Native Service Point 1.0 Release Note
This release note provides information about changes to CiscoWorks Blue Native Service Point 1.0 that are not documented in the CiscoWorks Blue Native Service Point Installation and Reference Guide, Software Release 1.0. Use this release note as a supplement to the CiscoWorks Blue Native Service Point Installation and Reference Guide.
Following are the topics in this release note:
The sample output of the contents of a $NWRUNCX NCL is changed and the correct output is shown below:
>>CHANGE 00010000
-* NAME : $NWRUNCM EWR0XX *00100000
>>TO 00100100
-* NAME : $NWRUNCX EWR0XX *00101000
-* *00110000
>>ADD 00120000
-* Modify DATE : 29-JUN-1995 *00231000
-* SHRVARS=(NSPHCOPY,SV32TXT,SYSMSG) *00232000
*00233000
>>ADD 01161000
-* JUL 95 Modified. Add NSPHCOPY to suppress output H.Liberty*01170000
>>BEFORE 01170100
-* JUN 92 CREATION. B.YUNG *01171000
01210000
>>CHANGE (REQUIRED) 01220000
&CONTROL UCASE NOSHRVARS 01280000
>>TO 01280100
&CONTROL NOUCASE NOSHRVARS (Need lower case for router) 01280200
01280300
>>ADD 01300000
&IF .&NSPHCOPY NE .NO &THEN + -* Modified by HJL 03920000
>>BEFORE 03921000
&WRITE DATA=EW0019 &WK1 03930000
>>ADD 03940000
&IF .&NSPHCOPY NE .NO &THEN + -* Modified by HJL 04190000
>>BEFORE 04191000
&WRITE DATA=EW0020 &WK -* WRITE THE HIERARCHY 04200000
04201000
>>ADD 04210000
&IF .&NSPHCOPY NE .NO &THEN + -* Modified by HJL 04300000
>>BEFORE 04301000
&WRITE DATA=EW0020 &WK -* WRITE THE HIERARCHY 04310000
>>ADD 04320000
&IF .&NSPHCOPY NE .NO &THEN + -* Modified by HJL 04540000
>>BEFORE 04541000
&WRITE LOG=YES DATA=EWR003 MESSAGE TEXT 04550000
04560000
>>ADD 04570000
&IF .&NSPHCOPY NE .NO &THEN + -* Modified by HJL 04800000
>>BEFORE 04801000
&WRITE LOG=YES DATA=EWR004 &WK4 04810000
04811000
>>ADD 04820000
&IF .&NSPHCOPY NE .NO &THEN + -* Modified by HJL 05111000
>>BEFORE 05111100
&WRITE LOG=YES DATA=EW0018 *END* -* DISPLAY TERMINATION MSG 05112000
?
In the procedure for building a list of routers for the NetView version of Native Service Point, access the NSPSINIT CLIST (documented in the manual as NSPSINIT CLIST) and enter the following line for each router you want to access from Native Service Point:
&NSPLSTn = 'SPname [domain]
[host name]'
Refer to the CiscoWorks Blue Native Service Installation and Reference Guide for the remainder of the procedure and save the NSPSINIT CLIST.
In the procedure for building a list of routers for the NetMaster version of Native Service Point, access the NSPSINIT NCL (documented in the manual as NSPSINIT CLIST) and enter the following line for each router you want to access from Native Service Point:
&NSPLSTn = 'SPname [domain]
[host name]'
Refer to the CiscoWorks Blue Native Service Installation and Reference Guide for the remainder of the procedure and save the NSPSINIT NCL procedure.
To enable Native Service Point to automatically obtain and provide an updated status of your routers, the domains where they are located, and information of any operators that are logged in to the routers, your programmer needs to add certain commands to the NetView automation table or the NetMaster MSGPROC procedure.
This section provides the correct commands to be used by your programmer.
If you use NetView, your programmer should complete this procedure to ensure that the latest status about your routers is available to you in Native Service Point.
IF MSGID='IST5901' & TEXT=MESSAGE THEN EXEC (CMD(`NSP590E' MESSAGE)) DISPLAY(Y) NETLOG(Y);
IF MSGID='IST5901' & TEXT=MESSAGE THEN EXEC (CMD(`NSP590E' MESSAGE)) DISPLAY(Y) NETLOG(Y) CONTINUE(Y);$
If you use NetMaster, your programmer should complete this procedure to ensure that the latest status about your routers is available to you in Native Service Point.
.M#IST590I .M#5D90I &NODE = &STR &5 -* SAVE THE NODE Name &NODECONN = &STR &2 -* GET THE NODE Status NSP590E &NODE &NODECONN -* Call Update status &GOTO .LOOP -* NEXT MESSAGE
&NODE = &STR &5 -* SAVE THE NODE Name &NODECONN = &STR &2 -* GET THE NODE Status NSP590E &NODE &NODECONN -* Call Update status
If you use NetView, your programmer should complete this procedure to ensure that the latest status about your routers is available to you in Native Service Point.
IF MSGID='IST5901' & TEXT=MESSAGE THEN EXEC (CMD(`NSP590E' MESSAGE)) DISPLAY(Y) NETLOG(Y);
IF MSGID='IST5901' & TEXT=MESSAGE THEN EXEC (CMD(`NSP590E' MESSAGE)) DISPLAY(Y) NETLOG(Y) CONTINUE(Y);$
Table 1 shows the correct commands you use to perform various tasks with Native Service Point.
Table 1 Correct Native Service Point Commands
| Command Shown in the Manual | Correct Command |
|---|---|
| rtrhelp | nsphelp |
| rtroper | nspoper |
| rtrcmd | nspcmd |
| rtrrcmd | nsprcmd |
| rtrreset | nspreset |
| rtrmgr | nspmgr |
| rtrsinit | nspsinit |
Table 2 shows the correct panel names.
Table 2 Correct Native Service Point Panels
| Panel Name Shown in the Manual | Correct Panel Name |
|---|---|
| RTRMGR | NSPMGR |
| RTRCMD | NSPCMD |
| RTRHLP | NSPHLP |
Error messages described as beginning with RTR (for example RTRM001) in the manual have changed. All error messages begin with NSP (for example NSPM001).
This section describes changes to the following:
This section provides a listing of the correct names for CLISTs available with the Native Service Point software for NetView.
Table 3 provides a description of the correct CLIST names in Native Service Point.
| CLIST Name in the Manual | Correct CLIST Name | Description |
|---|---|---|
| RTRCMD | NSPCMD | Cisco/NetView router CLIST |
| RTRRCMD | NSPRCMD | Cisco/NetView remote router CLIST |
| RTROPER | NSPOPER | Cisco/NetView operator reset CLIST |
| RTRMGR | NSPMGR | Router status display CLIST |
| RTRSINIT | NSPSINIT | Router Manager initialization CLIST |
| RTR590E | NSP590E | Status automation CLIST |
| RTRHELP | NSPHELP | List of all NSP commands |
This section provides a listing of the names of the correct common GLOBALs available with the Native Service Point software for NetView.
Table B-1 provides a description of the correct common GLOBALs in Native Service Point.
Table 4 Common GLOBAL Names for NetView
| Common Global Names Listed in the Manual | Correct Common Global Names |
Descriptions |
|---|---|---|
| &RTRSINITS | &NSPINITS | Date and time NSPSINIT was last executed. |
| &RTRNUM | &NSPNUM | Number of routers being monitored. |
| &node | &node | Router Service Point Name. |
| &RTR&node = &n = | &NSP&node = &n = | Index number assigned to the router. |
| &RTR&n | &NSP&n | Name of router (&node). |
| &RTR&n | &NSP&n | Name of domain that owns the router &node. |
| &RTH&n | &RTH&n | Host name defined in the router configuration &node. |
| &RTS&n | &RTS&n | Status of router &node. |
| &RTO&n | &RTO&n | Name of operator monitoring router &node. |
This section provides a listing of the names of the correct operator task GLOBALs available with the Native Service Point software for NetView.
Table 5 provides a description of the the correct common GLOBALs in Native Service Point.
Table 5 Operator Task GLOBAL Names for NetView
| Operator Task GLOBALs Listed in the Manual | Correct Operator Task GLOBALs |
Descriptions |
|---|---|---|
| RTRSPN | NSPSPN | Router being interrogated by operator. |
| &RTRHNAME | &NSPHNAME | Host name for router &NSPSPN. |
| &RTRDM | &NSPDM | Domain that owns the router &NSPSPN. |
| &RCMD | &NSPCMD | Last command sent to router &NSPSPN. |
| &RTRINDEX | &NSPINDEX | Number of commands saved for retrieve. |
| &c = | &c= | Saved command. |
| &RTRRCMD&c | &NSPRCMD& | =&NSPSPN &NSPHNAME &NSPDM &RCMD |
| &DEBUG | &DEBUG | Saved value of NSPCMD DEBUG operand. |
| &CTRACE | &CTRACE | Saved value(s) of NSPRESET CTRACE operand(s). |
This section contains the following topics:
This section provides a listing of NCL names and jobs available with the Native Service Point for NetMaster.
Table 5 shows the NCL descriptions for NetMaster version.
Table 6 Correct Names of NCL Descriptions for NetMaster
| CLIST Names Listed in the Manual | Correct CLIST Names | Descriptions |
|---|---|---|
| RTRCMD | NSPCMD | Cisco/NetMaster router. |
| RTRHELP | NSPHELP | Cisco/NetMaster help panel |
| RTRMGR | NSPMGR | Router status display NCL. |
| RTROPER | NSPOPER | Cisco/NetMaster operator reset NCL. |
| RTRRESET | NSPRESET | Cisco/NetMaster messsage retrieval reset. |
| RTRSINIT | NSPSINIT | Router Manager initialization NCL. |
| RTR590E | NSP590E | Status automation NCL. |
Table 6 shows the job descriptions for NetMaster version.
Table 7 Correct Names of Job Descriptions for NetMaster
| Jobs | Description |
|---|---|
| PNALLOC | Cisco/NetMaster NCL |
| PNLRESTR | Cisco/NetMaster NCL |
| NSPMSGPR | MSGPROC for sample automation job. |
This section provides a listing of common variables available with Native Service Point for NetMaster.
Table 8 shows the common variables for NetMaster version.
Table 8 Correct Names of Common Variables for NetMaster
| Common Variables Listed in the Manual | Correct Operator Variables | Description |
|---|---|---|
| &000RTRSINIT | &000NSPSINIT | Date and time the nspsinit command was last executed. |
| &000RTRNUM | &000NSPNUM | Number of routers being monitored. |
| &node | &node | Router Service Point Name. |
| &000&node = &n = | &000&node = &n = | Index number assigned to router &node. |
| &000RTR&n | &000NSP&n | Name of router (&node). |
| &000RTD&n | &000RTD&n | Name of domain that owns router &node. |
| &000RTH&n | &000RTH&n | Host name defined in router &node configuration. |
| &000RTS&n | &000RTS&n | Status of router &node. |
| &000RTO&n | &000RTO&n | Name of operator monitoring router &node. |
| &000RTO&n | &000RTO&n | Saved value of nspcmd debug operand. |
This section provides a listing of operator variables available with Native Service Point for NetMaster.
Table 9 shows the operator variables for NetMaster version.
Table 9 Correct Operator Variables for NetMaster
| Operator Variables Listed in the Manual | Correct Operator Variables | Descriptions |
|---|---|---|
| &RTRSPN | &NSPSPN | Router being interrogated by operator. |
| &RTRHNAME | &NSPHNAME | Host name for router. |
| &RTRDM | &NSPDM | Domain that owns the router. |
| &RCMD | &RCMD | Last command sent to the router. |
| &RTRINDEX | &NSPINDEX | Number of commands saved for retrieval. |
| &c | &c | Index for saved command. |
| &RTRRCMD&c | &NSPRCMD&c | Saved command |
| &RTRRCMD&c | &NSPRCMD&c | &NSPSPN &NSPHNAME &NSPDM &RCMD |
.
|
