.

You can also access this product bulletin on the Web at http://www.cisco.com. For more information, refer to the "Cisco Connection Online" section later in this document.

Memory Requirements

Table 9 describe the memory requirements for the feature sets on for the Cisco 7000 family of routers supported by Cisco IOS Release 11.3 T.

Cisco 7200 series routers are shipped with an 8-, 16-, or 20-MB Flash memory card. Cisco 7500 series routers and Cisco 7000 series routers with the RSP7000 and RSP7000CI are shipped with a 16- or 20-MB Flash memory card.

All feature sets for Cisco 7500 series and Cisco 7000 series routers with RSP7000 and RSP7000CI include VIP support.

**Table 9: Memory Requirements for Cisco 7000 Family of Routers**
Feature Set by Router	Image Name	Required Flash Memory	Required DRAM Memory	Release 11.3 T Runs From
Cisco 7200 Series
IP Routing	c7200-is-mz	8 MB Flash	32 MB DRAM	RAM
IP Routing/Encrypt 40	c7200-is40-mz	8 MB Flash	32 MB DRAM	RAM
IP Routing/Encrypt 56	c7200-is56-mz	8 MB Flash	32 MB DRAM	RAM
Desktop/IBM	c7200-ds-mz	8 MB Flash	32 MB DRAM	RAM
Desktop/IBM/Encrypt 40	c7200-ds40-mz	8 MB Flash	32 MB DRAM	RAM
Desktop/IBM/Encrypt 56	c7200-ds56-mz	8 MB Flash	32 MB DRAM	RAM
Enterprise	c7200-js-mz	8 MB Flash	32 MB DRAM	RAM
Enterprise/Encrypt 40	c7200-js40-mz	8 MB Flash	32 MB DRAM	RAM
Enterprise/Encrypt 56	c7200-js56-mz	8 MB Flash	32 MB DRAM	RAM
Enterprise/APPN	c7200-ajs-mz	8 MB Flash	32 MB DRAM	RAM
Enterprise/APPN/ Encrypt 40	c7200-ajs40-mz	8 MB Flash	32 MB DRAM	RAM
Enterprise/APPN/ Encrypt 56	c7200-ajs56-mz	8 MB Flash	32 MB DRAM	RAM
Network Layer 3 Switching	c7200-inu-mz	8 MB Flash	32 MB DRAM	RAM
Cisco 7500 Series and Cisco 7000 Series with RSP7000 and RSP7000CI
IP Routing	rsp-isv-mz	16 MB Flash	32 MB DRAM	RAM
IP Routing/Encrypt 40	rsp-isv40-mz	16 MB Flash	32 MB DRAM	RAM
IP Routing/Encrypt 56	rsp-isv56-mz	8 MB Flash	32 MB DRAM	RAM
Desktop/IBM	rsp-dsv-mz	16 MB Flash	32 MB DRAM	RAM
Desktop/IBM/Encrypt 40	rsp-dsv40-mz	16 MB Flash	32 MB DRAM	RAM
Desktop/IBM/Encrypt 56	rsp-dsv56-mz	16 MB Flash	32 MB DRAM	RAM
Enterprise	rsp-jsv-mz	16 MB Flash	32 MB DRAM	RAM
Enterprise/Encrypt 40	rsp-jsv40-mz	16 MB Flash	32 MB DRAM	RAM
Enterprise/Encrypt 56	rsp-jsv56-mz	16 MB Flash	32 MB DRAM	RAM
Enterprise/APPN	rsp-ajsv-mz	16 MB Flash	32 MB DRAM	RAM
Enterprise/APPN/Encrypt 40	rsp-ajsv40-mz	16 MB Flash	32 MB DRAM	RAM
Enterprise/APPN/Encrypt 56	rsp-ajsv56-mz	16 MB Flash	32 MB DRAM	RAM

Release 11.3 T Caveats

Refer to the Release Notes for Cisco IOS Release 11.3 publication for a list of the caveats that apply to Release 11.3. The caveats that apply to Cisco IOS Release 11.3 apply to Release 11.3 T.

The complete caveats against Release 11.3 are also available in the Cisco Documentation CD-ROM package. In the CD-ROM package, access the Cisco IOS 11.3 caveats in the Cisco IOS Release 11.3 database.

If you have an account on Cisco Connection Online (CCO), you can view additional caveats using the bug search tools in the Bug Toolkit, such as the Bug Navigator.

The following sections list caveats for Release 11.3 T that apply to the Cisco 7000 family of routers. For Release 11.3 T caveats for other Cisco products, refer to the specific product's release notes.

Release 11.3(1)T Caveats

This section describes possibly unexpected behavior by Release 11.3(1)T. Unless otherwise noted, these caveats apply to all 11.3 T releases up to and including 11.3(1)T.

Basic System Services

When frame relay traffic shaping is enabled on a serial interface, disabling and re-enabling weighted fair queuing will cause a system restart. [CSCdj58431]

Wide-Area Networking

The map-class commands frame-relay bc out and frame-relay be out are accepted by the enterprise image. These parameters are relevant for SVC setup. However, the traffic shaping code doesn't use them. As a result, the values appear to be unset. This behavior can be avoided by using the commands: frame-relay bc and frame-relay be. [CSCdj65624]

Cisco Connection Online

Cisco Connection Online (CCO) is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional information and services.

Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.

CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.

You can access CCO in the following ways:

WWW: http://www.cisco.com
WWW: http://www-europe.cisco.com
WWW: http://www-china.cisco.com
Telnet: cco.cisco.com
Modem: From North America, 408 526-8070; from Europe, 33 1 64 46 40 82. Use the following terminal settings: VT100 emulation; databits: 8; parity: none; stop bits: 1; and connection rates up to 28.8 kbps.

For a copy of CCO's Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.

Note If you are a network administrator and need personal technical assistance with a Cisco product that is under warranty or covered by a maintenance contract, contact Cisco's Technical Assistance Center (TAC) at 800 553-2447, 408 526-7209, or tac@cisco.com. To obtain general information about Cisco Systems, Cisco products, or upgrades, contact 800 553-6387, 408 526-7208, or cs-rep@cisco.com.

Documentation CD-ROM

Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more up to date than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or http://www-europe.cisco.com.

If you are reading Cisco product documentation on the World Wide Web, you can submit comments electronically. Click Feedback in the toolbar, select Documentation, and click Enter the feedback form. After you complete the form, click Submit to send it to Cisco. We appreciate your comments.

Table of Contents

Release Notes for Cisco 7000 Family for Cisco IOS Release 11.3 T
