Product Numbers: MEM-8BF-53=
Product Numbers: MEM-8S-AS53= , MEM-16S-AS53=
Product Numbers: MEM-32M-AS53= , MEM-64M-AS53=
Product Numbers: MEM-8F-AS53= , MEM-16F-AS53=
This document describes how to replace the boot ROMs, the shared and main memory DRAM SIMMs, and the Flash memory SIMMs, and includes the following sections:
Use this document with the Regulatory Compliance and Safety Information publication that shipped with the Cisco AS5300.
Follow these guidelines to ensure general safety:
Safety warnings appear throughout this publication in procedures that, if performed incorrectly, may harm you. A warning symbol precedes each safety warning.
Warning
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents. To see translations of the warnings that appear in this publication, refer to the Regulatory Compliance and Safety Information document that accompanied this device.
Waarschuwing Dit waarschuwingssymbool betekent gevaar. U verkeert in een situatie die lichamelijk letsel kan veroorzaken. Voordat u aan enige apparatuur gaat werken, dient u zich bewust te zijn van de bij elektrische schakelingen betrokken risico's en dient u op de hoogte te zijn van standaard maatregelen om ongelukken te voorkomen. Voor vertalingen van de waarschuwingen die in deze publicatie verschijnen, kunt u het document Regulatory Compliance and Safety Information (Informatie over naleving van veiligheids- en andere voorschriften) raadplegen dat bij dit toestel is ingesloten.
Varoitus Tämä varoitusmerkki merkitsee vaaraa. Olet tilanteessa, joka voi johtaa ruumiinvammaan. Ennen kuin työskentelet minkään laitteiston parissa, ota selvää sähkökytkentöihin liittyvistä vaaroista ja tavanomaisista onnettomuuksien ehkäisykeinoista. Tässä julkaisussa esiintyvien varoitusten käännökset löydät laitteen mukana olevasta Regulatory Compliance and Safety Information -kirjasesta (määräysten noudattaminen ja tietoa turvallisuudesta).
Attention Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une situation pouvant causer des blessures ou des dommages corporels. Avant de travailler sur un équipement, soyez conscient des dangers posés par les circuits électriques et familiarisez-vous avec les procédures couramment utilisées pour éviter les accidents. Pour prendre connaissance des traductions d'avertissements figurant dans cette publication, consultez le document Regulatory Compliance and Safety Information (Conformité aux règlements et consignes de sécurité) qui accompagne cet appareil.
Warnung Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu einer Körperverletzung führen könnte. Bevor Sie mit der Arbeit an irgendeinem Gerät beginnen, seien Sie sich der mit elektrischen Stromkreisen verbundenen Gefahren und der Standardpraktiken zur Vermeidung von Unfällen bewußt. Übersetzungen der in dieser Veröffentlichung enthaltenen Warnhinweise finden Sie im Dokument Regulatory Compliance and Safety Information (Informationen zu behördlichen Vorschriften und Sicherheit), das zusammen mit diesem Gerät geliefert wurde.
Avvertenza Questo simbolo di avvertenza indica un pericolo. La situazione potrebbe causare infortuni alle persone. Prima di lavorare su qualsiasi apparecchiatura, occorre conoscere i pericoli relativi ai circuiti elettrici ed essere al corrente delle pratiche standard per la prevenzione di incidenti. La traduzione delle avvertenze riportate in questa pubblicazione si trova nel documento Regulatory Compliance and Safety Information (Conformità alle norme e informazioni sulla sicurezza) che accompagna questo dispositivo.
Advarsel Dette varselsymbolet betyr fare. Du befinner deg i en situasjon som kan føre til personskade. Før du utfører arbeid på utstyr, må du vare oppmerksom på de faremomentene som elektriske kretser innebærer, samt gjøre deg kjent med vanlig praksis når det gjelder å unngå ulykker. Hvis du vil se oversettelser av de advarslene som finnes i denne publikasjonen, kan du se i dokumentet Regulatory Compliance and Safety Information (Overholdelse av forskrifter og sikkerhetsinformasjon) som ble levert med denne enheten.
Aviso Este símbolo de aviso indica perigo. Encontra-se numa situação que lhe poderá causar danos físicos. Antes de começar a trabalhar com qualquer equipamento, familiarize-se com os perigos relacionados com circuitos eléctricos, e com quaisquer práticas comuns que possam prevenir possíveis acidentes. Para ver as traduções dos avisos que constam desta publicação, consulte o documento Regulatory Compliance and Safety Information (Informação de Segurança e Disposições Reguladoras) que acompanha este dispositivo.
¡Advertencia! Este símbolo de aviso significa peligro. Existe riesgo para su integridad física. Antes de manipular cualquier equipo, considerar los riesgos que entraña la corriente eléctrica y familiarizarse con los procedimientos estándar de prevención de accidentes. Para ver una traducción de las advertencias que aparecen en esta publicación, consultar el documento titulado Regulatory Compliance and Safety Information (Información sobre seguridad y conformidad con las disposiciones reglamentarias) que se acompaña con este dispositivo.
Varning! Denna varningssymbol signalerar fara. Du befinner dig i en situation som kan leda till personskada. Innan du utför arbete på någon utrustning måste du vara medveten om farorna med elkretsar och känna till vanligt förfarande för att förebygga skador. Se förklaringar av de varningar som förkommer i denna publikation i dokumentet Regulatory Compliance and Safety Information (Efterrättelse av föreskrifter och säkerhetsinformation), vilket medföljer denna anordning.
| Warning Read the installation instructions before you connect the system to its power source. |
| Warning Ultimate disposal of this product should be handled according to all national laws and regulations. |
| Warning Only trained and qualified personnel should be allowed to install or replace this equipment. |
| Warning Before working on a chassis or working near power supplies, unplug the power cord on AC units; disconnect the power at the circuit breaker on DC units. |
| Warning Before performing any of the following procedures, ensure that power is removed from the DC circuit. To ensure that all power is OFF, locate the circuit breaker on the panel board that services the DC circuit, switch the circuit breaker to the OFF position, and tape the switch handle of the circuit breaker in the OFF position. |
| Warning Before working on equipment that is connected to power lines, remove jewelry (including rings, necklaces, and watches). Metal objects will heat up when connected to power and ground and can cause serious burns or weld the metal object to the terminals. |
Follow these guidelines when working on equipment powered by electricity:
Electrostatic discharge (ESD) can damage equipment and impair electrical circuitry. It occurs when electronic printed circuit cards are improperly handled and can result in complete or intermittent failures. Always follow ESD prevention procedures when removing and replacing cards. Ensure that the chassis is electrically connected to earth ground. Wear an ESD-preventive wrist strap, ensuring that it makes good skin contact. Connect the clip to an unpainted surface of the chassis frame to safely channel unwanted ESD voltages to ground. To properly guard against ESD damage and shocks, the wrist strap and cord must operate effectively. If no wrist strap is available, ground yourself by touching the metal part of the chassis.
 | Caution For safety, periodically check the resistance value of the antistatic strap, which should be between 1 and 10 megohms (Mohm). |
The Cisco AS5300 access server contains the following memory systems:
This kit includes one of the following items:
To remove or install the boot ROM or the SIMMs, you will also need the following tools and equipment (which are not included):
This section describes how gain access to the internal components by removing the chassis cover.
| Warning Do not touch the power supply when the power cord is connected. For systems with a power switch, line voltages are present within the power supply even when the power switch is off and the power cord is connected. For systems without a power switch, line voltages are present within the power supply when the power cord is connected. |
| Warning Before working on a chassis or working near power supplies, unplug the power cord on AC units; disconnect the power at the circuit breaker on DC units. |
| Warning Before opening the chassis, disconnect the telephone-network cables to avoid contact with telephone-network voltages. |
| Warning Do not work on the system or connect or disconnect cables during periods of lightning activity. |
To remove the chassis cover:
Step 1 Turn the power switch on the access server OFF and disconnect site power. (Note that the power switch is part of the power supply.)
Step 2 Remove all interface cables from the rear panel of the access server.
Step 3 Place the access server so that the front panel is facing you.
Step 4 Remove the four screws on the chassis cover, as shown in Figure 1.
Step 5 Lift the chassis cover upward as shown in Figure 2, and pull it away from the tabs on the rear of the chassis.
Place the chassis cover in a safe place where it will not be damaged.
This section describes how to remove features cards. You must remove the feature cards to access the packet (shared) memory SIMM, one of the two main memory DRAM SIMMs, and the boot ROM. It is not necessary to remove the feature cards to access the Flash memory SIMMs.
| Warning The E1 interface card may only be installed in an AUSTEL-permitted customer equipment or a data terminal equipment that is exempted from AUSTEL's cabinet, which has screw-down lids to stop user access to overvoltages on the customer equipment. The customer equipment has circuitry that may have telecommunications network voltages on them. |
| Caution The feature cards are not hot-swappable (that is, you cannot remove or install them when the power to the access server is ON). Be sure to turn OFF the power to the access server before installing or removing feature cards. Failure to do so can damage the access server. |
To remove feature cards, refer to Figure 3 and take these steps:
Step 1 Turn the power switch on the access server OFF and disconnect site power.
Step 2 Attach an ESD-preventive wrist strap.
Step 3 Remove all interface cables from the rear panel of the access server.
Step 4 Loosen the two captive screws that secure the feature card to the chassis until each screw is free of the chassis.
Step 5 Insert the feature card removal tool so that the slots in each arm of the tool are behind the shoulder of each captive screw, as shown in Figure 4, and carefully pull the removal tool toward you until the feature card slides free of the chassis.
| Caution The EMI protective devices on the feature cards are designed to make the cards fit tightly. When removing the cards, they can release suddenly. Exercise caution when removing the feature cards with the removal tool. |
Step 6 Set the removed feature card aside on an ESD-preventive mat.
To upgrade the boot ROM software to a new software image, you must replace the existing boot ROM.
| Warning Before working on a chassis or working near power supplies, unplug the power cord on AC units; disconnect the power at the circuit breaker on DC units. |
| Warning Before performing any of the following procedures, ensure that power is removed from the DC circuit. To ensure that all power is OFF, locate the circuit breaker on the panel board that services the DC circuit, switch the circuit breaker to the OFF position, and tape the switch handle of the circuit breaker in the OFF position. |
| Caution To avoid damaging ESD-sensitive components, observe all ESD precautions when handling SIMMs. To avoid damaging the motherboard or the SIMM, avoid excessive force when you remove or replace SIMMs. |
To replace the boot ROM:
Step 1 Turn the power switch on the access server OFF and disconnect site power.
Step 2 Attach an ESD-preventive wrist strap.
Step 3 Remove the chassis cover. (See the instructions in the section "Removing the Chassis Cover" earlier in this document.)
Step 4 Remove all feature cards to access the system card. (See the instructions in the section "Removing Feature Cards" earlier in this document.)
Step 5 Locate the boot ROM on the system card using Figure 5.
Step 6 Gently extract the old boot ROM with a ROM extraction tool or a small flat-blade screwdriver, and set the old boot ROM on a nonconductive surface.
Step 7 Insert the new boot ROM into the socket. Be careful not to bend or crush any of the bottom pins. If necessary, use needlenose pliers to straighten out any bent pins.
| Caution The notch in the ROM must align with the notch in the socket on the system card. If the ROM is installed backwards, it will be damaged when the access server is powered ON. |
Step 8 Replace any feature cards removed. (See the instructions in the section "Replacing Feature Cards" later in this document.
Step 9 Replace the access server chassis cover. (See the instructions in the section "Replacing the Chassis Cover" later in this document.)
Step 10 Power ON the access server. If error messages relating to memory are displayed, remove the new boot ROM and reinstall it, taking care to seat the ROM firmly in its socket.
This section describes how to replace the DRAM SIMMs on the system card. You might need to replace the DRAM SIMMs for the following reasons:
The system card contains three sockets for DRAM SIMMs (see Figure 5):
| Warning Before working on a chassis or working near power supplies, unplug the power cord on AC units; disconnect the power at the circuit breaker on DC units. |
| Warning Before performing any of the following procedures, ensure that power is removed from the DC circuit. To ensure that all power is OFF, locate the circuit breaker on the panel board that services the DC circuit, switch the circuit breaker to the OFF position, and tape the switch handle of the circuit breaker in the OFF position. |
| Caution To avoid damaging ESD-sensitive components, observe all ESD precautions when handling SIMMs. To avoid damaging the motherboard or the SIMM, avoid excessive force when you remove or replace SIMMs. |
To replace the DRAM SIMMs:
Step 1 Turn the power switch on the access server OFF and disconnect site power.
Step 2 Attach an ESD-preventive wrist strap.
Step 3 Remove the chassis cover. (See the instructions in the section "Removing the Chassis Cover" earlier in this document.)
Step 4 Remove all feature cards to access the system card. (See the instructions in the section "Removing Feature Cards" earlier in this document.)
Step 5 Use Figure 5 to locate the SIMM you are replacing.
Step 6 Pull the socket latches away from the SIMM, and then pull the SIMM out of the socket, as shown in Figure 6. The latches hold the SIMM tightly, so be careful not to break the latches.
Step 7 Position the new SIMM so that the polarization notch is located at the right end of the SIMM socket.
Step 8 Insert the new DRAM SIMM by sliding the end with the metal fingers into the SIMM socket at approximately a 45-degree angle to the system card, as shown in Figure 7.
Step 9 Gently rotate the SIMM until the latches snap into place, Do not use excessive force because the socket might break.
Step 10 Replace the feature cards. (See the instructions in the section "Replacing Feature Cards" later in this document.)
Step 11 Replace the access server chassis cover. (See the instructions in the section "Replacing the Chassis Cover" later in this document.)
Step 12 Power ON the access server. If error messages relating to memory are displayed, remove the DRAM SIMM and reinstall it, taking care to seat the SIMM firmly in its socket.
The system card contains three sockets for Flash memory SIMMs (see Figure 5):
Flash memory SIMMs must be purchased from Cisco Systems, Inc. For ordering information, refer to the Information Packet that accompanied your access server.
| Warning Before working on a chassis or working near power supplies, unplug the power cord on AC units; disconnect the power at the circuit breaker on DC units. |
| Warning Before performing any of the following procedures, ensure that power is removed from the DC circuit. To ensure that all power is OFF, locate the circuit breaker on the panel board that services the DC circuit, switch the circuit breaker to the OFF position, and tape the switch handle of the circuit breaker in the OFF position. |
| Caution To avoid damaging ESD-sensitive components, observe all ESD precautions when handling SIMMs. To avoid damaging the motherboard or the SIMM, avoid excessive force when you remove or replace SIMMs. |
To replace the Flash Memory SIMMs:
Step 1 Turn the power switch on the access server OFF and disconnect site power.
Step 2 Attach an ESD-preventive wrist strap.
Step 3 Remove the chassis cover. (See the previous procedure in the section "Removing the Chassis Cover" earlier in this document.)
Step 4 Place the chassis so that the system card is oriented as shown in Figure 5, with the Flash memory SIMMs toward you. The system-code SIMM sockets are labeled SIMM0 and SIMM1; the rxboot SIMM socket is labeled SIMM.
Step 5 Remove the existing Flash memory SIMM by pulling outward on the socket latches and then lifting the SIMM out of the socket (see Figure 8).
Step 6 Repeat these steps for all the Flash memory SIMMs that you need to replace.
Step 7 Insert the new SIMM by sliding the end with the metal fingers into the appropriate SIMM socket at approximately a 45-degree angle to the system card as shown in Figure 9.
Step 8 Gently rotate the SIMM until the latch on either side snaps into place. Do not use excessive force because the connector might break. When inserting the new SIMM, make sure that the polarization notch is located at the right end of the SIMM socket.
Step 9 Replace any feature cards removed. (See the instructions in the next section,"Replacing Feature Cards."
Step 10 Replace the access server chassis cover. (See the instructions in the section, "Replacing the Chassis Cover" later in this document)
Step 11 Connect the access server to a console terminal.
Step 12 Power ON the access server. If any memory-related error messages appear, remove the Flash memory SIMM and reinstall it, taking care to seat the SIMM firmly in the socket.
This section describes how to replace the features cards, which were removed to access the system board.
| Warning The E1 interface card may only be installed in an ACA-permitted customer equipment or a data terminal equipment that is exempted from ACA's cabinet which has screw-down lids to stop user access to overvoltages on the customer equipment. The customer equipment has circuitry that may have telecommunications network voltages on them. |
| Caution The feature cards are not hot-swappable (that is, you cannot remove or install them when the power to the access server is ON). Be sure to turn OFF the power to the access server before installing or removing feature cards. Failure to do so can damage the access server. |
To replace feature cards, refer to Figure 10 and take these steps:
Step 1 Remove the feature card from the ESD-preventive mat.
Step 2 Slide the card into the slot until it touches the backplane connector.
Step 3 Align the captive screws with their holes, and then seat the card completely.
Step 4 Tighten the two captive screws to secure the card to the chassis.
Step 5 If the access server is configured with fewer than three cards, make sure that a blank slot cover is installed over each open slot to ensure proper airflow inside the chassis.
Step 6 Replace the access server chassis cover. (See the instructions in the next section, "Replacing the Chassis Cover.")
To replace the chassis cover, refer to Figure 11 and take these steps:
Step 1 Place the chassis bottom so that the front panel is facing you.
Step 2 Hold the chassis cover over the chassis bottom, and align each of the cover tabs with the chassis tabs at the top rear of the chassis, as shown in Figure 11.
Step 3 Lower the front of the chassis cover to close the chassis.
When the chassis cover is closed, ensure the following:
When the chassis cover is properly assembled, no tabs should be visible.
Step 4 Secure the chassis cover with four screws.
Step 5 Reinstall the chassis on a rack, desktop, or table.
Step 6 Reinstall all interface cables and reconnect the AC power cord or rewire the DC power supply.
| Warning After wiring the DC power supply, remove the tape from the circuit breaker switch handle and reinstate power by moving the handle of the circuit breaker to the ON position. |
Step 7 Power ON the access server.
The internal power supply fan and the exhaust fans should power on.
