Catalyst 5000 Series Fast Ethernet Switching Module (100BaseTX 12 Port) Configuration Note
Product Number: WS-X5113
This document contains instructions for installing and configuring the Catalyst 5000 series Fast Ethernet switching module (100BaseTX 12 port). Configuration examples are also provided. For a complete description of commands used to configure and maintain the Catalyst 5000 series switch, refer to the Catalyst 5000 Series Configuration Guide and Command Reference. For complete hardware configuration and maintenance procedures, refer to the Catalyst 5000 Series Installation Guide. These documents are available on the Cisco Connection Documentation, Enterprise Series CD, or in print.
Sections in this document include the following:
What is the Catalyst 5000 Series Switch?
The Catalyst 5000 series switch provides high-density switched Ethernet and Fast Ethernet for both wiring closet and data center applications. The switch includes a single, integrated 1.2-Gbps switching backplane that supports switched Ethernet with repeater connections, and Fast Ethernet with backbone connections, Fiber Distributed Data Interface (FDDI), Copper Distributed Data Interface (CDDI), and Asynchronous Transfer Mode (ATM). The Catalyst 5000 provides switched connections to individual workstations, servers, LAN segments, backbones, or other Catalyst 5000 switches using shielded twisted-pair (STP), unshielded twisted-pair (UTP), and fiber-optic cable. Figure 1 is an example of a configuration using the Catalyst 5000 series switch.
Figure 1 : Cascaded Switches Using Fast Ethernet Interfaces
The Catalyst 5000 series switch chassis has five slots. Slot 1 is reserved for the supervisor engine, which provides Layer 2 switching, local and remote management, and dual Fast Ethernet interfaces. The remaining four slots are used for any combination of modules for additional Ethernet, Fast Ethernet, CDDI/FDDI, and ATM connections. Figure 2 shows the rear view of the Catalyst 5000 series switch, which provides access to the supervisor engine, all switching modules, power supplies, and fan assembly.
Figure 2 : Catalyst 5000 Series Switch Chassis Rear View
Fast Ethernet Switching Module (100BaseTX 12 Port)
The Fast Ethernet switching module (100BaseTX 12 port), shown in Figure 3, provides connection to twelve, full- or half-duplex Fast Ethernet interfaces using RJ-45 female connectors.
Figure 3 : Fast Ethernet Switching Module (100BaseTX 12 Port)
LEDs provide status information for the module and individual Fast Ethernet interface connections. The LEDs are described in the section "Fast Ethernet Switching Module (100BaseTX 12-Port) LEDs."
Following are the Fast Ethernet switching module (100BaseTX 12 port) specifications:
Table 1 : Fast Ethernet Switching Module (100BaseTX 12 Port) Specifications
| Description | Specification |
|---|---|
| Dimensions (H x W x D) | 1.2 x 14.4 x 16 in (3 x 35.6 x 40.6 cm) |
| Weight | 3 lb (1.36 kg) |
| Environmental Conditions:
Operating temperature Nonoperating temperature Humidity |
32 to 104°F (0 to 40°C) -40 to 167°F (-40 to 75°C) 10 to 90%, noncondensing |
| Connectors | 12 RJ-45 IEEE 802.3 Fast Ethernet 100BaseTX |
| RAM buffer memory | 192 KB per interface |
| Maximum station-to-station cabling distance | Category 5 UTP1: 328' (100 meters)
100-Ohm shielded UTP: 328 feet (100 meters) |
| Frame processing | Transparent bridging (802.1d) |
| Network management | SNMP2 agent |
| Agency approvals:
Safety EMI3 |
UL4 1950, CSA5-C22.2 No. 950-93, and EN60950 FCC Class A (47 CFR, Part 15), CE Mark, EN55022 Class B and VCCI Class 2 with shielded UTP cables |
The five available interface slots on the Catalyst 5000 series switch support the supervisor engine and switching modules, providing a maximum port density of up to 50 switched Fast Ethernet interfaces. Slot 1 is reserved for the supervisor engine; slots 2 through 5 are used for any combination of Catalyst 5000 series switching modules.
Fast Ethernet Switching Module (100BaseTX 12-Port) LEDs
Each switching module contains a status LED. When on, this LED indicates that the switching module is powered up and operational. It does not necessarily mean that the interface ports are functional or enabled.
The LEDs on the faceplate of the Fast Ethernet switching module provide status information for the module and individual Fast Ethernet interface connections. The LEDs are described in Table 2.
Fast Ethernet Switching Module (100BaseTX 12 Port) LEDs
The LEDs on the faceplate of the Fast Ethernet switching module, shown in Figure 4, are described in Table 2.
Table 2 : Fast Ethernet Switching Module (100BaseTX 12 Port) LED Descriptions
| LED | Description |
|---|---|
| Status | The switch performs a series of self-tests and diagnostics.
If all the tests pass, the status LED will be green. If any test fails, it will be red (or orange for a minor fault). |
| 100 Mbps (top LED) | If the port is operating at 100 Mbps, the LED is green. |
| Link (bottom LED) | If the port is operational (a signal is detected), the LED is green.
If the link has been disabled by software, the LED is orange. If the link is bad and has been disabled due to a hardware failure, the LED flashes orange. If no signal is detected, the LED is off. |
Figure 4 : Fast Ethernet Switching Module (100BaseTX 12 Port) LEDs
When preparing your site for network connections to the switch, you need to consider a few factors related to each type of interface:
Before installing the switch, have all additional external equipment and cables on hand. If you intend to build your own cables, refer to the cable pinouts in the "Cabling Specifications" appendix in the Catalyst 5000 Series Installation Guide. For ordering information, contact a customer service representative.
The distance and rate limitations discussed in this section are the IEEE recommended maximum speeds and distances for signaling. If you understand the electrical problems that may arise and can compensate for them, you may get good results with rates and distances greater than those described here, but you do so at your own risk. The following distance limitations are provided as guidelines for planning your network connections before installation.
Ethernet and Fast Ethernet Connections
The maximum distances for Ethernet and Fast Ethernet network segments and connections depend on the type of transmission cable used, for example, unshielded twisted-pair.
The IEEE 100BaseTX standard recommends a maximum distance of 328 feet (100 meters) between station (connection) and hub for Fast Ethernet connections using category 5 UTP. See Table 3 for maximum cable distances.
Table 3 : Ethernet and Fast Ethernet Maximum Transmission Distances
| Transceiver Speed | Cable Type | Duplex Mode | Maximum Distance Between Stations |
|---|---|---|---|
| 10 Mbps | Category 3 UTP | Full & half | 328 feet (100 meters) |
| 10 Mbps | Multimode fiber | Full & half | 1.2 miles (2 km) |
| 100 Mbps | Category 5 UTP | Full & half | 328 feet (100 meters) |
| 100 Mbp | Multimode fiber | Full | 1.2 miles (2 km) |
| 100 Mbp | Multimode fiber | Half | 1,312 feet (400 meters) |
Fast Ethernet Connection Equipment
Use RJ-45 male connectors to connect to the Fast Ethernet network. (See Figure 5.)
Figure 5 : Fast Ethernet RJ-45 Interface Cable Connectors
Table 4 lists the signals for the Fast Ethernet switching module's port RJ-45 connector cable.
Table 4 : Fast Ethernet Switching Module 100BaseT RJ-45 Port Signals
| Pin | Signal | Direction | Description |
|---|---|---|---|
| 1 | RxD+ | <--- | Receive data + |
| 2 | RxD-- | <--- | Receive data -- |
| 3 | TxD+ | ---> | Transmit data + |
| 4 | NC | No connection | |
| 5 | NC | No connection | |
| 6 | TxD-- | ---> | Transmit data -- |
| 7 | NC | No connection | |
| 8 | NC | No connection |
The following guidelines will help to ensure your safety and protect the equipment. This list is not inclusive of all potentially hazardous situations that you may be exposed to when installing the switch, so be alert.
The supervisor engine, switching modules, and redundant power supplies are designed to be removed and replaced while the system is operating without presenting an electrical hazard or damage to the system. Before removing a redundant power supply, ensure that the primary supply is powered on. However, you must shut down the system before removing or replacing any of the replaceable components inside the front panel; for example, the backplane. Never install equipment that appears damaged.
Follow these basic guidelines when working with any electrical equipment:
In addition, use the following guidelines when working with any equipment that is disconnected from a power source but still connected to telephone wiring or other network cabling.
Preventing Electrostatic Discharge Damage
Electrostatic Discharge (ESD) damage occurs when electronic or components are improperly handled, resulting in complete or intermittent failures. The supervisor engine and switching modules each consist of a printed circuit board (PCB) fixed in a metal carrier. Electromagnetic interference (EMI) shielding, connectors, and a handle are integral components of the carrier. Although the metal carrier helps to protect modules from ESD, use a preventive antistatic strap whenever you handle the supervisor engine or switching modules. Handle the carriers by the handles and the carrier edges only, never touch the modules or connector pins.
Following are guidelines for preventing ESD damage:
Figure 6 : Placement of ESD Wrist Strap
Installing and Configuring Switching Modules
All switching modules support hot swapping, letting you install, remove, replace, and rearrange them without turning off the system power. When the system detects that a switching module has been installed or removed, it automatically runs diagnostic and discovery routines, acknowledges the presence or absence of the module, and resumes system operation without any operator intervention.
The hot-swap feature lets you remove and replace switching modules while the system is operating. You do not need to notify the software or shut down the system power. All switching modules support hot swapping.
The switching module contains a bus-type connector that connects to the backplane. Each connector consists of a set of tiered pins in two lengths. The pins send specific signals to the system as they make contact with the backplane. The system assesses the signals it receives and the order in which it receives them to determine what event is occurring and what task it needs to perform, such as reinitializing new interfaces or shutting down removed ones.
For example, when inserting the switching module, the longest pins make contact with the backplane first, and the shortest pins make contact last. The system recognizes the signals and the sequence in which it receives them. The system expects to receive signals from individual pins in this logical sequence.
When you remove or insert a switching module, the backplane pins send signals to notify the system, and performs as follows:
When you insert a new switching module, the system runs a diagnostic test on the new interfaces and compares them to the existing configuration. If this initial diagnostic fails, the system remains off line for another 15 seconds while it performs a second set of diagnostic tests to determine whether or not the switching module is faulty and if normal system operation is possible.
If the second diagnostic test passes, indicating that the system is operating normally and a new switching module is faulty, the system resumes normal operation but leaves the new interfaces disabled.
If the second diagnostic test fails, the system crashes, which usually indicates that the new supervisor engine or a switching module created a problem in the bus and should be removed.
Avoiding Problems When Inserting and Removing Switching Modules
The function of the ejector levers (see Figure 7) on the switching module is to align and seat the board connectors in the backplane. Failure to use the ejector levers and insert the switching module properly can disrupt the order in which the pins make contact with the backplane. Follow the installation and removal instructions carefully, and review the following examples of incorrect insertion practices and results:
It is also important to use the ejector levers when removing a switching module, ensuring that its connector pins disconnect from the backplane in the logical sequence expected by the system. A switching module partially connected to the backplane can hang the bus. Detailed steps for correctly performing a hot swap are included in the following procedures for installing and removing a switching module.
Figure 7 : Ejector Levers and Captive Installation Screws (Supervisor Engine Module Shown)
You need a flat-blade screwdriver to remove the switching module, and to tighten the captive installation screws that secure the engine in its slot. Whenever you handle the switching module, use a wrist strap or other grounding device to prevent ESD damage. See the section "Preventing Electrostatic Discharge Damage."
Take the following steps to remove a switching module:
You can install switching modules in any of the four switching module slots, numbered 2 through 5. (See Figure 8.) Slot 1 contains the supervisor engine---a required system component. Switching module fillers, blank switching module carriers, are installed in slots without switching modules to maintain consistent airflow through the switching module compartment.
Figure 8 : Module Slot Numbers
Following is the procedure for installing a switching module:
Figure 9 : Module Installation
Hot-Swapping Procedure Sample Screen Display
When you remove and replace switching modules, the system provides status messages on the console screen. The messages are for information only. In the following sample display, using the show system and show module commands, you can follow the events logged by the system when a switching module is removed from slot 2. When the show port command is used to query the module, the system reports notconnect. When the module is reinserted, the system marks the module as ok.
After you install the switching module, use the following information to configure the individual interfaces on the module.
Each interface in the Catalyst 5000 series switch is designated by several different types of addresses. The physical interface address is the actual physical location (slot and port) of the interface connector within the chassis. The system software uses the physical addresses to control activity within the switch and to display status information. These physical slot and port addresses are not used by other devices in the network. They are specific to the individual switch and its internal components and software.
A second type of address is the MAC or hardware address---a standard data link layer address required for every port or device connected to a network. Other devices in the network use these addresses to locate specific ports in the network, and to create and update routing tables and data structures. The Catalyst 5000 series switch uses a unique method to assign and control the MAC addresses of its interfaces.
The following sections describe how the Catalyst 5000 series switch assigns and controls both the physical and MAC addresses for interfaces within the chassis.
In the Catalyst 5000 series switch, physical port addresses specify the actual physical location of each port on the rear of the switch. (See Figure 10.) The address is composed of a two-part number in the format slot number/port number. The first number identifies the slot in which the switching module is installed. Module slots are numbered 1 to 5, from top to bottom. The second number identifies the physical port number on the switching module. The port numbers always begin at 1 and are numbered from the left port to right port when facing the rear of the switch. The number of additional ports (n/1, n/2, and so on) depends on the number of ports available on the module.
Interface ports maintain the same address regardless of whether other switching modules are installed or removed. However, when you move a switching module to a different slot, the first number in the address changes to reflect the new slot number. For example, on a 12-port 10/100BaseTX switching module in slot 2, the address of the left port is 2/1 and the address of the right port is 2/12. If you remove the 12-port 10/100Base TX switching module from slot 2 and install it in slot 4, the addresses of those same ports become 4/1 and 4/12.
Figure 10 : Interface Port Address Examples
The Fast Ethernet switching module supports up to 12 interfaces---n/1 through n/12. Switching modules are always n/1 to n/12 because each switching module supports at least twelve interfaces. (Switching modules with more than 12 interfaces are addressed /1 through /n.)
You can identify module interfaces by physically checking the slot/port location on the back of the switch. Software commands are used to display information about a specific interface in the switch. To display information about every interface, use the show port command without parameters. To display information about a specific interface, use the show port command with the interface type and port address in the format show port [mod_num/port_num]. If you abbreviate the command (sho po), and do not include parameters, the system interprets the command as show port and displays the status of all interfaces.
Following is an example of how the show port command without parameters displays status information (including the physical slot and port address) for each interface in the switch.
For descriptions of commands used to configure and maintain the Catalyst 5000 series switch, refer to the Catalyst 5000 Series Configuration Guide and Command Reference.
All network interface connections require a unique MAC address. The switch uses a MAC address allocator, stored in the supervisor engine's nonvolatile memory which identifies all system interface addresses. Each switch interface, configured or not, is allocated a MAC address. For instance, interface 2/10 is allocated a MAC address as a Fast Ethernet connection configured in slot 2, port 10; interface 2/11 is not configured but is also allocated an address. This addressing scheme is important, especially when hot-swapping modules, because it gives the switch the intelligence to identify the state---connected or notconnect---of each interface on the switch.
Configuring the Fast Ethernet Ports
This section describes how to use the privileged interface to configure the interfaces on the Fast Ethernet switching module.
To configure Fast Ethernet ports, complete the tasks in the following sections:
The supervisor engine provides the following default configuration. The default values can be changed to suit your network requirements.
Use the enable command to activate the switch's privileged mode. Administrative mode lets you invoke privileged commands that set the switching module's interface features, such as enabling an interface and showing the current configuration. The designation (enable) indicates that the system is in privileged mode and privileged commands can be invoked.
Example
The following example shows how to enter privileged mode:
Assign a name to each port. To set a port name, perform the following tasks in privileged mode:
Figure 11 : set port name Command Example
Figure 12 : Sample show port Command Display
Configure the priority level of each port. When ports request simultaneous access to the switching bus, the switch uses the port priority level to determine the order in which ports access the bus. To set the priority level, perform the following tasks in privileged mode:
Figure 13 : set port level Command Example
Set the transmission type to full- or half-duplex for the ports to be used. To set the transmission type, perform the following tasks in privileged mode:
Figure 14 : set port duplex Command Example
VLANs allow ports on the same or different switches to be grouped so that traffic is confined to members of that group only. This feature restricts unicast, broadcast, and multicast traffic (flooding) to ports included in the same VLAN.
The set vlan command groups ports. The default configuration has all switched Ethernet ports and Ethernet repeater ports in VLAN 1. You can enter groups of ports as individual entries, such as 2/1,3/3,3/4,3/5. You can also use a hyphenated format to indicate a range of ports, such as 2/1, 3/3-5.
To create a VLAN, perform the following tasks in privileged mode:
Figure 15 : set vlan Command Example
Figure 16 : VLAN Configuration
Figure 17 : Sample show vlan Command Display
Use the set trunk command to configure trunks on ports, and to configure the mode for the trunk: on, off, desirable, or auto. To establish a trunk, the port on each Catalyst 5000 series switch must be configured as a trunk port. To establish trunks, perform the following steps in privileged mode:
Figure 18 : set trunk Command Example
Figure 19 : show trunk Command Display Sample
This section describes procedures uses to confirm that your Fast Ethernet switching module (100BaseTX 12 port) is installed and configured correctly.
Use the ping command to send Internet Control Message Protocol (ICMP) echo request packets to another node on the network. Enter Ctrl-C to stop pinging.
Syntax Description
Following are sample results of the ping command:
Example
In the following example, a host with the IP alias, elvis, is pinged a single time, then pinged once every second until you enter Ctrl C to stop pinging:
Use the show system command to display the power supply, fan, temperature alarm, system, and modem status; the number of days, hours, minutes, and seconds since the last system restart; the baud rate; the MAC address range; and the system name, location, and contact.
Example
In the following example, the system status and other information is displayed:
Displaying the System Configuration
Use the show config command to display the current port configuration:
Displaying the Port Configuration
Use the show port command to display the current system configuration:
Copyright 1988-1996 © Cisco Systems Inc.
Console> (enable) show system
PS1-Status PS2-Status Fan-Status Temp-Alarm Sys-Status Uptime d,h:m:s Logout
---------- ---------- ---------- ---------- ---------- -------------- ---------
ok none ok off ok 0,00:21:41 none
PS1-Type PS2-Type Modem Baud Traffic Peak Peak-Time
---------- ---------- ------- ----- ------- ---- -------------------------
WS-C5113 none disable 9600 0% 0% Tue May 14 1996, 14:37:31
System Name System Location System Contact
------------------------ ------------------------ ------------------------
Console> (enable)
Console> (enable) show module
Mod Module-Name Ports Module-Type Model Serial-Num Status
--- -------------------- ----- --------------------- -------- --------- -------
1 2 100BaseTX Supervisor WS-X5009 002650014 ok
2 10 100BaseTX Fast Eth WS-X5113 002475046 ok
4 48 4 Segment 10BaseT Eth WS-X5020 001336146 ok
Mod MAC-Address(es) Hw Fw Sw
--- ---------------------------------------- ------ ------ ----------------
1 00-40-0b-ac-80-00 thru 00-40-0b-ac-83-ff 1.81 1.5 2.1
2 00-40-0b-4c-92-58 thru 00-40-0b-4c-92-6f 1.0 1.4 2.1
4 00-40-0b-ff-00-00 thru 00-40-0b-ff-00-03 0.2 2.1(1) 2.1
Console> (enable)
Console> (enable) show port 2/10
Port Name Status Vlan Level Duplex Speed Type
---- -------------------- ---------- ---------- ------ ------ ----- -----------
2/10 connected 1 normal half 10 10BaseT
Port Align-Err FCS-Err Xmit-Err Rcv-Err
---- ---------- ---------- ---------- ----------
2/10 0 0 0 0
Port Single-Col Multi-Coll Late-Coll Excess-Col Carri-Sens Runts Giants
---- ---------- ---------- ---------- ---------- ---------- --------- ---------
2/10 0 0 0 0 0 0 0
Last-Time-Cleared
--------------------------
Tue May 14 1996, 14:37:31
Console> (enable)
Console> (enable) show port
Port Name Status Vlan Level Duplex Speed Type
---- -------------------- ---------- ---------- ------ ------ ----- -----------
1/1 Management Port connected 1 normal half 100 100BaseTX
1/2 InterSwitch Link connected trunk normal half 100 100BaseTX
2/1 100BaseTX Fast Eth connected 1 normal half 100 100BaseTX
2/2 100BaseTX Fast Eth connected 1 normal half 100 100BaseTX
2/3 100BaseTX Fast Eth connected 1 normal half 100 100BaseTX
2/4 100BaseTX Fast Eth connected 1 normal half 100 100BaseTX
2/5 100BaseTX Fast Eth connected 1 normal half 100 100BaseTX.
.
.
.
4/45 notconnect 1 normal half 10 10BaseT
4/46 notconnect 1 normal half 10 10BaseT
4/47 notconnect 1 normal half 10 10BaseT
Port Align-Err FCS-Err Xmit-Err Rcv-Err
---- ---------- ---------- ---------- ----------
1/1 0 0 0 0
1/2 0 0 0 0
2/1 0 0 0 0
2/2 0 0 0 0
2/3 0 0 0 0
.
.
.
2/18 0 0 0 0
2/19 0 0 0 0
2/20 0 0 0 0
2/21 0 0 0 0
2/22 0 0 0 0
2/23 0 0 0 0
2/24 0 0 0 0TT
Port Auto-Parts Giants Data-Rate FCS-Err Runts Rcv-frms Src-Addr
Mismatch Changes
---- ---------- ---------- ---------- ---------- ---------- ---------- --------
4/1 0 0 0 0 0 0 0
4/2 0 0 0 0 0 0 0
4/3 0 0 0 0 0 0 0
4/4 0 0 0 0 0 0 0
4/5 0 0 0 0 0 0 0
4/6 0 0 0 0 0 0 0
.
.
.
4/43 0 0 0 0 0 0 0
4/44 0 0 0 0 0 0 0
4/45 0 0 0 0 0 0 0
4/46 0 0 0 0 0 0 0
4/47 0 0 0 0 0 0 0
4/48 0 0 0 0 0 0 0
Port Rcv-Multi Rcv-Broad Good-Bytes Align-Err Short-Evnt Late-Coll Collision
---- ---------- ---------- ---------- ---------- ---------- --------- ---------
4/1 0 0 0 0 0 0 0
4/2 0 0 0 0 0 0 0
4/3 0 0 0 0 0 0 0
4/4 0 0 0 0 0 0 0
.
.
.
4/42 0 0 0 0 0 0 0
4/43 0 0 0 0 0 0 0
4/44 0 0 0 0 0 0 0
4/45 0 0 0 0 0 0 0
4/46 0 0 0 0 0 0 0
4/47 0 0 0 0 0 0 0
4/48 0 0 0 0 0 0 0
Last-Time-Cleared
--------------------------
Tue May 14 1996, 14:37:31
Console> (enable)
Console>
Console> enable
Enter password:
Console> (enable)
Task
Command
Configure a name for a port. Figure 11 shows an example
set port name command.
set port name mod_num/port_num [name_string]
Verify that the port name is correct. Figure 12 shows an example show port command. Port names are listed in the Name column.
show port mod_num/port_num
Console> (enable) set port name 1/1 Management Port
Port 1/1 name set.
Console> (enable) set port name 1/2 InterSwitch Link
Port 1/2 name set.
Console> (enable)
Console> (enable) show port
Port Name Status Vlan Level Duplex Speed Type
---- -------------------- ---------- ---------- ------ ------ ----- -----------
1/1 Management Port connected 1 normal half 100 100BaseTX
1/2 InterSwitch Link connected trunk normal half 100 100BaseTX
2/1 100BaseTX Fast Eth connected 1 normal half 100 100BaseTX
2/2 100BaseTX Fast Eth connected 1 normal half 100 100BaseTX
2/3 100BaseTX Fast Eth connected 1 normal half 100 100BaseTX
2/4 100BaseTX Fast Eth connected 1 normal half 100 100BaseTX
2/5 100BaseTX Fast Eth connected 1 normal half 100 100BaseTX.
.
.
4/45 notconnect 1 normal half 10 10BaseT
4/46 notconnect 1 normal half 10 10BaseT
4/47 notconnect 1 normal half 10 10BaseT
Port Align-Err FCS-Err Xmit-Err Rcv-Err
---- ---------- ---------- ---------- ----------
1/1 0 0 0 0
1/2 0 0 0 0
2/1 0 0 0 0
2/2 0 0 0 0
2/3 0 0 0 0
.
.
.
2/18 0 0 0 0
2/19 0 0 0 0
2/20 0 0 0 0
2/21 0 0 0 0
2/22 0 0 0 0
2/23 0 0 0 0
2/24 0 0 0 0TT
Port Auto-Parts Giants Data-Rate FCS-Err Runts Rcv-frms Src-Addr
Mismatch Changes
---- ---------- ---------- ---------- ---------- ---------- ---------- --------
4/1 0 0 0 0 0 0 0
4/2 0 0 0 0 0 0 0
4/3 0 0 0 0 0 0 0
4/4 0 0 0 0 0 0 0
4/5 0 0 0 0 0 0 0
4/6 0 0 0 0 0 0 0
.
.
.
4/43 0 0 0 0 0 0 0
4/44 0 0 0 0 0 0 0
4/45 0 0 0 0 0 0 0
4/46 0 0 0 0 0 0 0
4/47 0 0 0 0 0 0 0
4/48 0 0 0 0 0 0 0
Port Rcv-Multi Rcv-Broad Good-Bytes Align-Err Short-Evnt Late-Coll Collision
---- ---------- ---------- ---------- ---------- ---------- --------- ---------
4/1 0 0 0 0 0 0 0
4/2 0 0 0 0 0 0 0
4/3 0 0 0 0 0 0 0
4/4 0 0 0 0 0 0 0
.
.
.
4/42 0 0 0 0 0 0 0
4/43 0 0 0 0 0 0 0
4/44 0 0 0 0 0 0 0
4/45 0 0 0 0 0 0 0
4/46 0 0 0 0 0 0 0
4/47 0 0 0 0 0 0 0
4/48 0 0 0 0 0 0 0
Last-Time-Cleared
--------------------------
Tue May 14 1996, 14:37:31
Console> (enable)
Task
Command
Configure the priority level for each port. Figure 13 shows an example set port level command.
set port level mod_num/port_num normal | high
Verify that the port priority level is correct. Figure 12 shows an example show port command. Port priority levels are listed in the Level column.
show port mod_num/port_num
Console> (enable) set port level 1/1-2 high
Ports 1/1-2 port level set to high.
Console> (enable)
Task
Command
Enter the module number, port number, and transmission type of each port to be used. Figure 14 shows an example set port duplex command.
set port duplex mod num/port num [full | half]
Verify that the transmission type is set correctly. Figure 12 shows an example
show port command. The transmission type is listed in the Duplex column.
show port mod_num/port_num
Console> (enable) set port duplex 1/1 half
Port 1/1 set to half-duplex.
Console> (enable) set port duplex 1/2 half
Port 1/2 set to half-duplex.
Console> (enable)
Task
Command
Define the VLAN and indicate the ports to be included. Figure 15 shows an example of the set vlan command. Figure 16 shows a diagram of the established VLANs. VLAN 10, in the engineering department, includes module 2, ports 1 through 4. VLAN 20, in the accounting department, includes module 2, ports 5 through 24. The accounting and engineering departments are isolated from each other in this configuration.
set vlan vlan mod/ports
Verify that the VLAN configuration is correct. Figure 17 shows an example show vlan command.
show vlan
Console> (enable) set vlan 10 2/1-4
VLAN 10 modified.
VLAN 1 modified.
VLAN Mod/Ports
10 2/1-4
Console> (enable) set vlan 20 2/5-24
VLAN 20 modified.
VLAN 1 modified.
VLAN Mod/Ports
20 2/5-24
Console> (enable)
Console> (enable) show vlan
VLAN Mod/Ports
---- ------------------------------------------------------
1 1/1-2
10 2/1-4
20 2/5-24
Console> (enable)
Task
Command
Establish trunks on specific ports. Set the trunk to on to make it a trunk port, off to make it a non-trunk port, desirable to make it a trunk port if the port it is connected to allows trunking, or auto to make it a trunk port if the port it is connected to becomes set for trunking. Figure 18 shows an example of the set trunk command. Port 1 on module 1 is configured as a trunk.
set trunk mod_num/port_num
[ on | off | desirable | auto ] [vlans]
Verify that the trunk configuration is correct. Figure 19 shows a sample display of the
show trunk command.
show trunk
Console> (enable) set trunk 1/2 5
Port 1/2 allowed vlans modified to 1-5.
Console> (enable) set trunk 1/1 desirable
Port 1/1 mode set to desirable.
Port 1/1 has become a trunk.
Console> (enable)
Console> (enable) show trunk
Port Mode Status
------- --------- ------------
1/1 auto trunking
1/2 auto not-trunking
Port Vlans allowed
------- ---------------------------------------------------------------------
1/1 1-1000
1/2 1-1000
Port Vlans active
------- ---------------------------------------------------------------------
1/1 1-3,5
1/2 1
Console> (enable)
-s
Causes ping to send one datagram every second, printing one line of output for every response received. The ping command does not return any output when no response is received.
host
The IP address or IP alias of the host.
packet_size
(Optional) The number of bytes in a packet, from 1 to 2000 bytes with a default of 56 bytes. The actual packet size is eight bytes larger because the switch adds header information.
packet_count
(Optional) The number of packets to send
Console> ping elvis
elvis is alive
Console> (enable) ping -s elvis
ping elvis: 56 data bytes
64 bytes from elvis: icmp_seq=0. time=11 ms
64 bytes from elvis: icmp_seq=1. time=8 ms
64 bytes from elvis: icmp_seq=2. time=8 ms
64 bytes from elvis: icmp_seq=3. time=7 ms
64 bytes from elvis: icmp_seq=4. time=11 ms
64 bytes from elvis: icmp_seq=5. time=7 ms
64 bytes from elvis: icmp_seq=6. time=7 ms
^C
----elvis PING Statistics----
7 packets transmitted, 7 packets received, 0% packet loss
round-trip (ms) min/avg/max = 7/8/11
Console> (enable)
Console> (enable) show system
PS1-Status PS2-Status Fan-Status Temp-Alarm Sys-Status Uptime d,h:m:s Logout
---------- ---------- ---------- ---------- ---------- -------------- ---------
ok none ok off ok 1,20:53:07 none
PS1-Type PS2-Type Modem Baud Traffic Peak Peak-Time
---------- ---------- ------- ----- ------- ---- -------------------------
WS-C5008 none disable 9600 0% 1% Thu May 16 1996, 10:06:22
System Name System Location System Contact
------------------------ ------------------------ ------------------------
Console> (enable)
Console> (enable) show config
begin
set password $1$FMFQ$HfZR5DUszVHIRhrz4h6V70
set enablepass $1$FMFQ$HfZR5DUszVHIRhrz4h6V70
set prompt Console>
set length 100 default
set logout 0
!
#system
set system baud 9600
set system modem disable
set system name
set system location
set system contact
!
#snmp
set snmp community read-only public
set snmp community read-write private
set snmp community read-write-all secret
set snmp rmon enable
set snmp trap disable module
set snmp trap disable chassis
set snmp trap disable bridge
set snmp trap disable repeater
set snmp trap disable vtp
set snmp trap disable auth
!
#ip
set interface sc0 1 172.20.25.130 255.255.0.0 172.20.255.255
set interface sl0 0.0.0.0 0.0.0.0
set arp agingtime 1200
set ip redirect enable
set ip unreachable disable
set ip fragmentation enable
set ip route 0.0.0.0 172.20.1.201 1
set ip alias default 0.0.0.0
set ip alias max 171.69.193.165
set ip alias atlas 172.20.1.201
set ip alias cat7-lnf 172.20.25.130
set ip alias cat9-lnf 172.20.25.132
set ip alias da_bears 172.20.22.7
set ip alias lnf 172.20.0.0
!
!
#vlan
set vlan 1 1/2,2/1-24,4/1,4/13,4/25,4/37
!
#trunks
set trunk 1/1 desirable 1-1000
set trunk 1/2 off 1-1000
.
.
.
#vlan 2
set spantree enable 2
set spantree fwddelay 15 2
set spantree hello 2 2
set spantree maxage 20 2
set spantree priority 32768 2end
!
#trunk
set spantree portcost 1/1 10
set spantree portpri 1/1 32
set spantree portvlanpri 1/1 0 100-102
set spantree portfast 1/1 disable
set spantree portcost 1/2 10
set spantree portpri 1/2 32
set spantree portvlanpri 1/2 0
set spantree portfast 1/2 disable
!
#module 1
set module name 1
set port enable 1/1-2
set port level 1/1-2 normal
set port duplex 1/1-2 half
set port trap 1/1-2 disable
set port name 1/1 Management Port
set port name 1/2 InterSwitch Link
!
#module 2
set module name 2
set module enable 2
set port enable 2/1-24
set port level 2/1-24 normal
set port duplex 2/1-24 half
set port trap 2/1-24 disable
set port name 2/1-24
!
#module 3 empty
!
#module 4
set module name 4
set module enable 4
set port enable 4/1-48
set port level 4/1,4/13,4/25,4/37 normal
set port trap 4/1-48 disable
set port name 4/1-48
!
#module 5 empty
!
#switch port analyzer
set span 1 1/1 both
set span disable
end
Console> (enable)
Console> (enable) show port
Port Name Status Vlan Level Duplex Speed Type
---- -------------------- ---------- ---------- ------ ------ ----- -----------
1/1 Management Port connected 1 normal half 100 100BaseTX
1/2 InterSwitch Link connected trunk normal half 100 100BaseTX
2/1 100BaseTX Fast Eth connected 1 normal half 100 100BaseTX
2/2 100BaseTX Fast Eth connected 1 normal half 100 100BaseTX
2/3 100BaseTX Fast Eth connected 1 normal half 100 100BaseTX
2/4 100BaseTX Fast Eth connected 1 normal half 100 100BaseTX
2/5 100BaseTX Fast Eth connected 1 normal half 100 100BaseTX.
.
.
4/45 notconnect 1 normal half 10 10BaseT
4/46 notconnect 1 normal half 10 10BaseT
4/47 notconnect 1 normal half 10 10BaseT
Port Align-Err FCS-Err Xmit-Err Rcv-Err
---- ---------- ---------- ---------- ----------
1/1 0 0 0 0
1/2 0 0 0 0
2/1 0 0 0 0
2/2 0 0 0 0
2/3 0 0 0 0
.
.
.
2/18 0 0 0 0
2/19 0 0 0 0
2/20 0 0 0 0
2/21 0 0 0 0
2/22 0 0 0 0
2/23 0 0 0 0
2/24 0 0 0 0TT
Port Auto-Parts Giants Data-Rate FCS-Err Runts Rcv-frms Src-Addr
Mismatch Changes
---- ---------- ---------- ---------- ---------- ---------- ---------- --------
4/1 0 0 0 0 0 0 0
4/2 0 0 0 0 0 0 0
4/3 0 0 0 0 0 0 0
4/4 0 0 0 0 0 0 0
4/5 0 0 0 0 0 0 0
4/6 0 0 0 0 0 0 0
.
.
.
4/43 0 0 0 0 0 0 0
4/44 0 0 0 0 0 0 0
4/45 0 0 0 0 0 0 0
4/46 0 0 0 0 0 0 0
4/47 0 0 0 0 0 0 0
4/48 0 0 0 0 0 0 0
Port Rcv-Multi Rcv-Broad Good-Bytes Align-Err Short-Evnt Late-Coll Collision
---- ---------- ---------- ---------- ---------- ---------- --------- ---------
4/1 0 0 0 0 0 0 0
4/2 0 0 0 0 0 0 0
4/3 0 0 0 0 0 0 0
4/4 0 0 0 0 0 0 0
.
.
.
4/42 0 0 0 0 0 0 0
4/43 0 0 0 0 0 0 0
4/44 0 0 0 0 0 0 0
4/45 0 0 0 0 0 0 0
4/46 0 0 0 0 0 0 0
4/47 0 0 0 0 0 0 0
4/48 0 0 0 0 0 0 0
Last-Time-Cleared
--------------------------
Tue May 14 1996, 14:37:31
Console> (enable)
