January 26, 1998
These release notes describe the features and caveats for Cisco IOS software on the Cisco AccessPath-TS3 Integrated Access System, up to and including Cisco IOS Release 11.2(10) P.
For additional information on the releases of software used on the Failsafe/Console Management Shelf and the Switch Shelf, refer to the documents referenced in "Related Documentation" and the document Release Notes for Cisco IOS Release 11.2(10). The electronic documentation can be found on Cisco Connection Online on the World Wide Web and on the Documentation CD-ROM. (Refer to the "Online Navigation" section for more details.)
Table 1 lists the AccessPath-TS3 system shelves and the version of the Cisco IOS software each is running. (The Switch Shelf does not run Cisco IOS software.) In order for the AccessPath-TS3 system to operate correctly, it must have the correct software.
| AccessPath-TS3 System Shelf | Cisco IOS Release Version |
|---|---|
| Failsafe/Console Management Shelf: Cisco 3640 | 11.2(10a) P |
| Access Server Shelf: AS5300s | 11.2(10a) P1 |
| Router Shelf: Cisco 7206s | 11.2(10a) P |
| Switch Shelf: Catalyst 5000 (AC or DC) or Catalyst 5002 (AC only) | 2.2(1)1 2.4(3) |
These release notes discuss the following topics:
Table 2 identifies the related software documents for each Cisco AccessPath-TS3 system shelf.
.
| Cisco Product | Documents |
|---|---|
| Failsafe/Console Management Shelf (Cisco 3640 Access Server) |
|
|
Access Server Shelf |
|
|
Router Shelf |
|
|
Switch Shelf |
|
For Cisco IOS Release 11.2, the Cisco IOS documentation set consists of eight modules, each module consisting of a configuration guide and a command reference. The documentation set also includes five supporting documents.
These documents are available as printed manuals or electronic documents.
You can access the electronic documents either on Cisco Connection Online (CCO) on the World Wide Web or on the Cisco Documentation CD-ROM.
On CCO, go to Software and Support and select Documentation. Next, select Documentation, click on Cisco IOS Software Configuration, and then select Cisco IOS Release 11.2. Or, the direct URL is: http://www.cisco.com/univercd/cc/td/doc/product/software/ios112/index.htm
On the Documentation CD-ROM, go to Cisco Product Documentation, select Cisco IOS Software Configuration, and then select Cisco IOS Release 11.2.
Online documentation for Release 11.2 includes:
For additional information about CCO and the Documentation CD-ROM, refer to the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of these release notes.
These guidelines are used during the preconfiguration process for the Cisco AccessPath-TS3 Integrated Access System. They should be taken into consideration during any subsequent reconfigurations of the AccessPath-TS3 system.
The Access Server Shelves and Router Shelves of the AccessPath-TS3 system use Cisco IOS Release 11.2(10a) P1 and 11.2(10a) P, respectively.
The Access Server Shelves support the following LAN and WAN interfaces:
The Access Server Shelves support the following modem cards:
The Router Shelves support the following LAN interfaces:
The Router Shelves support the following WAN interfaces:
The Router Shelves support the following WAN data rates:
There are no new features in the Access Server Shelves (Cisco AS5300) or Router Shelves (Cisco 7206) for Cisco IOS Release 11.2(10a) P and 11.2(10a) P1, respectively.
The Cisco IOS software is packaged into "feature sets" (also called "software images"). There are many different feature sets available, and each feature set contains a specific subset of Cisco IOS features.
The Cisco IOS Enterprise image is loaded on every shelf in the AccessPath-TS3 system, except on the Failsafe Console Management Shelf, which has the IP+ image on it. The AccessPath-TS3 system is shipped with IP configurations only; however, if you want a detailed list of all the features available with Enterprise, refer to the Cisco Product Catalog, CCO, or the Documentation CD-ROM. (Refer to the sections "Cisco Connection Online" and "Documentation CD-ROM" later in this document for details.)
This section describes fixes introduced in Release 11.2(10) P. For a list of serious problems that might affect the AccessPath-TS3 system, refer to the section "Release 11.2(10) P Caveats." For the complete list of caveats against Release 11.2, access CCO or use the Documentation CD-ROM as described in the section "Online Navigation."
| DDTS Number | Explanation |
|---|---|
| CSCdj10440 | On Access Server Shelves running Multichassis Multilink Point-to-Point Protocol (MMP), under heavy traffic, the Access Server Shelf might crash. This issue was resolved in Cisco IOS Release 11.2(09.01)P. |
| CSCdj14985, CSCdj26818 | When PPP dubugs are turned on, you might find messages of this type on the console:
This issue was resolved in Cisco IOS Release 11.2(09)XA. |
This section describes possibly unexpected behavior by Release 11.2(10). Unless otherwise noted, these caveats apply to all 11.2, 11.2 P, and 11.2 F releases up to and including 11.2(10). The caveats listed here describe only the serious problems. For the complete list of caveats against Release 11.2, use the Documentation CD-ROM or access CCO as described in the section "Online Navigation" earlier in this document.
When running Cisco IOS software on the AccessPath-TS3 system, keep the following caveats in mind. These caveats pertain specifically to AccessPath-TS3 system configurations:
Cisco Connection Online (CCO) is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional information and services.
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can access CCO in the following ways:
For a copy of CCO's Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more up to date than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or http://www-europe.cisco.com.
|
|
