Release Notes for the Catalyst 2800 and Catalyst 2100 Firmware Version 3.76

March 6, 1997

These release notes describe modifications made to the Catalyst 2800 and Catalyst 2100 firmware for Version 3.76.

For more information, see the product documentation:

Catalyst 2800 User Guide
Catalyst 2800 Modules User Guide
Catalyst 2100 User Guide
Catalyst 2000 MIB Reference Manual

Important Notes

All modifications and features added to the firmware prior to Version 3.76 are documented in Release Notes for Catalyst 2800 and Catalyst 2100 Firmware Version 3.71.

Version 3.76 Modifications

The following modifications are included in Version 3.76:

To avoid connectivity problems, the switch automatically suspends a port when a loopback twisted-pair cable is connected to it.
To enhance Telnet connectivity, the firmware has been improved to reduce the chance of Telnet connections failing.
The switch ages out Telnet connections when the workstation side of the connection is not closed properly.
Broadcast packets are forwarded to eligible ports and to the switch management software for processing. Packets forwarded for processing encounter a threshold that is designed to prevent the management queue from overflowing. This threshold has been increased from 50 to 300 packets per second.
The default IP time-to-live value has been increased from 15 to 255.
Large switch-management IP packets are now properly fragmented when transmitted from the FDDI module.
The FDDI module uses the IP address of the switch to discover the maximum transmission unit (MTU) path.
The switch now supports two types of Content-Addressable Memory devices: Music Semiconductor MU9C1480 and MU9C2480.

For service and support for a product purchased from a reseller, contact the reseller. Resellers offer a wide variety of Cisco service and support programs, which are described in the section "Service and Support" in the information packet that shipped with your product.

Note If you purchased your product from a reseller, you can access Cisco Connection Online (CCO) as a guest. CCO is Cisco Systems' primary, real-time support channel. Your reseller offers programs that include direct access to CCO's services.

For service and support for a product purchased directly from Cisco, use CCO.

Cisco Connection Online

CCO is Cisco Systems' primary, real-time support channel. SMARTnet customers and partners can self-register on CCO to obtain additional information and services.

Note If you purchased your product from a reseller, you can access CCO as a guest. Your reseller offers programs that include direct access to CCO's services.

Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.

CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.

You can access CCO in the following ways:

WWW: http://www.cisco.com
WWW: http://www-europe.cisco.com
WWW: http://www-china.cisco.com
Telnet: cco.cisco.com
Modem: From North America, 408 526-8070; from Europe, 33 1 64 46 40 82. Use the following terminal settings: VT100 emulation; databits: 8; parity: none; stop bits: 1; and connection rates up to 28.8 kbps.

For a copy of CCO's Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.

Note If you need technical assistance with a Cisco product that is under warranty or covered by a Cisco maintenance contract, contact Cisco's Technical Assistance Center (TAC) at 800 553-2447, 408 526-7209, or tac@cisco.com.

Please use CCO to obtain general information about Cisco Systems, Cisco products, or upgrades. If CCO is not accessible, contact 800 553-6387, 408 526-7208, or cs-rep@cisco.com.
