Addendum to CiscoWorks Installation and Reference on SunOS, Solaris, and HP-UX

Addendum to CiscoWorks Installation and Reference on SunOS, Solaris, and HP-UX

Addendum to CiscoWorks Installation and Reference on SunOS, Solaris, and HP-UX

This addendum is intended for users of CiscoWorks 3.0 on SunOS who want to move to CiscoWorks 3.0 on Solaris and also want to migrate their existing SunOS CiscoWorks 3.0 to their new Solaris installation.

This addendum only explains the steps necessary to migrate your existing SunOS CiscoWorks 3.0 data to Solaris. Refer to the appropriate Solaris or CiscoWorks installation guides for instructions on installing Solaris or CiscoWorks.

The shell script on the CiscoWorks 3.0 CD can perform most of the steps described in this addendum. Each step of the migration procedure is explained below, and it is indicated if the shell-script can do the step for you.

There are four stages in migrating from SunOS CiscoWorks 3.0 to Solaris CiscoWorks 3.0:

  1. On the SunOS machine on which you currently run CiscoWorks 3.0, create a new directory and dump all the necessary data into files in this new directory, as explained in the section "Saving your SunOS CiscoWorks 3.0 data (Migration Stage 1)."

  2. Move this entire directory to the Solaris machine on which you are going to install CiscoWorks 3.0. If this is the same machine on which you are currently running SunOS, you should have your system administrator backup this directory before installing Solaris and then restore it after Solaris has been installed.

  3. Install CiscoWorks 3.0 on your Solaris machine, as described in the CiscoWorks Installation and Reference publication. If you have added any user Sybase accounts (either with isql or a CiscoWorks application) to your SunOS CiscoWorks 3.0 installation, you must recreate them on your Solaris CiscoWorks 3.0 installation. Follow the same procedure you used originally to create the accounts on SunOS Sybase. However, you must recreate them in the Solaris Sybase database before restoring the data saved from SunOS CiscoWorks.

  4. On the Solaris machine, move to the directory that contains all the data dumped from the SunOS installation, and load it into Solaris CiscoWorks 3.0, as explained in the section "Restoring your saved data on the Solaris machine (Migration Stage 4 )."

Most of the CiscoWorks data is stored in Sybase tables, but there are also a few standard UNIX files you may wish to retain. The procedures below provide the details of stages 1 and 4 by describing how to save and restore all the CiscoWorks-created Sybase tables as well as relevant standard UNIX files.

Stages 2 and 3 are not discussed further in this addendum. If you added any user-created tables to your SunOS Sybase database (for polling data) and wish to retain that data on Solaris, follow the same steps for each user-created Sybase table as described below for the standard CiscoWorks-created Sybase tables.

Note Each command that you must enter is preceeded by a "#" sign.


Saving your SunOS CiscoWorks 3.0 data (Migration Stage 1)

To save your SunOS CiscoWorks 3.0 data, perform the following steps:

Step 1 Log into your SunOS machine as root (you must be root to save the non-Sybase data) and start a C-shell (/bin/csh) if you are not already running one. Make sure the environmental variable NMSROOT is set correctly, and that $NMSROOT/bin is at the front of your PATH environmental variable. (Refer to the CiscoWorks Installation and Reference publication.)

If you want to use the commands below exactly as shown, you need to set the environmental variable sa_password to the password of your Sybase sa account:
        # setenv sa_password YOUR_PASSWORD

Otherwise, use your Sybase sa password wherever $sa_password appears below.

Step 2 Make a directory for the data files you are about to create, and change to that directory.
        # mkdir /tmp/bcp_data
# cd /tmp/bcp_data

This directory needs to be in a partition large enough to hold your exported database. If there is enough room to do a Sybase "dump" command to that partition, you should be fine.

To run the commands exactly as shown below, you need to set the environmental variable saved to the directory you just created:
        # setenv saved /tmp/bcp_data

Step 3 If you want to use the shell-script provided on the CiscoWorks 3.0 CD, proceed to Step 4. Otherwise, individually extract each Cisco-created database table into an external file using the bcp command, as shown below:
        bcp table_name out table_name.dat -c -t "\t" -Usa -P$sa_password

table_name is the name of the table to be dumped.

To save typing the entire bcp command, you can create an alias as shown in the following example:
        # alias bcp 'bcp \!^ out \!^.dat -c -t "\t" -Usa -P$sa_password'

Then use this aliased bcp command on each table as follows:
# bcp polldb.nmsuper.polls
# bcp polldb.nmsuper.polls_config
# bcp polldb.nmsuper.tables out
# bcp polldb.nmsuper.columns
# bcp polldb.nmsuper.summaryinfo
# bcp polldb.nmsuper.grouptemplate
# bcp polldb.nmsuper.polls
# bcp polldb.nmsuper.attr
# bcp polldb.nmsuper.action

# bcp polldb.nmsuper.start_stop
# bcp polldb.nmsuper.pollers
# bcp polldb.nmsuper.msglog
# bcp polldb.nmsuper.filterlog
# bcp polldb.nmsuper.applog
# bcp polldb.nmsuper.ciscolog
# bcp polldb.nmsuper.sample
# bcp polldb.nmsuper.sample_error
# bcp polldb.nmsuper.sample_load
# bcp polldb.nmsuper.sample_traffic
# bcp polldb.nmsuper.sample_mix
# bcp nms.cisco_connect.cisco_connect_users
# bcp nms.SAnms.applications
# bcp nms.SAnms.app_bits
# bcp nms.nmsuper.auto_install
# bcp nms.nmsuper.sw_inventory
# bcp nms.SAnms.logins
# bcp nms.SAnms.groups
# bcp nms.SAnms.users
# bcp nms.SAnms.group_users
# bcp nms.SAnms.group_domains
# bcp nms.nmsuper.gcmds_domains
# bcp nms.nmsuper.gcmds
# bcp nms.nmsuper.domains_devices
# bcp nms.nmsuper.domains
# bcp nms.nmsuper.summaryinfo
# bcp nms.nmsuper.DevConfigs
# bcp nms.nmsuper.DevConfHist
# bcp nms.nmsuper.DevConfFileLoc
# bcp nms.nmsuper.interfaces
# bcp nms.nmsuper.devices
# bcp nms.nmsuper.crons
# bcp nms.nmsuper.if_addresses
# bcp nms.nmsuper.locations
# bcp nms.nmsuper.admins
# bcp nms.nmsuper.vendors
# bcp nms.nmsuper.people
# bcp nms.nmsuper.phones
# bcp nms.nmsuper.contacts
# bcp nms.nmsuper.admin_contacts
# bcp nms.nmsuper.vendor_contacts
# bcp nms.nmsuper.line_contacts
# bcp nms.nmsuper.lines
# bcp nms.nmsuper.networks
# bcp nms.nmsuper.net_numbers
# bcp nms.nmsuper.device_types
# bcp nms.nmsuper.interface_types
# bcp nms.nmsuper.protocol_types
# bcp nms.nmsuper.line_types
# bcp nms.SAnms.permissions
# bcp nms.nmsuper.net_types
# bcp nms.nmsuper.procinfo
# bcp nms.nmsuper.SysFiles
# bcp nms.dbo.SystemEvents
# bcp nms.dbo.DumpDevices
# bcp nms.nmsuper.pccmdset
# bcp nms.nmsuper.pcdevset

If you created any user-defined poll group tables and wish to save the data in them, repeat the bcp command for each table:
        bcp polldb.nmsuper.CREATED_TABLENAME

Proceed to Step 5.

Step 4 If you do want to use the supplied shell-script to save your Sybase tables instead of typing all the commands shown in Step 3, mount your CiscoWorks 3.0 CD and copy the file /CISCOWORKS/Migrate/copy_tables into your current working directory (which should be the $saved directory you are using to hold the saved data). Refer to the CiscoWorks Installation and Reference publication for instructions on mounting and copying from the CD-ROM.

As supplied, the copy_tables script works only if you have not created any user-defined poll group tables. If you created any such tables, edit the script before running it.

If you created user-defined poll groups, but you do not want to save the data in them, edit the copy_tables script to remove the following line from the list of tables:
polldb.nmsuper.polls

The list of tables looks like this:
TABLES="polldb.nmsuper.polls_config
polldb.nmsuper.tables
polldb.nmsuper.columns
polldb.nmsuper.summaryinfo
polldb.nmsuper.grouptemplate
polldb.nmsuper.polls
...

If you have created user defined poll groups, and you do want to save the data in them, edit the copy_tables script to add a line naming each of your user-defined poll groups to the end of the list of tables, as shown below:
TABLES="polldb.nmsuper.polls_config
polldb.nmsuper.tables
polldb.nmsuper.columns
polldb.nmsuper.summaryinfo
polldb.nmsuper.grouptemplate
polldb.nmsuper.polls
...
polldb.nmsuper.my_first_poll_group
polldb.nmsuper.my_second_poll_group

Make sure the copy_tables script is executable, and then run the following commands:
        # chmod +x copy_tables
# ./copy_tables out $sa_password $cwd

Step 5 After saving all your Sybase tables, you can also save certain information contained in standard UNIX files. To save your CiscoConnect history, enter the following commands:
        # cd $NMSROOT/lib/httpd/conf
# tar cvf $saved/cc-conf.tar *Profile.conf
# cd $NMSROOT/lib/httpd
# tar cvf $saved/cc-query.tar etc/*.dat htdocs/Cisco*/CaseQueryReply.shtml

To save your TACACS information, enter the following commands:
        # cd /etc
# tar cvf $saved/tacacs.tar tac*

To migrate your crontab entries, enter the following command:
        # crontab -l $saved/cronfile


Restoring your Saved Data on the Solaris Machine (Migration Stage 4 )

To restore your saved data on the Solaris machine, perform the following steps:

Step 1 Log into your Solaris machine as root (you must be root to restore the non-Sybase data) and start a C-shell (/bin/csh) if you are not already running one. Make sure the environmental variable $NMSROOT is set correctly (default is /opt/CSCOcw). Source the $NMSROOT/etc/install.cshrc as shown below:
        # source $NMSROOT/etc/install.cshrc
Note If install.cshrc has been moved to another directory, find it and issue the appropriately modified source statement.

If you want to use the commands below exactly as shown, you need to set the environmental variable sa_password to the password of your Sybase sa account:
        # setenv sa_password YOUR_PASSWORD

Otherwise, just use your Sybase sa password wherever $sa_password appears below.

Step 2 To run the commands exactly as shown below, you need to set the environmental variable saved to the directory containing your data files saved from your SunOS CiscoWorks adn then change to this directory:
        # setenv saved /tmp/bcp_data
# cd $saved

Step 3 Log in to isql as sa, set the bulkcopy option, and checkpoint your database:
        # isql -Usa -P$sa_password
# sp_dboption nms, "select into/bulkcopy", true
# go
# use nms
# go
# checkpoint
# go
# quit

Step 4 If you are using the copy_tables script (that is, you performed Step 4 on SunOS), proceed to Step 5. Otherwise, log into isql as sa, truncate the following standard CiscoWorks tables, and exit isql.
Note It is advisable to enter a go command after every truncate; otherwise, if you mistype a table-name you will have to retype the entire list.
# isql -Usa -P$sa_password
# truncate table polldb.nmsuper.polls_config
# truncate table polldb.nmsuper.tables
# truncate table polldb.nmsuper.columns
# truncate table polldb.nmsuper.summaryinfo
# truncate table polldb.nmsuper.grouptemplate
# truncate table polldb.nmsuper.attr
# truncate table polldb.nmsuper.action
# truncate table polldb.nmsuper.start_stop

# truncate table polldb.nmsuper.pollers
# truncate table polldb.nmsuper.msglog
# truncate table polldb.nmsuper.filterlog
# truncate table polldb.nmsuper.applog
# truncate table polldb.nmsuper.ciscolog
# truncate table polldb.nmsuper.sample
# truncate table polldb.nmsuper.sample_error
# truncate table polldb.nmsuper.sample_load
# truncate table polldb.nmsuper.sample_traffic
# truncate table polldb.nmsuper.sample_mix
# truncate table nms.cisco_connect.cisco_connect_users
# truncate table nms.SAnms.applications
# truncate table nms.SAnms.app_bits
# truncate table nms.nmsuper.auto_install
# truncate table nms.nmsuper.sw_inventory
# truncate table nms.SAnms.logins
# truncate table nms.SAnms.groups
# truncate table nms.SAnms.users
# truncate table nms.SAnms.group_users
# truncate table nms.SAnms.group_domains
# truncate table nms.nmsuper.gcmds_domains
# truncate table nms.nmsuper.gcmds
# truncate table nms.nmsuper.domains_devices
# truncate table nms.nmsuper.domains
# truncate table nms.nmsuper.summaryinfo
# truncate table nms.nmsuper.DevConfigs
# truncate table nms.nmsuper.DevConfHist
# truncate table nms.nmsuper.DevConfFileLoc
# truncate table nms.nmsuper.interfaces
# truncate table nms.nmsuper.devices
# truncate table nms.nmsuper.crons
# truncate table nms.nmsuper.if_addresses
# truncate table nms.nmsuper.locations
# truncate table nms.nmsuper.admins
# truncate table nms.nmsuper.vendors
# truncate table nms.nmsuper.people
# truncate table nms.nmsuper.phones
# truncate table nms.nmsuper.contacts
# truncate table nms.nmsuper.admin_contacts
# truncate table nms.nmsuper.vendor_contacts
# truncate table nms.nmsuper.line_contacts
# truncate table nms.nmsuper.lines
# truncate table nms.nmsuper.networks
# truncate table nms.nmsuper.net_numbers
# truncate table nms.nmsuper.device_types
# truncate table nms.nmsuper.interface_types
# truncate table nms.nmsuper.protocol_types
# truncate table nms.nmsuper.line_types
# truncate table nms.SAnms.permissions
# truncate table nms.nmsuper.net_types
# truncate table nms.nmsuper.procinfo
# truncate table nms.nmsuper.SysFiles
# truncate table nms.dbo.SystemEvents
# truncate table nms.dbo.DumpDevices
# truncate table nms.nmsuper.pccmdset
# truncate table nms.nmsuper.pcdevset
# go
# quit

Now individually load each standard Cisco-created database table from its dumped file using the bcp command (note its "in" on Solaris, "out" on SunOS):
        bcp table_name in table_name.dat -c -t "\t" -Usa -P$sa_password

table_name is the name of the table to be loaded.

To save typing the entire bcp command, you can create an alias as shown below (again note its "in" on Solaris, "out" on SunOS):
        # alias bcp 'bcp \!^ in \!^.dat -c -t "\t" -Usa -P$sa_password'

Then use this aliased bcp command on each table as shown below:
# bcp polldb.nmsuper.polls_config
# bcp polldb.nmsuper.tables
# bcp polldb.nmsuper.columns
# bcp polldb.nmsuper.summaryinfo
# bcp polldb.nmsuper.grouptemplate
# bcp polldb.nmsuper.attr
# bcp polldb.nmsuper.action
# bcp polldb.nmsuper.start_stop
# bcp polldb.nmsuper.pollers
# bcp polldb.nmsuper.msglog
# bcp polldb.nmsuper.filterlog
# bcp polldb.nmsuper.applog
# bcp polldb.nmsuper.ciscolog
# bcp polldb.nmsuper.sample
# bcp polldb.nmsuper.sample_error
# bcp polldb.nmsuper.sample_load
# bcp polldb.nmsuper.sample_traffic
# bcp polldb.nmsuper.sample_mix
# bcp nms.cisco_connect.cisco_connect_users
# bcp nms.SAnms.applications
# bcp nms.SAnms.app_bits
# bcp nms.nmsuper.auto_install
# bcp nms.nmsuper.sw_inventory
# bcp nms.SAnms.logins
# bcp nms.SAnms.groups
# bcp nms.SAnms.users
# bcp nms.SAnms.group_users
# bcp nms.SAnms.group_domains
# bcp nms.nmsuper.gcmds_domains
# bcp nms.nmsuper.gcmds
# bcp nms.nmsuper.domains_devices
# bcp nms.nmsuper.domains
# bcp nms.nmsuper.summaryinfo
# bcp nms.nmsuper.DevConfigs
# bcp nms.nmsuper.DevConfHist
# bcp nms.nmsuper.DevConfFileLoc
# bcp nms.nmsuper.interfaces
# bcp nms.nmsuper.devices
# bcp nms.nmsuper.crons
# bcp nms.nmsuper.if_addresses
# bcp nms.nmsuper.locations
# bcp nms.nmsuper.admins
# bcp nms.nmsuper.vendors
# bcp nms.nmsuper.people
# bcp nms.nmsuper.phones
# bcp nms.nmsuper.contacts
# bcp nms.nmsuper.admin_contacts
# bcp nms.nmsuper.vendor_contacts
# bcp nms.nmsuper.line_contacts
# bcp nms.nmsuper.lines
# bcp nms.nmsuper.networks
# bcp nms.nmsuper.net_numbers
# bcp nms.nmsuper.device_types
# bcp nms.nmsuper.interface_types
# bcp nms.nmsuper.protocol_types
# bcp nms.nmsuper.line_types

# bcp nms.SAnms.permissions
# bcp nms.nmsuper.net_types
# bcp nms.nmsuper.procinfo
# bcp nms.nmsuper.SysFiles
# bcp nms.dbo.SystemEvents
# bcp nms.dbo.DumpDevices
# bcp nms.nmsuper.pccmdset
# bcp nms.nmsuper.pcdevset

If you chose to save any user-defined poll group tables on SunOS, you must load them into the polldb database. To do so, truncate the polldb.nmsuper.polls table by entering the following commands:
        # isql -Usa -P$sa_password
# truncate table polldb.nmsuper.polls
# go
# quit

Then load the polldb.nmsuper.polls table by entering the following command:
        # bcp polldb.nmsuper.polls

Next, load each of the user-created tables you dumped on SunOS by entering a bcp command:
        bcp polldb.nmsuper.CREATED_TABLENAME

Proceed to Step 7.

Step 5 If you chose to use the copy_tables script on SunOS, it should now be in your $saved directory. Make sure it is still executable, and then run it using the following commands:
        # chmod +x copy_tables
# ./copy_tables in $sa_password $cwd

Step 6 Log in to isql as sa and unset the bulkcopy option:
        # isql -Usa -P$sa_password
# sp_dboption nms, "select into/bulkcopy", false
# go
# quit

Step 7 Restore the non-Sybase files you chose to save from SunOS. If you saved your CiscoConnect history, enter the following commands:
        # cd $NMSROOT/lib/httpd/conf
# tar xvf $saved/cc-conf.tar
# cd $NMSROOT/lib/httpd
# tar xvf $saved/cc-query.tar

If you saved your TACACS information, enter the following commands:
        # cd /etc
# tar xvf $saved/tacacs.tar

If saved your crontab entries, enter the following command:
        # crontab $saved/cronfile

Step 8 For safety's safe, backup your new database immediately, now that you have finshed the migration.
Note If you get errors that look like "You cannot run the non-logged version of bulkcopy in this database," when using either bcp or copy_tables to load your database on Solaris, it generally means the database was not checkpointed (see Step 3). If you were using the bcp command, repeat Step 3, truncate the table as in Step 4, and then redo the bcp command. It is essential to truncate the table before redoing the bcp command or you may end up with duplicate rows in the table which will cause problems. If you were using copy_tables, repeat Step 3 and reissue the copy_tables command. You do not need to truncate the table.

Table 1 lists the tables moved by the copy_tables command.

Table 1 Tables Moved by the Copy_Tables Command

Database Table Owner Table Name
polldb nmsuper polls_config
polldb nmsuper tables
polldb nmsuper column
polldb nmsuper summaryinfo
polldb nmsuper grouptemplate
polldb nmsuper polls
polldb nmsuper attr
polldb nmsuper action
polldb nmsuper start_stop
polldb nmsuper pollers
polldb nmsuper msglog
polldb nmsuper filterlog
polldb nmsuper applog
polldb nmsuper ciscolog
polldb nmsuper sample
polldb nmsuper sample_error
polldb nmsuper sample_load
polldb nmsuper sample_traffic
polldb nmsuper sample_mix
nms cisco_connect cisco_connect_users
nms SAnms applications
nms SAnms app_bits
nms nmsuper auto_install
nms nmsuper sw_inventory
nms SAnms logins
nms SAnms groups
nms SAnms users
nms SAnms group_users
nms SAnms group_domains
nms nmsuper gcmds_domains
nms nmsuper gcmds
nms nmsuper domains_devices
nms nmsuper domains
nms nmsuper summaryinfo
nms nmsuper DevConfigs
nms nmsuper DevConfHist
nms nmsuper DevConFileLoc
nms nmsuper interfaces
nms nmsuper devices
nms nmsuper crons
nms nmsuper if_addresses
nms nmsuper locations
nms nmsuper admins
nms nmsuper vendors
nms nmsuper people
nms nmsuper phones
nms nmsuper contacts
nms nmsuper admin_contacts
nms nmsuper vendor_contacts
nms nmsuper line_contacts
nms nmsuper lines
nms nmsuper networks
nms nmsuper net_numbers
nms nmsuper device_types
nms nmsuper interface_types
nms nmsuper protocol_types
nms nmsuper line_types
nms SAnms permissions
nms nmsuper net_types
nms nmsuper procinfo
nms nmsuper SysFiles
nms dbo SystemEvents
nms dbo DumpDevices
nms nmsuper pccmdset
nms nmsuper pcdevset


Cisco Connection Online

Cisco Connection Online (CCO) is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional content and services.

Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.

CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously---a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO (called "CCO Classic") supports Zmodem, Kermit, Xmodem, FTP, Internet e-mail, and fax download options, and is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.

You can access CCO in the following ways:

For a copy of CCO's Frequently Asked Questions (FAQ), contact ciohelp@cisco.com. For additional information, contact cioteam@cisco.com.

If you are a network administrator and need personal technical assistance with a Cisco product that is under warranty or covered by a maintenance contract, contact Cisco's Technical Assistance Center (TAC) at 800 553-2447, 408 526-7209, or tac@cisco.com. To obtain general information about Cisco Systems, Cisco products, or upgrades, contact 800 553-6387, 408 526-7208, or csrep@cisco.com.


HomeTOCPrevNextGlossSearchHelp
-

Copyright 1988-1996 © Cisco Systems Inc.
